Remote Unit - Intronics DT-04 Plus Instruction Manual

1. Power
Press button to turn on/off the air
conditioner. When turn on, it will operate
according to the last program settings on the

Remote unit.

2. Fan
Press button to select the fan speed or put
it in fan mode.
AUTO
3. Temperature setting
Press button to set the temperature.
4. Mode of operation
Press button to change the mode of
MODE
operation.
for cool only version, or
for cool + heat version.
Remark
In Fan mode,
will be lit.
In Cool/Dry mode,
Display unit will be lit.
In Heat mode,
unit will be lit.
In Auto mode, the LED according to the
current operating mode will be lit.
5. Sleep
Press button to activate the Sleep function
SLEEP
which will raise up/reduce the setting temperature
1°C after 1 hour for Cool/Heat mode respectively.
6. Sweep (optional)
Press
SWEEP
7. Clock Setting
To set the clock on the Remote unit.
Press
blinking.
Press
Press
SEND
8. Timer on/off
To turn on/off the air conditioner in advance
up to 24 hours.
Press
or
ON OFF
Press
Press
SEND
Remark
To cancel is to press
symbol
ON
button.
CANCEL
-3-
Remote unit
on the Display unit
FAN LED
COOL LED
on the Display
HEAT LED
button to turn on/off the sweep motor.
button until clock symbol
button to set the clock.
button to confirm setting.
button until timer symbol
is blinking.
button to set the time.
button to confirm setting.
button until timer
or is blinking, then press
OFF
on the
is
