DVD player, home theatre system

CMP AUDIO in
adapter adapter
Blu-ray Disc player, headphones, HD game console & HD camcorder
Notes:
─ USB connectors are for data input from
USB storage devices. Only USB 1 port can
be connected to your USB memory stick.
─ Exposure to excessive sound levels from
earphones and headphones can result in
hearing loss.
─ Number of HDMI may vary.
─ ARC (Audio Return Channel) function is
only supported on HDMI 4 (ARC) port.
It is recommended to connect your home
theatre to the HDMI ARC connector to send
sound from the TV to the sound system via
an HDMI cable.
DVD player/
Home theatre system
Pr Pb
OUT
COMMON
INTERFACE
HD Camcorder
HDMI 1
HDMI 2
HDMI 3
USB
Y R L
Blu-ray Disc player
HD game console
9
