- Page 1 1:4 Splitter for HDMI 1.3 GTV-HDMI1.3-144 User Manual www.gefentv.com...
- Page 2 Write To: Gefen, LLC. c/o Customer Service 20600 Nordhoff St Chatsworth, CA 91311 www.gefentv.com support@gefentv.com Notice Gefen, LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice.
-
Page 3: Table Of Contents
CONTENTS Introduction Operation Notes Features Panel Layout Panel Descriptions Connecting and Operating the GefenTV 1:4 Splitter for HDMI 1.3 Wiring Diagram EDID Management EDID Mode Selection External EDID Management Specifi cations Warranty... -
Page 4: Introduction
Please call us so we can better assist you with your particular needs. The GefenTV Splitter The GefenTV 1:4 Splitter for HDMI 1.3 allows a single HDMI device to be mir- rored to four HDMI displays. When two or more GefenTV HDMI 1:4 splitter units are connected together, they can be used to create a larger video signal distri- bution. -
Page 5: Operation Notes
OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE GEFENTV 1:4 SPLITTER FOR HDMI 1.3 • Display information (EDID) is sent from the display connected to HDMI output port 1 to the source. If there is no display connected to HDMI output port 1, the remaining HDMI output ports will be scanned in succession and use the fi... -
Page 6: Features
• Supports the use of DVI sources and DVI displays with an HDMI-to-DVI converter cable or adapter Package Includes: (1) GefenTV 1:4 Splitter for HDMI 1.3 (1) 6 ft. HDMI cable (M-M) (1) 5V DC Power Supply (1) User Manual... -
Page 7: Panel Layout
PANEL LAYOUT Front Panel Back Panel... -
Page 8: Panel Descriptions
PANEL DESCRIPTIONS IR Sensor Not used. Power Indicator This LED will turn bright red once the locking power supply has been properly connected. Internal EDID Indicator This LED turns bright blue when the Internal EDID is being used. TV Indicator This LED turns bright green when the External EDID is being used. -
Page 9: Connecting And Operating The Gefentv 1:4 Splitter For Hdmi
CONNECTING AND OPERATING THE GEFENTV 1:4 SPLITTER FOR HDMI 1.3 How to Connect the GefenTV 1:4 Switcher for HDMI 1.3 Use the provided HDMI cables to connect the source devices to the HDMI input port of the GefenTV 4:1 Switcher for HDMI 1.3. -
Page 10: Edid Management
To use this mode, press the EDID button on the rear panel until the front- panel LED marked “Int” turns bright blue. This mode will use a preset EDID, from the factory, that is stored in the GefenTV 1:3 Splitter for HDMI 1.3. This pre-programmed standard EDID data structure is compatible with most A/V display devices. -
Page 11: External Edid Management
EDID MANAGEMENT External EDID Management To use the External EDID mode, press the EDID button on the rear panel until the front-panel LED marked “TV” turns bright green. Display Connections • The information contained in the Internal EDID is used as the default EDID until a display is connected to the Splitter and the Splitter is power-cycled. -
Page 12: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ............... 225 MHz Input Video Signal ................1.2 Volts p-p Input DDC Signal ................. 5 Volts p-p (TTL) HDMI Input Connector ............Type A 19-pin female HDMI Output Connectors ..........(4) Type A 19-pin female Power Supply .................... - Page 14 Rev A1 2.3M 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefentv.com support@gefentv.com...
