USER'S MANUAL

CHALLENGER X

RECREATIONAL ELECTRIC SCOOTER

MODEL: J750

Please read this manual completely before riding your scooter

www.challengermobility.com

Table of Contents

Summary of Contents for Challenger X J750

Page 1 USER’S MANUAL CHALLENGER X RECREATIONAL ELECTRIC SCOOTER MODEL: J750 Please read this manual completely before riding your scooter www.challengermobility.com...
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ………………………………………………………………………………4 SAFETY NOTICES ………………………………………………………………………..5 SCOOTER COMPONENTS OVERVIEW ………………………………………………… 8 HANDLEBAR DISPLAY …………………………………………………………………….9 CHARGING THE BATTERIES …………………………………………………………..10 ASSEMBLY INSTRUCTIONS ……………………………………………………………11 RIDING INSTRUCTIONS ………………………………………………………………..15 CARE & MAINTENANCE …………………………………………………………………16 BASIC TROUBLESHOOTING …………………………………………………………..17 TECHNICAL SPECIFICATIONS ……………………………………………………….18 LIMITED WARRANTY …………………………………………………………………...19 PRODUCT REGISTRATION ……………………………………………………………..21...
Page 4: Introduction
The Challenger X also includes multiple features that increase overall functionality, yet simple to manage. In order to get the most of your Challenger X, please read and follow all instructions, warnings, and notes in this owner’s manual and all other accompanying literature before using it for the first time.
Page 5: Safety Notices
Safety Notices Read the Owner’s Manual Do not operate your Challenger X Scooter for the first time without completely reading and understanding this owner’s manual. The user should be familiar with the operation of this scooter, and keep the safety notices in mind.
Page 6 Do not use a mobile phone or other wireless communication device while driving. Also, do not charge a mobile phone or other electrical devices from your scooter. Do not stretch your body out on the scooter Such action may cause you to lose your balance or be injured. Also, pay attention to loose clothing that could get tangled in the wheels.
Page 7 WARNINGS:  Always keep your feet on the scooter platform when moving.  Never carry or wear anything which obstructs your vision, or would interfere with the proper scooter operations.  Never ride your scooter while under the influence of alcohol or other drugs. ...
Page 8: Scooter Components Overview
Scooter Components Overview 1.Hand Brakes 2.Front Basket 3.Front Motor-Wheel 4.LED Headlight 5.Standard Seat 6.Removable Floor Mat 7.Rear Wheel 8.Charging Port...
Page 9: Handlebar Display
Handlebar Display 1.Speed Limit Switch 2.Power Light 3.Headlight Indicator 4.Power gage 5.Forward/Reverse Button 6.Horn Switch 7.Key Switch/Light Switch 8.Throttle Knob...
Page 10: Charging The Batteries
Charging the Batteries Before you ride the mobility scooter for the first time you must charge the batteries for 6—8 hours using the supplied charger. To charge the batteries, plug the charger into the charger port of scooter at the lower left, then plug the charger into a wall outlet.
Page 11: Assembly Instructions
Assembly Instructions The packaging will contain the assembled scooter frame, elbow tube, tiller and handlebar, charger, tool bag, front basket, helmet, standard seat and seat post assembly. Step 1: Insert the elbow tube into the groove of scooter chassis, and screw tightly with the attached screws.
Page 12 Step 2: Put the scooter tiller into the tube. Make sure the position is proper. Tighten the top screw with spanner, and fasten lock buckle. Step 3: You can also use this method to change the height. It is worthwhile to lock buckle tightly，or it is dangerous...
Page 13 Step 4: Adjust the position between the scooter and the basket，Screw two screws tightly. Be sure to attach the gold washer plate to prevent the basket bolts from going through the basket. Step 5: The standpipe should be inserted into the hole of scooter chassis, and the seat of the left picture should be inserted into the standpipe.
Page 15: Riding Instructions
Riding Instructions It is important that you understand how to operate the scooter, so carefully follow these steps： 1. Check the power gauge indicator on the front tiller panel. Make sure it is on green to get the most travel distance. 2.
Page 16: Care & Maintenance
Care & Maintenance Check your scooter before riding and make sure it is fully charged. If you find anything abnormal, go to or call your scooter dealer for further inspection before using it. TIRES The condition of the tires depends on how you drive and use your scooter. Please check the tread depth regularly.
Page 17: Basic Troubleshooting
Basic Troubleshooting Below tips is how to deal with the technical situations that you may encounter: problem cause solution The key is turned to The amperage may Fully charge the batteries the ON position, but be too low to drive there is no drive.
Page 18: Technical Specifications
Technical Specifications Model: J750 Dimensions assembled: 50” (L) x 32” (W) x 48” (H) Dimensions folded: 50” (L) x 32” (W) x 31” (H) Ground clearance: 3” Total Weight with battery and seat: 126 lbs. Maximum load Capacity: 300 lbs.
Page 19: Limited Warranty
Limited Warranty THREE-YEAR LIMITED WARRANTY Three (3) years from the date of purchase on all structural frame components; including platform, seat post, and frame. ONE-YEAR LIMITED WARRANTY One (1) year from the date of purchase, if any part or electronic component of the Scooter is found upon examination to be defective in material and or workmanship, it will be repaired or replaced, at Challenger Mobility option, without charge.
Page 20 WARRANTY EXCLUSIONS: This warranty is only given to the original purchaser of the Scooter. This Warranty excludes:  Consumable items which may need replacing due to normal wear and tear (tires, tubes, belts, bulbs, upholstery and seating, throttle, brakes, fuses, plastic shrouds and footrest covers, etc.) ...
Page 21: Product Registration
Product Registration CHALLENGER X RECREATIONAL ELECTRIC SCOOTER J750 MODEL Scooter Serial Number Date Purchased Owner’s Name Address Street: City: State: ZIP: Phone: E-mail Address: Dealer’s Name Dealer’s Phone Comments Mailing address 16609 US HIGHWAY 19 - Hudson, FL 34667 Fax Number (727) 597-8454 Toll Free Number 1-888-364-3813 www.challengermobility.com...
