Summary of Contents for Brinno MAC200 DN
- Page 1 Motion Activated Camera MAC200 DN User Manual www.brinno.com...
- Page 3 Register@online http://www.brinno.com/support/register.html contact us: customerservice@brinno.com more information: www.brinno.com...
- Page 4 WEL COME BRINNO FA MI LY ! Follow Brinno to receive the latest product news facebook.com/BrinnoInc...
- Page 5 Thank you for purchasing this Brinno Motion Activated Camera! The Brinno Motion Activated Camera (MAC200 DN) is a battery powered, motion activated security camera. Forget the power cord, Ethernet line or DVR system, it is your 100% DIY, 100% Wire-free, 100% portable security anywhere anytime camera.
-
Page 6: Table Of Contents
Contents Motion Activated Camera Features Parts of the Camera Display Icons LED indicator Installation Initial Set Up Capture Mode Motion Activated Mode Time Lapse Mode Hybrid Mode Start Recording Motion Activated Mode Time Lapse Mode & Hybrid Mode To Stop Recording Basic Installation... - Page 7 MENU Setting SD card capacity Capture Mode Overwrite Timer Playback Rate Image Quality Time Stamp LED Display Band Filter Night Vision Mode Set Latitude Set Date and Time FW version Reset Default Setting What Size SD Card Should I Use Battery Life Specification...
-
Page 8: Motion Activated Camera Features
Motion Activated Camera Features 14 Months Battery Life The Brinno MAC200 DN needs only 2D batteries for up to fourteen months of power. No need for external power = truly portable. Dual Protection 2x 2x Brinno’ new Hybrid Mode® provides the dual functionality of a fixed capture interval + flexible Motion Activation, providing you with an unprecedented level of portable protection. -
Page 9: Package Contents
Instant Video/ Fast Playback The Brinno MAC200 DN captures and converts thousands of photos into a Time Lapse video inside the camera. Review your daily activity with the push of a button. 100% DIY The Brinno MAC200 DN is a battery powered, motion activated security camera. -
Page 10: Parts Of The Camera
Parts of the Camera Front Back 1. Lens 6. Battery Cover 2. Motion Sensor 7. Tree Strap Hole 3. LED Indicator 8. Locking Hole 4. Operation Control Zone Latch 9. External Power Port (DC IN 5V) 5. Operation Control Zone Cover MAC200 DN... - Page 11 Inside Operation Control Zone 10. SD Card Slot 15. OK button 11. Micro USB port 16. Power Switch 12. LCD Panel 13. TIME / Next ( ) button 14. MENU / Previous ( ) button MAC200 DN...
-
Page 12: Display Icons
Hybrid • (green) 2. Capture Interval/ Capture Rate : Battery partially charged. (green) Displayed in Time Lapse Mode/ Low battery-Replace as Hybrid Mode soon as possible. (yellow) 3. System date and time Out of battery-Replace battery immediately. (red) MAC200 DN... - Page 13 Please download files to clear 6. Preview Screen SD card space. 7. Timer 13. SD Card Error 8. Night Vision Mode Please replace SD card. /OFF /AUTO 9. Overwrite 14. Connected to computer via micro USB camera. 10. Battery Level MAC200 DN...
-
Page 14: Led Indicator
LED indicator LED color Green light : Indicates image capture in process. • Red light : Low battery. • Low recording memory on your SD card. • Orange light : PIR sensor is warming up. • MAC200 DN... -
Page 15: Installation
Installation MAC200 DN... -
Page 16: Initial Set Up
Open battery door, insert 2 D batteries and close battery door. Initial Step-2 Installing SD Card Insert the SD card. We support up to 32GB SD cards. And we recommend you use the maximum SD card to save your files. MAC200 DN... - Page 17 Press : Next to confirm and go to the next number. 3. When finished press to exit and return to the Set Up Screen. 4. S T: Standard Time DT: Daylight Saving Time MAC200 DN...
- Page 18 At Preview Screen After 60 seconds without activity on the set up or preview screens, the LCD screen will turn off automatically to save power. You can press to wake up. MAC200 DN...
