Page 2: Table Of Contents
Safety Instructions..........................3 General Safety Instructions.......................3 Installation............................4 Cleaning............................5 Installation.............................6 Base Stand Assembly Instruction..................6 Wall Mounting Installation Guidelines..................7 Antenna.............................7 Power..............................7 Front Panel Layout........................8 Keyboard Layout...........................8 REAR AV Connections........................9 SIDE AV Connections........................9 AV EQUIPMENT Connections....................10 HDMI (basic)..........................10 HDMI (advanced)........................10 AV (Audio/Video)........................11 Audio.............................11 PC Connections..........................11 Remote Control..........................13 Battery Installation ........................13 Getting Started..........................14... - Page 3 Block Program ........................20 Parental Guidance.........................20 USB Source...........................20 EPG MENU (Electronic Program Guide)................21 DTV EPG.............................21 PVR Operation..........................22 Preparing to record programs....................22 Select Disk..........................22 Check PVR File System.......................22 Format............................22 Recording a DTV Program.....................23 Playing back the Recording ....................23 Timeshift Function ........................24 Preparing to record the program ..................24 USB Drive Storage Format ....................24 Record a paused DTV program to USB storage devices........24 Digital Media Player (DMP)......................25...
- Page 4 Turn off the unit immediately. • Disconnect the power plug from the power outlet. • Contact the Kogan customer support team. Never • attempt to make repairs yourself. Never push objects of any kind into the set through the cabinet slots as they may touch dangerous voltage points or short-circuit parts that could result in a fire or electric shock.
- Page 5 An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits, as contact with them may be fatal. Always turn the set off when it is not being used.
-
Page 6: Installation
Do not place this television near water, for example near a bathtub, wash bowl, kitchen sink, laundry tub, swimming pool or in a damp basement etc.. When moving the television to a warm location from a cold location, allow some time for any dew or condensation inside the television to evaporate fully before you turn the unit on. -
Page 7: Antenna
Once all items are removed from the packaging, use the list below to check that nothing is missing. If any items appear to be missing, contact the Kogan.com customer support team. 32” LED TV x 1 •... -
Page 8: Power
For wall mounting with an optional bracket, please read the following instructions in conjunction with the bracket's instructions. If you are not confident of your abilities to mount the TV, please seek assistance from qualified personnel. Kogan.com is not liable for any damage or injury caused by an incorrectly mounted television. - Page 9 Remote control sensor 2. Power indicator LED: Red = stand-by 3. Keyboard (on bottom of TV) 4. Main power switch (on bottom mid right-hand panel of TV) ° The remote control needs to be pointed directly within +/- 30 the sensor on the front of the TV for reliable operation. Note: there will be a 5-10 second delay between the power indicator of the TV changing colour and the TV responding.
-
Page 10: Audio
When viewed from the rear of the TV, the following terminals/connections are visible (from left to right): AC mains power • AV INPUT sockets – RCA type socket for Composite type VIDEO input, and RCA type • sockets for Left and Right audio inputs. AV OUTPUT sockets –... - Page 11 You can use the input and output terminals on the TV set as follows for basic accessory inter- connections. HDMI is a digital connection system that can carry both video and audio information. Using HDMI connections to this TV is recommended where accessory equipment can support higher resolution modes (such as 1080i/1080p) from products such as upscaling DVD players, Blu-ray players and high-performance gaming consoles.
- Page 12 This TV provides an AV input and AUDIO output using line-level analogue stereo Audio and composite format Video signals for compatibility with earlier accessory devices (eg. VCRs, CRT TVs, basic gaming consoles etc). For installations where you have an existing stereo system and wish to improve your listening experience, connect a stereo RCA cable between the AUDIO output R/L sockets on this TV and the appropriate line-level inputs (eg.
- Page 13 720 x 400 31.47 640 x 480 31.47 800 x 600 35.16 800 x 600 37.88 800 x 600 48.08 1024 x 768 48.36 1024 x 768 56.48 The above resolutions are the only ones guaranteed to be supported. Other resolutions may be supported, but this must be assessed by the user on a case-by-case basis.
