Support for disks
-
MIDI-DVD,DVD,DVD-R,SVCD,VCD,CD,CD-R,CD-RW,Mp3,Mp4,USB
Karaoke support various functions
-
Function of presetting the song and helps to preset 20 songs.
-
The list of new songs.
-
Favorite songs.
-
Language is displayed in Vietnamese and English.
-
Reserve the song and clear the reserved song as preference
-
Adjust the key and tempo appropriate with each voice.
-
Increase/decrease the song's melody as desired.
-
Install greetings/lines on the screen in Vietnamese.
-
Score and applause as preference.
Qualitative picture, transparent and clear sound
-
Decoding technique MPEG1, MPEG2 and MPEG3, DIVX(Code3.11-5.0).
* Note: not support absolutely 100% for DIVX formats.
-
High quality sound with digital effect.
-
High quality video background (MPEG2).
Other special features:
-
Can use picture from other signal source as background picture in Midi Karaoke play.
-
Unique VOCAL/CHORUS technique with the lively effect of vocal/chorus
-
Play picture and audio data of all formats MP3,MP4,WMA,WAV...
DVD disc can play up to 135', including 8 languages and 32 different captions
-
-
MPEG-2 helps compress picture with high quality sound; creates the great, lively audio and
picture as in the theaters.
USER'S MANUAL
AR-3600Hi
SPECIAL FEATURES
Advertisement
Table of Contents
Related Manuals for Arirang AR-3600Hi
Summary of Contents for Arirang AR-3600Hi
-
Page 1: Special Features
USER’S MANUAL AR-3600Hi SPECIAL FEATURES Support for disks MIDI-DVD,DVD,DVD-R,SVCD,VCD,CD,CD-R,CD-RW,Mp3,Mp4,USB Karaoke support various functions Function of presetting the song and helps to preset 20 songs. The list of new songs. Favorite songs. Language is displayed in Vietnamese and English. Reserve the song and clear the reserved song as preference Adjust the key and tempo appropriate with each voice. -
Page 2: Name Of Each Part
NAME OF EACH PART Front panel 1. POWER key: Turn on/off power 2. MIC port: Use to plug in Microphone. Have 2 micro ports: MIC 1 and MIC 2 3. VOL 1/2 knob: increase/decrease the volume of MIC 1/2 4. ECHO knob: increase/decrease the effect of echo 5. -
Page 3: Rear Panel
Rear panel: 1. Power-source cable: plug in 110V/220V power source 2. Optical audio port: To connect to optical audio input of digital amplifier. Only have effect on DVD, VCD…not have effect on MIDI Karaoke disc 3. Coaxial audio port: Use to connect to coaxial audio input of digital amplifier. Only have effect on DVD, VCD…not have effect on MIDI Karaoke disc 4. -
Page 4: Remote Control
REMOTE CONTROL 1. POWER: on/off power 2. Keys of numbers: input the code of the song 3. RESV/PBC (VCD 2.0):... - Page 5 + MIDI: Input the code and press RESV to reserve the song (approximately 20 songs) + VCD: PBC ON/OFF (only have effect on VCD 2.0) 4. STOP: stop the program being played 5. VOL +/-: increase/decrease the volume of device 6.
- Page 6 + DVD: enter to main menu in DVD use + MIDI: Input the code and press this key to place the song in priority 26. MELODY/RETURN: + MIDI: On/off the song’s melody + Return to previous operation 27. BGV (BGV 1/BGV 2): select video mixing port from external signal source 28.
-
Page 7: Basic Connection
BASIC CONNECTION Connect to TV Video port (yellow) Audio port (red and white) Scoring port connected to MIC OUT of Amplifier Component video cable Subwoofer Speaker Connect to 5.1ch Amplifier Rear speaker (right) Rear speaker (left) - Connect to digital Amplifier Dolby Digital (Digital Theater... -
Page 8: Use The Remote Control
USE THE REMOTE CONTROL 1. Install the battery: Check for installing in right polarity +/- 2. Battery life: + Battery life depends on more or less use + If the remote control does not work or work s in very close area with the device, the user should replace the battery + Use AA battery 3. - Page 9 * Play CD disc: The user will recognize CD disc through logo. * MIDI Karaoke disc: MIDI disc contains a great amount of songs including: Vietnamese, English, Chinese…MIDI Karaoke disc for model AR-3600Hi has chorus, vocal, lyric and function to adjust fast/slow tempo that is very convenient for new singer * Note: The device only reads MIDI disc released by MASECO Company.