-
Page 19: Capture Mode
Motion Activation captures direct threats up close. Capture Rate Captures 2-3 frames per second. Once activated captures for Clip Length 5 seconds. Motion Sensor Detecting Angle: 100° Detecting Area Detecting Distance: 6M 6m ( 20 ft ) MAC200 DN... - Page 20 Motion Sensor is activated again, it will extend the capture time for 5 more seconds. When the motion ceases and the Motion Activated Camera finishes capturing, all the frames will be stored into one AVI file. MAC200 DN...
-
Page 21: Time Lapse Mode
Time Lapse mode and cover a range over 100 meters deep in the capture area. Captures 1 frame per second~24 Capture Rate hours ( How to set the Capture Interval? please refer to page 18) > 100m ( 320 ft ) MAC200 DN... -
Page 22: Hybrid Mode
Capture Mode Hybrid Mode Hybrid Mode Brinno Hybrid Mode combines Fixed Capture Rate and Flexible Motion Detection. They provide Dual Protection in the Hot Zone. In standby mode the camera works in Time Lapse Mode, and the camera will capture images at your desired Capture Rate (2 second~24 hours.) When motion is detected... - Page 23 Detecting Zone (Detect angle = 100°/ Detect distance = 6 M), the Motion Activated Camera will shift to the Motion Mode, and captures 2-3 photos per second. At this range it will record the target in greater detail. MAC200 DN...
-
Page 24: Start Recording
1. At the set up screen, press to go to preview screen. 2. Press again to start recording. The LCD will display the “ REC ” icon. 3. After 5 seconds without any activity, the LCD screen will turn off to save power. MAC200 DN... -
Page 25: Time Lapse Mode & Hybrid Mode
23:56:39 1. At the set up screen, press to set a capture interval (capture rate). 2. Press to select a pre-set capture interval or customize it. When complete, press to confirm and return to the set up screen. MAC200 DN... -
Page 26: To Stop Recording
LCD screen turns on. 2. The LCD screen will show the “Processing” icon. The Motion Activated Camera is saving your data. Please wait until the icon disappears. 3. Once complete, the LCD panel will return to the preview screen. MAC200 DN... -
Page 27: Basic Installation
Basic Installation Mount it anywhere, no power required so anywhere really means anywhere. 3 ways to mount the camera Wall Mount MAC200 DN... - Page 28 Basic Installation Wall Mount MAC200 DN...
- Page 29 Rubber Strap Tree strap MAC200 DN...
- Page 30 Basic Installation 2 ways to secure the camera safety Security Lock Cable Camera Body Lock MAC200 DN...
-
Page 31: Sd Card Capacity
SD card capacity Menu 1/14 SD card S i z e Used capacity F r e e In this mode, the LCD will display the SD card capacity, telling you how much free space remains on the SD card. MAC200 DN... -
Page 32: Capture Mode
Cap Mode Motion Capture T.Lapse Mode Hybrid You select your capture mode with this function. 1. Select between : Motion = Motion Activated mode. T. Lapse = Time Lapse mode. Hybrid = Hybrid mode. 2. Press to confirm. MAC200 DN... -
Page 33: Overwrite
Overwrite function will remove old files to ensure SD card has more than 1% free space. If you do not want the SD Card to be over written, and files deleted, select Off. 1. Select On or Off by 2. Press to confirm. MAC200 DN... -
Page 34: Timer
The Timer will allow you to pre-set a recording period. (E.g. 8 am–5 pm) Select 0000-0000 and select to go to the timer setting menu. Don't want to set a daily recording time frame, select Cancel to cancel the setting. MAC200 DN... - Page 35 1600-2330 afternoon to night 2345-0500 overnight 1. Set the start recording time (A area), then set the stop recording time (B area). Press to lower the number, press to increase the number and press to move to the next column. MAC200 DN...
- Page 36 The camera will automatically activate at the start recording time you selected. Once you have activated the Timer, all functions, like Motion Activated mode, Time Lapse mode and Hybrid mode, will only work during the time period selected. MAC200 DN...
-
Page 37: Playback Rate
If the video plays at 1 frame per second, the video will 1 FPS not look smooth, and the video length will be longer. If the video plays at 30 frames per second, the video will 30 FPS look smooth, and the video length will be shorter. MAC200 DN... -
Page 38: Image Quality
The image quality setting will determine the number of frames that can be stored on the SD Card : The higher the quality the fewer images you can store on your SD Card. MAC200 DN... - Page 39 14,000 Best 200~400 KB maximum image photos data for the highest quality images 20,000 Better 150~300 KB General usage photos High compression rate produce less 30,000 Good 70~150 KB image data, best photos for long capture periods MAC200 DN...
