14. Orient the Storage Latch (96) so that the decals
are facing away from the treadmill as shown.
Attach the lower end of the Storage Latch (96) to
the bracket on the Base (85) with a 5/16" x 1 3/4"
Bolt (94), two Latch Spacers (98), and a 5/16"
Nut (34) as shown.
Raise the Storage Latch (96) to a vertical posi-
tion. If a tie and a spacer (C) are in the top of the
latch, remove and discard them.
15. Attach the upper end of the Storage Latch (96)
to the bracket on the Latch Crossbar (97) with a
5/16" x 2 1/4" Shoulder Bolt (95) and a 5/16"
Nut (34).
Lower the Frame (56) (see HOW TO LOWER
THE TREADMILL FOR USE on page 22).
14
Tie
Decals
34
98
15
34
56
14
C
96
94
85
97
95
96
