Robin Safir Murale 900 Operating Instructions Manual

Robin safir murale 900 canopy hood operating instructions
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Dir. 8 9 / 3 3 6 / CEE
73/ 23/ CEE
Safir Murale 900
Istruzioni per l'uso
Operating instructions
Mode d'emploi
Bedienungsanleitung
Gebruiksaanwijzing
Manual de instrucciones
Manual de instruções
4 3 2 9 0 6 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Safir Murale 900 and is the answer not in the manual?

Questions and answers

Summary of Contents for Robin Safir Murale 900

  • Page 1 Dir. 8 9 / 3 3 6 / CEE 73/ 23/ CEE Safir Murale 900 Istruzioni per l'uso Operating instructions Mode d'emploi Bedienungsanleitung Gebruiksaanwijzing Manual de instrucciones Manual de instruções 4 3 2 9 0 6 6...
  • Page 2: Installation

    1 - Air outlet turned upwards (extraction or recirculation mode). Part 1ª - INSTALLATION INSTRUCTIONS 2 - Air outlet turned towards the wall (extraction mode only). 3 - Air outlet turned to the right or left (extraction mode only). In this case the air must be ducted to the outside. 1 - GENERAL INFORMATION To install the hood properly, follow the procedures indicated below: This canopy hood is designed to be fixed to any rigid vertical surface, above a gas or electric...
  • Page 3: Safety Warnings

    to fix the hood canopy C. The holes used to fix the chimney must be drilled at a distance 4.4 - Ducting or recirculation fitting X from the central axis of holes 1, which is found by measuring the extension of the 1 - Ducting fitting chimney required for installation Z plus 15 mm (fig.
  • Page 4: Operation

    2 - OPERATION 1ère Partie - INSTRUCTIONS POUR L’INSTALLATION Control panel The control panel houses the following controls (fig. 21): SWITCH L = controls worktop illumination. 1 - GENERALITES SWITCH V1 = sets the motor to low speed, to be used to give a continuous light flow of Cette hotte est destinée à...
  • Page 5 3 - Sortie de l’air tournée vers la droite ou la gauche (uniquement dans l’installation aspirante). les centres marqués et introduire les tasseaux fournis. b - Fixer à fond dans les trous 1 les vis avec bague fournies dans les accessoires. Pour installer correctement la hotte, il faut suivre le schéma suivant: 4.1 - Choix du type d’installation c - Fixer l’étrier S dans la partie supérieure de la cheminée (fig.
  • Page 6: Entretien

    e - Serrer définitivement les vis pour fixer le corps de hotte C à la cheminée A. 2 - UTILISATION Tableau des commandes 4.4 - Connexion aspirante et filtrante Le schéma de commandes est le suivant (fig. 21): 1 - Connexion aspirante Elle peut être faite pour tous les types d’installation: TOUCHE 1 = Allume et éteint le circuit d’éclairage.