- Page 10 3. To Previous/Next Track/Chapter: When title of DVD disk has a lot of Chapters or VCD disk has a lot of Tracks, move to other Chapters or Tracks by the following way: + Press to move to next Chapter/Track + Press to move to previous Chapter/Track + For VCD/CD disk, when in stop mode, select Track by number keys to play.
- Page 11 9. Randomly play (VCD/CD/MP3): + Press “SHUFFLE” key to play disc in random mode (VCD2.0 must open PBC OFF) 10. Key of function list (Menu DVD): only have effect if supported Menu function by disc + Press MENU key to select the function list + Press key to select item + Press “ENTER”...
- Page 12 6. Popular song: + Press POPULAR key to select the song in list of popular songs installed previously (approximately 300 songs) + Press key to select the song + Press PLAY/ENTER to play + Press STOP to exit 7. Favorite song: + Press FAVORITE key + Press key to select the song, then press PLAY/ENTER key to play...
- Page 13 14. VOL key: Press VOL +/- key to adjust the volume 15. MUTE key: Use to turn on/off the volume (Mute on/off) CHOOSE THE SONG DIRECTLY BY REMOTE CONTROL + Press SONG_LIST key, the device will display a page about the song information + Press COUNTRY key to change the song list of each country (Vietnamese, English, Chinese…) + Press TIT/SIN/WRI to change TIT (title)/SIN (singer)/ WRI (writor) + Press...
- Page 14 + Sx1/Sx2: font size * Note: reserve before exiting - For example: to install the greeting with the text “MASECO ARIRANG”, press SETUP key Code: ”0000” Press Down key select GREETING press ENTER Press Up/Down/Left/Right key to select M A S E C O move to “SPACE”...
-
Page 15: Installation
INSTALLATION Press SETUP when the device has no disc inside or is playing (DVD/VCD/CD/MP3), use key press ENTER to select items in the installation Press SETUP again or select EXIT to exit the installation 1. General setup: PIC MODE: set picture mode + AUTO: set automatic mode + FILM: high scanning mode + VIDEO: set high resolution mode... - Page 16 CAPTION: caption of audio effect (the wind, footstep…), must be supported by DVD SCREEN SAVER: set the screen saver, only perform when the device is on STOP/PAUSE mode MAIN PAGE: return to the main setting screen 2. Speaker setup: DOWNMIX: this function changes the audio mixing method at output to suitable for Amplifier or + LT/RT: select left/right 2-channel output + STEREO: select separate 2- channel output + OFF: 5.1CH feature is opened...
- Page 17 SPDIF OUTPUT: select audio output suitable with Amplifier + OFF: use normal AV cable to connect with Amplifier Stereo + SPDIF/RAW: connect to digital Amplifier through Coaxial/Optical port + SPDIF/PCM: connect to Amplifier Stereo having support of Coaxial port + OP MODE: have two modes to select LINE OUT/RF REMOD DUAL MONO: change mode of output audio + STEREO: separate 2- channel output + L-MONO: select left-channel output...
- Page 18 TV DISPLAY: select mode of screen display suitable with TV + NORMAL/PS: display in normal mode 4:3PS, lost picture when displaying in 16:9 mode + NORMAL/LB: display in normal mode 4:3LB but not lost picture when displaying in 16:9 mode + WIDE: only display in 16:9 mode TV TYPE: set color system + MULTI: automatically select color system suitable with TV...
-
Page 19: Troubleshooting
TROUBLESHOOTING Technical problems Repair No source of supply Check the power-source cable Not read disc when press PLAY The device cannot read disks that are not in DVD, Press PLAY but then stop immediately VCD or CD format Dirty disc No picture Check the disk placed in the device with right surface... -
Page 20: Specifications
SPECIFICATIONS Voltage: AC 90 – 240VAC 50/60Hz Power Consumption: 14W Weight: 3.0Kg Compatible with: DVD Midi Karaoke/DVD/DVD-R/SVCD/ VCD/CD-R/ CD-RW/Mp3/WMA/Mp4 & Jpeg Video 1VP-P (750) 1VP-P (750) S-Video 0.286 VP-P (750) Output 1VP-P (750) Component 0.7 VP-P (750) 0.7 VP-P (750) Audio L/R,5.1CH 2Vrms(max) Input...
