Akai AMC306 User Manual

Microset
Hide thumbs
Table of Contents

Advertisement

Quick Links

AMC306 – Microset
User manUal
en
© Elmarc, 14/04

Advertisement

Table of Contents
loading

Related Manuals for Akai AMC306

Summary of Contents for Akai AMC306

  • Page 1 AMC306 – Microset User manUal © Elmarc, 14/04...

  • Page 2: Table Of Contents

    Table of contents Intended use Safety 2.1 Labels in this manual 2.2 General safety instructions Functions 3.1 Remote control 3.2 AMC306 Microset Operation 4.1 CD functions 4.2 Radio functions 4.3 USB functions 4.4 LINE-IN Cleaning and maintenance 5.1 Handle and care of a disc Disposalofusedelectricandelectronicequipment Technical data...

  • Page 3: Intended Use

    1 Intended use The Microset plays music from CDs and USB. Music can also be played via the LINE-IN port. The FM function lets you listen to the radio. Read the manual with care before the first use. 5 A number of functions are not described in this manual. Please read the quick start guide that comes with the product. Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories. Confidential unpublished works. Copyright 1992-1997 Dolby Laboratories. All rights reserved. 5 Because of the great variety of products with USB ports and their sometimes quite manufacturer-specific functions we can neither guarantee that all devices will be recognised, nor that all operating options that are possible in theory will actually work.

  • Page 4: Safety

    2 Safety 2.1 Labels in this manual 6 WARNING A warning means that injury or death is possible if the instructions are not obeyed. 1 CAUTION A caution means that damage to the equipment is possible. 5 A note gives additional information, e.g. for a procedure. 2.2 Generalsafetyinstructions 6 WARNING Do not put force on the appliance. The appliance can fall and can cause serious injury. 6 WARNING Do not insert any objects in the ventilation holes. 6 WARNING This appliance employs a laser system. To prevent direct exposure to the laser beam, do not open the appliance. Visible laser radiation when open and interlock defeated. 1 CAUTION Do not spill any liquid on the appliance. 1 CAUTION Do not block the ventilation holes. 5 This appliance is double insulated; therefore no earth wire is required. Always check that the mains voltage corresponds to the voltage on the rating plate.

  • Page 5: Functions

    3 Functions 3.1 Remote control 1. STANDBY button 14. Equaliser button 2. Digit buttons 15. MUTE button 3. PROGRAM button 16. ALB + button 4. ALB - button 17. PLAY/PAUSE button 5. VOLUME button + 18. FAST FORWARD / NEXT 6. FAST REWIND / PREVIOUS button button 7. VOLUME button - 19. TUNER + button 8. TUNER - button 20. FM button 9. CD button 21. SOURCE button 10. USB button 22. RANDOM button 11.

  • Page 6: Amc306 Microset

    • To stop playback, press the AUTO/STOP button (22). • To select the source mode , press the SOURCE button (20). • To switch between Mono and Stereo reception, press the ST/MONO button (24). Sleeptimer • Press the button SLEEP (13) repeatedly until the desired setting is found. The SLEEP indicator is ON. UsingtheEQfunction Select from the various sound effects • Press the button EQ (14) repeatedly until the desired setting is found. 3.2 AMC306 Microset 1. CD compartment 2. LCD Display 3. On / Off key (POWER) 4. SOURCE button 5. Volume dial 6. PLAY/PAUSE button 7. Stop button 8. USB slot 9. Line in jack...

  • Page 7: Operation

    4 Operation 4.1 CDfunctions Preparation • Press the CD compartment (1) to open the appliance • Insert the CD with the label upwards • Close the CD compartment (1) • Press the SOURCE button (20) to select the CD mode. Duringplayback,thefollowingfunctionsareavailable: • To start playback, press the PLAY/PAUSE button (17) once. • To pause playback, press the PLAY/PAUSE button ((17)) once; to resume playback, press the button again. • To select a track, press the PREV button (6) or the NEXT button (18) until the desired track is set.
  • Page 8 • To search for a specific point on the disc, hold the PREV button (6) or the NEXT button (18) until the point is reached and release the button. • Press the digit buttons (2) to select a desired track. • To stop playback, press the AUTO/STOP button (22). 5 Please note: • Normally, if an MP3 disc is loaded, the unit will take longer time to read the initial data. • If a disc contains mixed content (e.g. MP3 and video files), the appliance will only recognise, list and play one content type. ToprogramaCD: With the PROGRAM function favourite tracks from the disks can be stored. • Press the AUTO/STOP key once (22). • Press the PROGRAM key once (3). • To select a track, press the PREV button (6) or the NEXT button (18) until the desired track is set. • Press the PROGRAM button (3) once to store a chosen track. • Repeat the last 2 steps to add to the programme list. • To start playback, press the PLAY/PAUSE button (17) once. • To delete the program during the playback, press the AUTO/STOP button (22) twice. UsingtheREPEATfunction For video discs and audio CDs • Press the REPEAT button (12) once to repeat the current chapter or track.
  • Page 9 REPEAT ALL appears on the display. • Press the button once again to cancel the function. UsingtheRANDOMfunction • Press the button 1 times to play all tracks in random order. The repeat function is now off. RANDOM appears on the display. • Press the button once again to cancel the function. UsingtheALB+/-function For audio discs (MP3/WMA) • Press the ALB- (4) button or the ALB+ (16) button to select the desired folder. UsingtheINTROfunction • Press the INTRO (11) button to play the first ten seconds of a track. • To cancel the function, press the INTRO (11) button again. The appliance will resume the normal playback.

