Cheetah 4LP FC Product Manual, Rev. A
6.6
Mechanical specifications
The following nominal dimensions are exclusive of the decorative front panel accessory. Refer to Figure 4 for
detailed mounting configuration dimensions for the drive. Refer to Figure 12 for detailed FC-AL SCA connector
dimensions. A minimum clearance of 0.050 in. (1.27 mm) must be maintained from the PWA side of the drive.
Height
1.00 in
Width
4.00 in
Depth
5.75 in
Weight
1.3 lb
R
Figure 4.
Mounting configuration dimensions
25.4 mm
101.6 mm
146.05 mm
0.588 kilograms
N
P
[1]
A
F
D
G
E
B
[5]
[2]
K
J
H
[4]
S
[3]
C
M
.01
L
Notes:
[1]
Mounting holes three on each side, 6-32 UNC.
Max screw length into side of drive 0.15 in.
(3.81 mm). Screw tightening torque 6.0 in-lb
(.675 NM) max with minimum thread
engagement of 0.12 in. (3.05 mm).
[2]
Mounting holes four on bottom, 6-32 UNC.
Max screw length into bottom of drive 0.15 in.
(3.81 mm). Screw tightening torque 6.0 in-lb
(.675 NM) max with minimum thread
engagement of 0.12 in. (3.05 mm).
[3]
Power and interface connectors can extend
past the "A" dimension by 0.040 in. (1.02 mm).
[4]
Decorative front panel.
Connector is centered on module ±0.020 in.
[5]
(.508 mm).
Inches
Millimeters
±
A
5.750
0.010
146.05
±
B
4.000
0.010
101.60
C
1.000
+
0.026
25.40
–
0.010
±
D
0.625
0.020
15.87
±
E
4.000
0.005
101.60
±
F
0.250
0.005
±
G
2.375
0.010
60.32
±
H
3.750
0.010
95.25
±
J
2.370
0.010
60.20
±
K
1.750
0.020
44.45
±
L
0.181
0.015
±
M
0.275
0.015
±
N
0.190
0.010
P
0.015
max
0.381
±
R
1.100
0.010
27.94
±
S
4.100
0.010
104.14
±
.25
±
.25
±
.38
±
.50
±
.13
±
6.35
.13
±
.25
±
.25
±
.25
±
.50
±
4.32
.38
±
7.00
.38
±
4.83
.25
max
±
.25
±
.25
21
