- Page 1 REACH RoHS ELECTRIC OUTBOARD MOTOR X-SERIES Owner’s Manual Please read and retain this manual before using this electric motor...
-
Page 2: Table Of Contents
Motor TABLE OF CONTENTS GENERAL INFORMATION SPECIFICATIONS WIRING AND BATTERY RECOMMENDATIONS Battery Type Circuit Protection Cable Size SAFETY INFORMATION FIRST TIME RUNNING MOTOR USAGE Battery Connection Method (12 Volt only) Battery Connection Method (24 Volt only) How to Control the Motor Adjust the Angle of Handle TRANSOM MOUNT INSTALLATION HOW TO REPLACE THE PROPELLER... -
Page 3: General Information
There is a wide range of aqua-marina.nl outboard motors, from 32lbs through to 86lbs to suit every customer’s requirements and application. -
Page 4: Safety Information
Motor Be sure all switches are in the OFF position before connecting to battery or batteries. Electrical arcing near the battery could ignite hydrogen gas and cause the battery to explode. SAFETY INFORMATION Do not allow children to operate the electric outboard motor. Do not modify the unit in any way or add accessories not intended for this product. -
Page 5: Motor Usage
Motor MOTOR USAGE The motors package does not include batteries; please choose a battery with 12V (24V for 86LBS motor) output to fit this motor, the recommended type of battery is deep cycle battery or marine battery, as they will last much longer and designed for this application. Battery Connection Method (12 Volt only) Connection with one battery (12V DC) The red wire should connect to positive;... -
Page 6: How To Control The Motor
Motor How to Control the Motor Remember always disconnect from the battery(s) once the motor leaves water as a rotating propeller can cause personal injury. On/Off Speed Control Rotate handle clockwise to obtain any of the 5 forward speeds. Rotate handle anticlockwise for any of the 3 reverse speeds. -
Page 7: Adjust The Angle Of Handle
Adjust the Angle of Handle Tight adjust button aqua-marina.nl X series motor is able to adjust the angle of handle to make comfortable for user’s control. Please follow these steps to make adjustment. 1. Loose the button so that the handle can move upwards and downwards freely. -
Page 8: How To Replace The Propeller
Motor 1. Tilt Position Lever - This lever allows the user to adjust the tilt (angle) of the motor. Push tilt position lever, adjust tilt of motor, release lever. 2. Steering Tension Adjustment -To adjust the steering resistance, simply tighten or loosen the tension knob located on front of the mount. -
Page 9: Daily Maintainance
Motor Do not strike bent prop pin with hammer to remove pin. Damage to motor armature may occur that would not be covered by warranty. DAILY MAINTAINANCE 1. Check behind the propeller after each day for weeds, fishing line or other debris that may get wrapped behind the propeller. -
Page 10: Motor Makes Excessive Noise Or Vibration
Motor Motor Makes Excessive Noise or Vibration Propeller may be fouled. Propeller by be damaged or unbalanced. Check to see if propeller is secured. Bent armature. Remove propeller, set at medium speed, turn unit on and check for armature wobble. Turn propeller by hand. -
Page 11: Function Of The Circuit Breaker
Motor FUNCTION OF THE CIRCUIT BREAKER During the usage of the electric outboard motor, when the propeller is stuck by the weeds, small stones, fishing lines or so forth, the circuit breaker will cut off the power automatically to prevent the damage of the electrical parts. -
Page 12: Warranty
Routine maintenance out-lined in the Operation and Maintenance section must be performed in order to maintain warranty coverage. If the retail customer performs maintenance, aqua-marina.nl reserves the right to make future warranty coverage possible only with proof of proper maintenance. -
Page 13: Liability Free Clause
Placed or changed the motors under wet circumstances which may damage the batteries, the circuit or other electric parts. aqua-marina.nl components. User used parts or accessories that are not genuine Declaration of Conformity for Recreational Craft Propulsion Engine with the requirements of Directive 89/392/EEC as amended by 89/336/EEC. - Page 14 Motor...
