  • Page 1 DIRIS Multifunction meters - MFM Multi-measurement meter - dimensions 72 x 72 mm Operating instructions...
  • Page 2: Table Of Contents

    ..........29 DIRIS A17 - Ref.: 541 984 A...
  • Page 3: Documentation

    DIRIS A17 1. Documentation All DIRIS A17 documentations are available on the website at the following address: www.socomec.com/en/documentation-diris-a17 2. Danger and warning This equipment must be mounted only by professionals. The manufacturer shall not be held responsible for failure to comply with the instructions in this manual.
  • Page 4: Presentation

    4. Presentation The DIRIS A17 is a 72x72 mm compact multifunction meter for measuring electrical network parameters. The DIRIS provides measurements of voltage, current, power and energy. With display and push buttons, users can easily access to all product functionalities. It includes an input and an output, and depending on the reference, it can includes a communication bus as well as the measurement of the harmonic distorsion rate.
  • Page 5: Installation

    TRHMF NMD NE 2NBNLDB R B@S@KNFTD OQNCTBSR SGD /3( QDE   0521). Please contact us for further information. 2.5 mm² (AWG14) 0.29 in / 7.5 mm Flat 3 4.42 lb-in / 0,5 Nm 1.5 mm² (AWG16) 0.31 in / 8 mm Flat 2 2.12 lb-in / 0,25 Nm DIRIS A17 - Ref.: 541 984 A...
  • Page 6: Connections

    S2 S1 S2 S1 S2 V1 V2 V3 VN L1 ( R ) L1 ( R ) L2 ( S ) L2 ( S ) L3 ( T ) L3 ( T ) DIRIS A17 - Ref.: 541 984 A...
  • Page 7: Communication Modbus

    6.1. General Information ® communication bus is available on DIRIS A17 QDE   DS   The MODBUS It is achieved via an RS485 serial link (2 or 3 wires) for using products from a PC or an API.
  • Page 8: Register Table

    According to the MODBUS protocol, transmission time must be less than 3 silences, i.e. the emission time of 3 characters so that the message is processed by the DIRIS A17. To use this information correctly, it is necessary to use the MODBUS ®...
  • Page 9: Programming

    DIRIS A17 7. Programming /QNFQ@LLHMF B@M AD @BGHDUDC EQNL SGD $@RX "NMjF BNMjFTQ@SHNM RNESV@QD NQ CHQDBSKX EQNL SGD DIRIS A17 display. Refer to following paragraphs for programming from the display. 7.1. Navigation principle The programming mode allows to modify parameters such as network type, integration time, input/output, alarms or communication parameters.
  • Page 10: Access To Programming Mode

    TRDQ jMHRGDR SGD RDRRHNM AX OQDRRHMF /1.& ATSSNM ENQ  RDBNMCR Attention: For a timeout of 60 seconds without activity on the pushbuttons the device leaves the programming mode without saving possible changes. DIRIS A17 - Ref.: 541 984 A...
  • Page 11: Example: Network Selection

    In programming mode (see page 10), go to screen "Network type - nEt" In this example, network change from 4NBL to 3NBL : x 1 (3BL) x 2 (3NBL) x 3 (4BL) x 4 (4 NBL) confirm DIRIS A17 - Ref.: 541 984 A...
  • Page 12: Example: Choice Of Current Transformer

    7.4. Example: choice of current transformer In programming mode (see page 10), access to screen "Current transformer - Ct" Example: ratio change to 500/1. confirm confirm DIRIS A17 - Ref.: 541 984 A...
  • Page 13: Programming Mode Overview

    Alarm Energy K@QL 'HFG +NV Pulse output @MC 'XRSDQDRHR energy value Threshold Pulse output Alarm delay duration value Output (OUT) activation in case of alarm Communication Backlit Program password Serial number Software version DIRIS A17 - Ref.: 541 984 A...
  • Page 14: Detailed View Of The Programming Menu

    Network type Voltage transformer 3BL, 3NBL, 4BL, b9 4NBL     5 Current transformer Voltage transformer 60, 100, 110, 115,     120, 173, b9 XX = default value DIRIS A17 - Ref.: 541 984 A...
  • Page 15 Yes, No No, puls, cd Power max reset Output type (OUT) Ea: active energy Er: reactive energy Alarm: status change if alarm Yes, No ($, ER, Alarm XX = default value DIRIS A17 - Ref.: 541 984 A...
  • Page 16 3 : 100 kWh/kvarh 4 : 1000 kWh/kvarh 5 : 10000 kWh/ 0 -> 9999 kvarh Alarm hysteresis threshold Pulse output duration value 0% -> 99% 100 -> 900 msec XX = default value DIRIS A17 - Ref.: 541 984 A...
  • Page 17 Program password Baud Rate 1.2, 2.4, 4.8, 9.6, 19.2, 38.4 kbaud 0 -> 999 Communication Serial number Parity No, Even, Odd Communication Software version Stop bit 1, 2 3 sec XX = default value DIRIS A17 - Ref.: 541 984 A...
  • Page 18: Use