  • Page 10: Radio Functions

    4.2 Radiofunctions • Press the SOURCE key (20) to select the radio mode. TUNER appears on the display. • To switch between Mono and Stereo reception, press the ST/MONO button (24). Automaticallyadjustthefrequency • To search for frequencies automatically, press the AUTO/STOP button (22). • Press the button once again to cancel the function. • To select a preset station, press the digit buttons (2). Adjustthefrequencymanually • To tune to the station of your choice, press the TUN- (8) button or the TUN+ (19) button repeatedly until the frequency is found. • Touch MEMORY (25) to add the current station to your favourites • Use the number buttons to determine the preset position. Start with a 0 for numbers under ten. • To skip to the next preset station, press the PREV button (6) or the NEXT button (18).

  • Page 11: Usb Functions

    4.3 USBfunctions • Insert the USB device in the slot (8). The device can only be connected one way. • Press the SOURCE button (20) to select the USB mode. USB appears on the display. The display shows the total number of tracks. Duringplayback,thefollowingfunctionsareavailable: • Press the PREV button (6) or the NEXT button (18) to select a folder or a file. • Press PLAY/PAUSE (17) to confirm. • To pause playback, press the PLAY/PAUSE button (17) once; to resume playback, press the button again. • To stop playback, press the AUTO/STOP button (22). UsingtheREPEATfunction • Press the REPEAT button (12) once to repeat the current chapter or track.
  • Page 12 • Press the button 2 times to repeat all the numbers within the album. • Press the button 3 times to repeat all chapters or tracks. • To cancel the function, press the REPEAT (12) button again. The appliance will resume the normal playback. • To remove the device, gently pull it out of the slot. Due to the great variety of products with USB ports and their sometimes quite manufacturer-specific functions we can neither guarantee that all devices will be recognised, nor that all operating options that are possible in theory will actually work.

  • Page 13: Line-In

    4.4 LINE-IN • Connect the external appliance to your AMC306 Micro System. • To select the source mode LINE-IN, press the SOURCE button (20). LINE-IN appears on the display. During playback, the following functions are available: • To select a track, press the PREV button (6) or the NEXT button (18) until the desired track is set. • To start playback, press the PLAY/PAUSE button (17) once. • To pause playback, press the PLAY/PAUSE button ((17)) once; to resume playback, press the button again. • To stop playback, press the AUTO/STOP button (22). • To remove the device, gently pull it out of the slot.

  • Page 14: Cleaning And Maintenance

    5 Cleaning and maintenance 6 WARNING Before performing any cleaning or maintenance, switch off and unplug the appliance. • Clean the outside of the appliance with a soft cloth. When the appliance is very dirty, dampen the cloth slightly with water and a neutral solution. • Put the appliance on a horizontal flat surface. • When the appliance is not in use for longer period, we recommend switching the appliance off at the master power switch. 5.1 Handle and care of a disc • Hold the disc with fingers. Hold the disc outer edge and/or the centre spindle hole. Do not touch the disc surface. • Do not bend or press the disc. Do not expose the disc to direct sunlight or heating sources. • Clean the disc surface with a soft, dry cleaning cloth. Wipe the disc surface gently, radially, from centre towards the outer edge. • Do not apply thinner, alcohol, chemical solvent, or sprays when cleaning. Such cleaning fluids will permanently damage the disc surface.

  • Page 15: DisposalOfUsedElectricAndElectronicEquipment

    6 Disposal of used electric and electronic equipment The meaning of the symbol on the material, its accessory or packaging indicates that this product shall not be treated as household waste. Please, dispose of this equipment at your applicable collection point for the recycling of electrical and electronic equipments waste. In the European Union and Other European countries which there are separate collection systems for used electrical and electronic product. By ensuring the correct disposal of this product, you will help prevent potentially hazardous to the environment and to human health, which could otherwise be caused by unsuitable waste handling of this product. The recycling of materials will help conserve natural resources. Please do not therefore dispose of your old electrical and electronic equipment with your household waste. Do not dispose of batteries as household waste but take them to a battery recycling facility. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. For more information and warranty conditions, please visit: www.akai.eu...

  • Page 16: Technical Data

    7 Technical data General • LCD Display • Voltage: 100 - 240VAC ~ 50/60 Hz • Power consumption: 10W • Standby power consumption: <0,5W • Frequency response: +/- 3 dB (20Hz ~20KHz) • Speaker output: 2 x 2,5W RMS • Impedance: 8Ω 3W • Dimensions: • Weight: Disc output • Frequency range: 20Hz ~20KHz • Dynamic range: ≥ 70dB • Signal/noise ratio: > 80dB Remote control • Battery size: 2 x AA • Dimensions: • Weight: Radio • Frequency range: 87,5~108 MHz Supported media formats • Disc types: CD/CD-R/CD-RW • Audio formats: MP3...
