- Page 1 12IN. DISC SANDER OWNER’S MANUAL WARNING: Read carefully and understand RULES FOR SAFE OPERATION and instructions before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #46464...
-
Page 2: Intended Use
Thank you very much for choosing an Ironton product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. -
Page 3: Important Safety Considerations
SAVE THESE INSTRUCTIONS IMPORTANT SAFETY CONSIDERATIONS DISC SANDER USE AND CARE • Do not modify the Disc Sander in any way. Unauthorized modification may impair the function and/or safety and could affect the life of the equipment. There are specific applications for which the Disc Sander was designed. -
Page 4: Work Area
• Do not force the Sander. This tool will do the work better and safer at the speed and capacity for which it was designed. • Always unplug the Sander from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. •... -
Page 5: Grounding Instructions
Personal Safety • Stay alert. Watch what you are doing, and use common sense when operating a power tool. Do not use a power tool while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury. -
Page 6: Guidelines For Extension Cords
Refer to the illustration: WARNING: Improper connection of equipment grounding conductor can result in the risk of electrical shock. Equipment should be grounded while in use to protect operator from electrical shock. -Check with a qualified electrician if you do not understand grounding instructions or if you are in doubt as to whether the tool is properly grounded. -
Page 7: Operation
1. Table 2. Screw 1/4”*5/8” 3. Washer 4. Screw 1/4”*1/2” OPERATION Basic Controls Refer to figure on the right and the following descriptions to become familiar with the basic controls of this machine. ON/OFF Switch. Turns the motor ON when flipped up; turns motor OFF when pressed down. -
Page 8: Inspection, Maintenance, And Cleaning
5. With light, but firm pressure, push the workpiece into the down-spin side of the rotating disc. See Figures A–C for examples of disc sanding. Figure A. 90˚ disc sanding. Figure B. Miter sanding. Figure C. Sanding with table angled. INSPECTION, MAINTENANCE, AND CLEANING WARNING! Make sure the Power Switch of the Belt Sander is in its “OFF”... - Page 9 DIAGRAM...
-
Page 10: Parts List
PARTS LIST Description Description 1-2N M5x8mm Pan head screw 4mm Lock washer 4-2N Base cover M4 x 8mm Pan head screw Disc, Sanding Junction box lower cover M6x16mm Flat cap head screw 5mm Serrated washer Hold-down plate 5mm Lock washer Disc, Aluminum M5 x 6mm Pan head screw 5-0.8 x 25mm Hex bolt... -
Page 11: Warranty
WARRANTY One-year limited warranty. For warranty questions, call 1-800-222-5381 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: •...