-
Page 14: Remote Control
The remote control requires two AAA batteries. Below are steps to assist you with replacing batteries. Open the back cover of the battery compartment. 2. Install the batteries into the battery tray. There are +/- polarity markings on the compartment. Please ensure the polarities are correct. -
Page 15: Menu Settings
Once you have connected your TV antenna and other AV playback equipment (eg. CD, DVD, Blu-ray player) to the appropriate input sockets on the rear and side of the TV, you will need to be comfortable with selecting several basic operations before setting up your TV using the Menu system. -
Page 16: Channel Menu
Once the TV has run through the Auto Tune mode and found the available TV stations, you will then need to know how to select the relevant input you want (eg. DTV, AV, HDMI etc) and also how to select and adjust the various menus that allow you to tailor the operation of the TV to suit you application. -
Page 17: Signal Information
: Do not attempt to use this option unless you have a valid software update for the TV that has been supplied by Kogan.com stored on a compatible USB drive, and the drive is connected to the TV. Remove the antenna cable from the TV's RF port, go to the channel menu,... -
Page 18: Picture Menu
The second item of the MENU is the PICTURE MENU. You can adjust picture effects here, such as contrast, brightness etc.. ▲ ▼ Press to move and press OK to adjust. In the Picture Mode sub-menu, the TINT option is available for NTSC systems only. 2. -
Page 19: Time Menu
The fourth item of the menu is the TIME MENU. You can adjust the clock, ▲ ▼ power on/off times, sleep timer etc. Press to move and press OK to adjust. The clock time is automatically set by reading the time data that is transmitted by local Digital TV stations. -
Page 20: Pvr File System
4. HDMI ARC (Audio Return Channel) may allow compatible equipment connected to the TV (eg. A sound bar) to receive audio from the TV via a “return” channel in a compatible HDMI cable, so that the sound is heard through the sound bar without having to connect a second cable between the two devices. - Page 21 This will show the supported speed of recording, and whether your storage device can support HD DTV recording. Speeds above 5,500kb/s are usually more successful when recording HD TV material. This will show the approximate time you will be able to record to your USB drive or Hard Disc. If you wish to reset your TV, please select the Restore Factory Default option.
- Page 22 Press the EPG key to enter the EPG menu. The first line displays the current channel number, channel name, event title and current time. ▲ ▼ The following line displays all programs that will be played on this channel. Press to select the program you desire.
-
Page 23: Check Pvr File System
Before the PVR function can be used, a suitable USB storage device (USB flash-drive or USB hard-drive) must be connected to the USB socket on the rear side panel of the TV. The USB storage device should only be connected or disconnected when the TV is switched off. The USB PVR function relies on the use of high quality USB drives, with higher speed models likely to provide the best performance. - Page 24 When the Format process has finished, you can then use the “Check PVR File System” option to show the speed ability of your USB storage device. Press EXIT to return to the TV mode. If you select the “Hi Speed FS” format mode, you can then change the Time Shift memory size. Remember to set the Time Shift size to be smaller than the total capacity of your USB storage device, or else the Speed test may report an error.
- Page 25 Video may become pixelated if the video bit rate is too high for your USB drive, especially during recordings of high-definition material. If this occurs, try using a faster USB drive, or re-format it using the High Speed Format option. Note: this may make it unreadable in other USB devices.
-
Page 26: Usb Source
To play and view limited types of low data-rate USB media files (such as JPEG, MP3 or AVI formats), use the USB Source that is accessible from the Input button on the Remote Control. For playback of high data-rate media files, the use of an external Media Player (not supplied) will be required. - Page 27 Check antenna position, Snow Noise direction and connection. Check antenna position, Ghosting Normal Audio direction and connection. Electronic equipment, car/ Interference Noise motorcycle, fluorescent lights Volume (check if mute is Normal Picture Mute activated or if the audio systems are not correct) Power cord not inserted No Picture Mute...
- Page 28 Viewing Picture Size (Diagonal) 32” (80cm) Resolution 1366 x 768 Aspect Ratio 16 : 9 Display Colours 16.7M Brightness (Typical) 220 cd/m Contrast Ratio 1400 : 1 Response Time Viewing Angle (max) 160° (H) / 150° (V) TV System Digital TV: DVB-T DVB-T Decode MPEG2 Demodulator: COFDM...
