Support for disks
- MIDI-DVD,DVD,DVD-R,SVCD,VCD,CD,CD-R,CD-RW,MP3.
Karaoke support various functions
-
Function of presetting the song and helps to preset 20 songs.
- The list of new songs.
- Favorite songs.
- Language is displayed in Vietnamese and English.
- Reserve the song and clear the reserved song as preference
- Adjust the key and tempo appropriate with each voice.
- Increase/decrease the song's melody as desired.
- Install greetings/lines on the screen in Vietnamese.
- Score and applause as preference.
Qualitative picture, transparent and clear sound
- Decoding technique MPEG1, MPEG2 and MPEG3, DIVX(Code3.11-5.0).
* Note: not support absolutely 100% for DIVX formats.
- High quality sound with digital effect.
- High quality video background (MPEG2).
Other special features:
- Can use picture from other signal source as background picture in Midi Karaoke play.
- Unique VOCAL/CHORUS technique with the lively effect of vocal/chorus
-
Play picture and audio data of all formats MP3,WMA,WAV...
USER'S MANUAL
AR-3600S
SPECIAL FEATURES
-
DVD disc can play up to 135', including 8 languages and 32 different
captions
- MPEG-2 helps compress picture with high quality sound; creates the great,
lively audio and picture as in the theaters.
Advertisement
Table of Contents
Related Manuals for Arirang AR-3600S
Summary of Contents for Arirang AR-3600S
- Page 1 USER’S MANUAL AR-3600S SPECIAL FEATURES Support for disks - MIDI-DVD,DVD,DVD-R,SVCD,VCD,CD,CD-R,CD-RW,MP3. Karaoke support various functions Function of presetting the song and helps to preset 20 songs. - The list of new songs. - Favorite songs. - Language is displayed in Vietnamese and English.
-
Page 2: Name Of Each Part
NAME OF EACH PART Front panel 1. POWER key: Turn on/off power 2. LIST key: Display the song list 3. COU key: Select song list as per the language 4. T/S key: Select a song as per its title or author’s name 5. - Page 3 Rear panel: 1. Scoring port: Connect to Mic Out output of amplifier to score 2. 5.1 channel audio port: Connect to 5.1 audio input of Amplifier 3. Picture mixing port: use picture of other equipments as background picture for device in MIDI play 4.
-
Page 4: Remote Control
REMOTE CONTROL 1. POWER: on/off power 2. Keys of numbers: input the code of the song 3. RESV/PBC (VCD 2.0): + MIDI: Input the code and press RESV to reserve the song (approximately 20 songs) + VCD: PBC ON/OFF (only have effect on VCD 2.0) 4. - Page 5 6. SLOW/TIT/SIN/WRI: + MIDI: select Title/Singer/Writer in SONG_LIST + DVD/VCD: slowly play picture following the speed x2/x4/x6 7. ZOOM/COUNTRY: + MIDI: Select the song in English, Chinese, Vietnamese…while searching for a song (SONG_LIST) + DVD/VCD: zoom in pictures being played x1.5/x2/x3 8.
- Page 6 25. MENU/1 ST_RESERVE: + DVD: enter to main menu in DVD use + MIDI: Input the code and press this key to place the song in priority 26. MELODY/RETURN: + MIDI: On/off the song’s melody + Return to previous operation 27.
-
Page 7: Basic Connection
BASIC CONNECTION Connect to TV Video port (yellow) Audio port (red and white) Scoring port connected to Component video cable MIC OUT of Amplifier Subwoofer Speaker Connect to 5.1ch Amplifier Rear speaker (left) Rear speaker (right) - Connect to digital Amplifier Dolby Digital or DTS (Digital Theater System). - Page 8 1. Install the battery: Check for installing in right polarity +/- 2. Battery life: + Battery life depends on more or less use + If the remote control does not work or work s in very close area with the device, the user should replace the battery + Use AA battery 3.
