Summary of Contents for Voxoa P10
-
Page 2: Table Of Contents
CONTENTS ENGLISH IMPORTANT SAFETY INSTRUCTIONS ............... 14 FEATURES ......................16 PART NAMES AND FUNCTIONS ................17 FRONT PANEL ....................17 REAR PANEL ....................21 GETTING STARTED ....................22 SPECIFICATIONS ....................23... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use the apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. - Page 4 IMPORTANT SAFETY INSTRUCTIONS 17. All warnings on the appliance and in the operating instructions should be adhered to. 18. Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifi ers) that produce heat. 19 .Power Sources - This product should be operated only from the type of power source indicated on the rating label.
-
Page 5: Features
FEATURES The VOXOA P10 is an Multimedia Audio Player which accommodates three different kinds of audio sources into one single device. All-in-one Design P10 is an All-In-One audio source device, it combines a CD-Player, MP3-player and AM/FM tuner into one single rack space 19”... -
Page 6: Part Names And Functions
PART NAMES AND FUNCTIONS FRONT PANEL 12 13 14 15 16 1. Function selection button (FUNCTION) The function selection button is a rotatable push dial. By pressing this button, the device will toggle between Tuner, CD or USB & SD/MMC operation mode. By rotating this button, the volume for the “Variable audio output”... - Page 7 PART NAMES AND FUNCTIONS 6. Stop button (STOP) CD, USB & SD/MMC mode The music stops when this button is pushed. Tuner mode Press and hold: By pressing and holding this button, the current chosen radio frequency will be stored on ‘Position 2’ of the selected Band. 7.
- Page 8 PART NAMES AND FUNCTIONS 10. Band select for the tuner (BAND) Tuner mode: Press this button to select between the different tuner bands. The different tuner bands are FM1 – FM2 – FM3 – MW1 – MW2, and can be cyclically selected in this order by pressing the BAND button. CD, USB &...
- Page 9 PART NAMES AND FUNCTIONS 15. Memory for the tuner frequency (MEMO) When pressing this button, the device will start searching for available radio stations and automatically stores them to the preset memory. The radio stations are stored in order of increasing frequency, starting from Band 1 - Position 1 with subsequently the increasing frequencies on the higher positions.
-
Page 10: Rear Panel
PART NAMES AND FUNCTIONS REAR PANEL 1. Power inlet The mains power supply (110~240V AC / 50~60 Hz) has to be applied to this AC power inlet. The connection is made by an IEC power connector and is fi tted with a fuse. When replacing the fuse, make sure that the value of the replacement fuse matches the value of the original fuse. -
Page 11: Getting Started
GETTING STARTED The player is designed for installation into a rack (482 mm / 19”) with a height of one single rack space (44.45 mm), but it can also be placed as a desktop unit. Before using the device, the connections of the device should be made properly. -
Page 12: Specifications
SPECIFICATIONS Features Inputs Audio Compact disk slot (12 cm) USB Memory Stick Input SD/MMC Memory Card Input Control Front panel RS-232 Outputs 2 x Fixed audio output (Tuner & CD/MP3) 1 x Variable audio output (Selectable) Performance Frequency range 87.5~108.0 MHz 522~1620 KHz Channel step 50 KHz... - Page 13 VERSION 1.0 Printed in China...