-
Page 40: Time Stamp
Time Stamp Time Stamp Menu 7/14 Time Stamp Time Stamp You can choose if you want the time stamp to show at bottom of your video. Select On or Off using the buttons. 1. Select 2. Press to confirm. MAC200 DN... -
Page 41: Led Display
MENU Setting LED Display LED Display Menu 8/14 LED Display Display You can choose whether or not the LED will flash while capturing each frame. 1. Select 2. Press to confirm. MAC200 DN... -
Page 42: Band Filter
1. Select between : None, 50 Hz and 60 Hz options. 2. None : For outdoor enviroments 50 Hz : Europe 60 Hz : USA We suggest you use None when the scene is outdoors. MAC200 DN... -
Page 43: Night Vision Mode
The MAC200 DN is designed to operate in daytime and nighttime environments. The color quality is improved dramatically in daytime and with the addition of the Brinno Night view LED accessory, you will be able to capture events 24’s a day. -
Page 44: Set Latitude
REFER TO PAGE 38) 2. If the Sunrise & Sunset time is not correct, you can change adjust to select a more close time. (HOW TO KNOW SET CORRECT SUNRISE & SUNSET TIMES ? PLEASE REFER TO PAGE 38) MAC200 DN... - Page 45 How to find your location latitude? Please go to: www.latlong.net 1. Type in your location 2. Get your latitude To know your correct sunrise and sunset time? Please go to: www.timeanddate.com/astronomy 1. Type in your location 2. Get the sunrise and sunset time MAC200 DN...
-
Page 46: Set Date And Time
) for a lower number or ) for a higher number. Press : Next to confirm and go to the next number. ST: Standard time DT: Daylight Saving time 2. When finished press to exit and return to the set up screen. MAC200 DN... -
Page 47: Fw Version
MENU Setting FW version FW version Menu 13/14 Firmware Firmware X.XX.X Version Displays the current version of firmware installed on the camera. 1. Displays the current version of firmware. 2. Press to exit. MAC200 DN... -
Page 48: Reset
MENU Setting Reset Reset Menu 14/14 Reset Reset You can reset your camera back to the factory default settings. Select Reset. 2. Select Yes and press to reset your camera. MAC200 DN... -
Page 49: Default Setting
MENU Setting Default setting Function Setting Capture Mode Motion Mode Overwrite Timer Playback Rate 20 FPS Image Quality Good Time Stamp LED Display Band Filter None NightVision MAC200 DN... -
Page 50: What Size Sd Card Should I Use
What Size SD Card Should I Use SD card size Frame 4 GB SD Card 30,000 8 GB SD Card 60,000 16 GB SD Card 120,000 32 GB SD Card 240,000 Base on image quality setting of “Good” MAC200 DN... -
Page 51: Battery Life
5 sec 1,317,800 10 sec 1,118,000 30 sec 696,200 1 min 444,570 5 min 114,240 10 H 59,230 10,185 2,558 24 H Motion mode & Hybrid mode Stand by time: 427 days Frames captured to low battery: 1,845,000 frames MAC200 DN... -
Page 52: Specification
Specification Camera Model MAC200 DN LCD Screen 1.44” TFT LCD Waterproof IPX4 Capture Mode Motion Activated PIR motion detection Time Lapse Fixed Capture Rate Combine Time Lapse and Motion Hybrid Activated mode PIR Sensor Detect distance Detect Angle 100° Image Sensor Type 1/4”... - Page 53 DC IN: 5V Dimension Size(DxWxH) 106x110x78 mm (4.13”x4.29”x3.04”) Weight 250g (without batteries) Color Black Operation Temperature - 20°C ~ 50°C - 4°F ~ 122°F 1. Batteries last 14 months usage under time lapse mode. (time interval setting: 5 minutes.) MAC200 DN...
- Page 54 MAC200 DN...
- Page 55 MAC200 DN...
- Page 56 301 - 0076 - 30 EN A1...