    ,@W OG@RD BTQQDMSR 3'# Export reactive energy MDTSQ@K UNKS@FDR 3'# and apparent power ______________ ______________ ______________ Pulse meter connected to 3'# MDTSQ@K BTQQDMS Total power factor the input ______________ Instantaneous power factor per phase DIRIS A17 - Ref.: 541 984 A...
  • Page 19: Detailed View Of The "Current" Menu

    DIRIS A17 8.1. Detailed view of the "Current" menu Instantaneous phase currents Max. phase currents THD Instantaneous neutral current THD neutral current Max. phase currents Max neutral current DIRIS A17 - Ref.: 541 984 A...
  • Page 20: Detailed View Of The "Voltage" Menu

    8.2. Detailed view of the "Voltage" menu Instantaneous phase-phase Instantaneous phase-neutral voltages voltages THD Instantaneous phase-neutral voltages Instantaneous frequency Instantaneous phase-phase voltages THD DIRIS A17 - Ref.: 541 984 A...
  • Page 21: Detailed View Of The "Power" Menu

    Maximum active, reactive and imported/exported reactive - apparent apparent power Instantaneous active power per Total power factor phase Instantaneous reactive power per Instantaneous power factor per phase phase Instantaneous apparent power per phase DIRIS A17 - Ref.: 541 984 A...
  • Page 22: Detailed View Of The "Energy" Menu

    8.4. Detailed view of the "Energy" menu Import active energy Export reactive energy Pulse meter connected to the Import reactive energy input Apparent energy Export active energy DIRIS A17 - Ref.: 541 984 A...
  • Page 23: Connection Test Function

    Press the TEST button for 3 seconds. The error indication is displayed on the screen. 3 sec Err 0 = no error 3 sec To quit Test mode and return to the screen displayed before the test. DIRIS A17 - Ref.: 541 984 A...
  • Page 24 To automatically change the TC current, change the value NO to YES. Err 0 = no error 3 sec To quit Test mode and return to the screen displayed before the test. DIRIS A17 - Ref.: 541 984 A...
  • Page 25 To start the second test, change the value to YES Err 0 = no error 3 sec To quit Test mode and return to the screen displayed before the test. DIRIS A17 - Ref.: 541 984 A...
  • Page 26: Assistance

    Powers and power-factor (PF) Use the test connection function (see page 23) Phases missing on Display "GDBJ SGD MDSVNQJ BNMjFTQ@SHNM RDD O@FD  I/O are not operating Check power supply 8 - 30VDC DIRIS A17 - Ref.: 541 984 A...
  • Page 27: Electrical And Technical Characteristics

    Type of optocoupler IEC 62053-31 Class A (5 ... 30 VDC) Pulse weight  6G  J6G  J6G  J6G  J6G  J6G Pulse length  LR  LR  LR  LR DIRIS A17 - Ref.: 541 984 A...
  • Page 28: According To Iec 61557-12

    8GLS 8VZO 8WU 8LQW 8QED 8QE +]  UDQNV  WR  7+'X +]  UDQNV  WR  7+'5X +]  UDQNV  WR  7+'L +]  UDQNV  WR  7+'5L DIRIS A17 - Ref.: 541 984 A...
  • Page 29: Glossary Of Abbreviations

    7+' 9 9 9 3KDVHWRQHXWUDO YROWDJH KDUPRQLF GLVWRUWLRQ UDWH &20 &RPPXQLFDWLRQ 6ODYH DGGUHVV &RPPXQLFDWLRQ VSHHG EDXG &RPPXQLFDWLRQ IUDPH SDULW\ :LWKRXW SDULW\ (YHQ (YHQ SDULW\ 2GG SDULW\ 6723 )UDPHVWRS EHHS  VWRS ELW  VWRS ELWV DIRIS A17 - Ref.: 541 984 A...
  • Page 30 Fax +48 91 442 64 19 info.scp.pl@socomec.com HEAD OFFICE YOUR DISTRIBUTOR SOCOMEC GROUP S.A. SOCOMEC capital 10 816 800€ R.C.S. Strasbourg B 548 500 149 B.P. 60010 - 1, rue de Westhouse F-67235 Benfeld Cedex - FRANCE Tel. +33 3 88 57 41 41 Fax +33 3 88 74 08 00 info.scp.isd@socomec.com...