- Page 9 * Play CD disc: The user will recognize CD disc through logo. * MIDI Karaoke disc: MIDI disc contains a great amount of songs including: Vietnamese, English, Chinese…MIDI Karaoke disc for model AR-3600S has chorus, vocal, lyric and function to adjust fast/slow tempo that is very convenient for new singer * Note: The device only reads MIDI disc released by MASECO Company.
- Page 10 + For VCD/CD disk, when in stop mode, select Track by number keys to play. For VCD2.0, select PBC OFF feature to choose the song. 4. Fast Forward/Rewind – Record the song – Display the list of song - DVD: + When the device is playing, press to fast Forward/Rewind with 5 levels x2/x4/x8/x16, each level corresponding with each key press + To return to play mode, press PLAY key...
- Page 11 10. Key of function list (Menu DVD): only have effect if supported Menu function by disc + Press MENU key to select the function list + Press key to select item + Press “ENTER” or “PLAY” to select + Press “MENU” key to return to main Menu BASIC OPERATION IN USING MIDI KARAOKE DISC 1.
- Page 12 + Press key to select the song + Press PLAY/ENTER to play + Press STOP to exit 7. Favorite song: + Press FAVORITE key + Press key to select the song, then press PLAY/ENTER key to play + Press STOP key to exit 8.
- Page 13 14. VOL key: Press VOL +/- key to adjust the volume 15. MUTE key: Use to turn on/off the volume (Mute on/off) CHOOSE THE SONG DIRECTLY BY REMOTE CONTROL + Press SONG_LIST key, the device will display a page about the song information + Press GO TO to change between USB device and DVD drive + Press COUNTRY key to change the song list of each country (Vietnamese, English, Chinese…) + Press TIT/SIN/WRI to change TIT (title)/SIN (singer)/ WRI (writer)
-
Page 14: Installation
+ EXIT: exit the application + Sx1/Sx2: font size * Note: reserve before exiting - For example: to install the greeting with the text “MASECO ARIRANG” Press SETUP key Code: ”0000” Press Down key select GREETINGPress ENTER Press Up/Down/Left/Right key to select M A S EC O move to “SPACE” Press ENTER to create a space between two words... - Page 15 1. General setup: - PIC MODE: set picture mode + AUTO: set automatic mode + FILM: high scanning mode + VIDEO: set high resolution mode + SMART: set high resolution and scanning mode + SUPER SMART: set high resolution and scanning mode - ANGLE MARK: view angle (DVD), can view picture from different angles if supported by disc, press ANGLE many times to view each picture angle - OSD LANG: select displayed language ENGLISH/VIETNAMESE (not supported Vietnamese)
- Page 16 - DOWNMIX: this function changes the audio mixing method at output to suitable for Amplifier or TV + LT/RT: select left/right 2-channel output + STEREO: select separate 2- channel output + OFF: 5.1CH feature is opened - CENTER: center speaker - REAR: rear speaker - SUBWOOFER: subwoofer speaker - CENTER DELAY: helps adjust the delay of center speaker...
- Page 17 + OP MODE: have two modes to select LINE OUT/RF REMOD - DUAL MONO: change mode of output audio + STEREO: separate 2- channel output + L-MONO: select left-channel output + R-MONO: select right-channel output + MIX-MONO: Mix audio of left/right 2-channel - COMPRESSION: effect of audio compression, only support for DVD with 5.1CH - PRO LOGIC: create virtual sound effect (DVD) - LPCM OUTPUT: select sampling frequency 48K/96K...
- Page 18 + NORMAL/LB: display in normal mode 4:3LB but not lost picture when displaying in 16:9 mode + WIDE: only display in 16:9 mode - TV TYPE: set color system + MULTI: automatically select color system suitable with TV + NTSC: NTSC color system + PAL: PAL color system - VIDEO OUTPUT: VIDEO output + S-VIDEO: S-Video video output...
-
Page 19: Troubleshooting
TROUBLESHOOTING Technical problems Repair No source of supply Check the power-source cable Not read disc when press PLAY The device cannot read disks that are not in DVD, Press PLAY but then stop immediately VCD or CD format Dirty disc No picture Check the disk placed in the device with right surface...
