Summary of Contents for GefenTV GTV-HDMI1.3-144
- Page 1 1:4 Gefen TV Splitter GTV-HDMI1.3-144 User Manual www.gefentv.com...
- Page 2 Write To: Gefen Inc. c/o Customer Service 20600 Nordhoff St Chatsworth, CA 91311 www.gefentv.com support@gefen.com Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction / Operation Notes Features / HDMI 1.3 Features / Package Includes Panel Descriptions Connecting and Operating the 1:4 Gefen TV Splitter / EDID Button / Reset Button Wiring Diagram Specifi cations Warranty... -
Page 4: Introduction / Operation Notes
INTRODUCTION Congratulations on your purchase of the 1:4 Gefen TV Splitter. Your complete satisfaction is very important to us. Gefen TV Gefen TV is a unique product line catering to the growing needs for innovative home theater solutions. We specialize in total integration for your home theater, while also focusing on going above and beyond customer expectations to en- sure you get the most from your hardware. -
Page 5: Features / Hdmi 1.3 Features / Package Includes
FEATURES Features • HDMI and HDCP compliant • Connects up to four HDMI™ / DVI displays at the same time to one video source • Maintains beautiful, sharp HDTV resolutions up to 1080p, 2k, and computer resolutions up to 1920 x 1200 are easily achieved •... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS Power Internal EDID Link Indicator LED Indicator Indicator IR Eye EDID and Reset HDMI Output 1* Output 2 Output 3 Output 4 Button* Input Power Supply Input *Please see page 4 for additional information... -
Page 7: Connecting And Operating The 1:4 Gefen Tv Splitter / Edid Button / Reset Button
CONNECTING AND OPERATING THE 1:4 GEFEN TV SPLITTER How to Connect the 1:4 Gefen TV Splitter Connect the HDMI source to the 1:4 Gefen TV Splitter using the supplied HDMI cable. Connect the displays (up to four) to the 1:4 Gefen TV Splitter using user supplied HDMI cables. -
Page 8: Wiring Diagram
WIRING DIAGRAM... -
Page 9: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ............... 225 MHz Input Video Signal ................1.2 Volts p-p Input DDC Signal ................. 5 Volts p-p (TTL) Single Link Range ........1080p/60 12 bit color depth, 1920x1200 HDMI Connector ..............Type A, 19 pin female Dimensions ...............
