- Page 1 Owner's manual AA-8.0 TFE Manual size : 150 x 210mm...
-
Page 2: Installation
Installation In case you install the amplifiers by yourself, please read owners' manual very carefully. Before you start your installation, please take all steps into consideration. If in doubt, please contact with authorized distributors / dealers to check installation and turn in your car audio systems. -
Page 3: Panel Layout
Panel Layout BASS BASS PHASE REMOTE GAIN SONIC BOOST FREQ. SHIFT SPEAKER OUTPUTS 0.2V 10Hz 70Hz 12dB 30Hz 90Hz 30Hz 250Hz SLAVE MASTER SLAVE INPUT OUTPUT MASTER OUTPUT INPUT DAISY-CHAIN SPEAKER OUTPUTS 1) INPUT Connect preamp signal cables from head unit to RCA input of the amplifiers. A minimum level input of 0.2V is essential for correct operation. - Page 4 +12V (B+), GND, REM +12V +12V +12V POWER POWER POWER INPUT-B INPUT-A INPUT-C PT LINK GND (GROUND CONNECTION) For connection to the chassis’ ground. For optimum performance 0 gauge cable is recommended. REM (REMOTE) Connect to switched +12V from the head unit. +12V / B+ (POWER CONNECTION) For connection to the positive terminal of the battery (+12).
-
Page 5: Single Connection
+12V ), GND, REM Connection SINGLE CONNECTION GROUND +12V +12V +12V POWER POWER POWER INPUT-B INPUT-A INPUT-C PT LINK BATTERY Remote turn on HEAD UNIT GROUND Recommend fuse rating (See the page 8) DAISY CHAIN (LINKED) CONNECTION +12V +12V +12V POWER POWER POWER... -
Page 6: Speaker Connection
Speaker connection SINGLE CONNECTION BASS BASS PHASE REMOTE SONIC BOOST FREQ. SHIFT GAIN SPEAKER OUTPUTS 0.2V 10Hz 70Hz 12dB 30Hz 90Hz 30Hz 250Hz SLAVE MASTER SLAVE INPUT OUTPUT MASTER OUTPUT INPUT DAISY-CHAIN SPEAKER OUTPUTS Speaker Impedance 1~8 ohms HEAD UNIT DAISY CHAIN (LINKED) CONNECTION MASTER AMPLIFIER... -
Page 7: Troubleshooting
Troubleshooting Assure that the Power LED is on, if so please proceed with step # 3, if not, continue with the steps below; 1. Check the in line fuse (s) on the battery’s positive cable, replace if needed. 2. Assure that the Ground is properly attached to the vehichle’s chassis on a clean metal point, tighten or grind the connection point once again. -
Page 8: Specifications
Specifications MODEL CODE AA-8.0 TFE Continuous power output -Power 12.4 VDC - 1 ohm : 8,000W RMS -Power 12.4 VDC - 2 ohms 4,000W RMS -Power 12.4 VDC - 4 ohms 2,000W RMS -Strapped Power 12.4 VDC - 2 ohms...
