Summary of Contents for Kogan KALCD46FHDXA
- Page 1 USER MANUAL...
- Page 2 USB..............
-
Page 4: Remote Control Batteries
Remote control/batteries... - Page 6 P.MODE: Picture mode button, setting the picture mode. S.MODE: Sound mode button, setting the sound mode. I/II: Press the I/II button to choose a different audio channel. SLEEP: Sleep button, setting TV power off time. 0,1-9: TV channel selection button. Press the FAV button to start the “Favorite List”...
- Page 7 Remote sensor Power indicator Power on/off button.
- Page 8 USB input socket (USB) 3. VGA interface input socket (VGA) 4. PC audio input socket (PC AUDIO) 5. Composite video & audio input sockets (AV IN-VIDEO R L) 6. Component video input sockets (Y Pb/Cb Pr/Cr) 7. Coaxial Input socket (COAXIAL) 8.
- Page 9 YPbPr...
-
Page 10: Assembling The Stand
Assembly A ssembling the stand Con t ents of car t on: 7 x PB4*14 Screws (for stand) 1 x LCD TV 1 x Stand base Step 1: Place a soft cushioned material on top of a flat surface to prevent damaging the LCD screen.Then place the TV monitor flat on top, with the screen side facing... -
Page 11: Channel Tuning
If this is the first time switch on, the First time installation menu will appear on the display. Language Press o/p/b/a button to select the desired language, then press OK button to enter the “Channel Tuning” screen. The original language of this TV is English. Channel Tuning The TV will start searching channels automatically from Channel Tuning... -
Page 12: Channel Menu
1 CHANNEL MENU The image on the left depicts the channel menu. The definition of each option: Auto Tuning: Press button to this position, then Auto Tuning ATV Manual Tuning press or OK button to enter auto tuning of both ATV DTV Manual Tuning Programme Edit CHANNEL... - Page 13 ATV Manual Tuning: Current CH: Press b/a button to select the channel ATV Manual Tuning number you want to store. Current CH Color System: Press b/a button to change the color Color System system as Auto, SECAM, PAL. Sound System Sound System: Press b/a button to change the sound Fine-Tune 44.00 MHz...
-
Page 14: Picture Menu
2 PICTURE MENU The image on the left depicts the picture menu. The definition of each option: Picture Mode: Changes the picture mode in sequence: Picture Mode Personal Contrast Dynamic Standard Mild Personal. You may select Brightness Colour PICTURE Tint the picture mode by pressing P.MODE button repeatedly. -
Page 15: Auto Standby
4 TIME MENU The image on the left depicts the time menu. The definition of each option: Clock (For DTV only): Display the current system time. Clock 01/Jan 11:11 Time Zone NSW/ACT It’s not available. Sleep Timer Auto Standby TIME Time Zone (For DTV only): Press p/o/b/a button to OSD Timer... - Page 16 Set Password: You can change the password by entering the old and a new password and then re-entering it to Please enter old password confirm the new one. Please enter new password Confirm new password Block Program: Press Green button to lock the desired Block Program channel, press it again to unlock it.
-
Page 17: Setup Menu
Hotel Mode: Have the priority than other options below. To set below options, this item must be set to “On” firstly. Source Lock: To set the input source item which you Hotel Mode Source Lock want to be locked. Default Source Default Prog HOTEL Max Volume... - Page 18 Press button on the remote control to start recording [00:00:59] (0000:23:40) the programme. “ ” mark appears at the top left corner Play Prev. Next Pause Stop 9 Nine Digital 15:51 of the TV screen, and the title bar appears at the bottom which includes the recording information.
-
Page 20: Basic Operation
Basic operation Before operating Media menu, plug in USB device in USB1 port, then press SOURCE button to set the input source to Media. Press o/p button to select Media in the source menu. then press OK or a button to enter. Press b/a button to select the submenu: PHOTO, MUSIC, MOVIE or TEXT, and press OK button to confirm. - Page 21 EXIT Exit EXIT Exit Press b/a button to select the file you want Press OK button to start a slideshow. to watch in the file selecting menu. Press Red button then select “Yes” or press OK button to delete the file selected. When highlighting the option you select, the Press INFO button to show the menu in the file information will appear on the right and...
- Page 22 Press b/a button to select one function in the bottom you want to run, then press OK button to operate. Press EXIT button to return to the main menu. You can press relevant buttons on the remote control to perform such functions directly. l button: Pause or resume playing.
- Page 23 TEXT EXIT Exit Press b/a button to select “TEXT”, then Press b/a button to select the file you want press OK button to enter. to watch in the file selecting menu. When highlighting the option you select, the file information will appear on the right and text will be previewed in the center.
- Page 26 46 inch 1018.08mm (H) X 572.67mm (V) 16:9 1920 X 1080 400 cd/m 4000:1 0.53025mm (H) X 0.53025mm (V) 16.7M 6.5ms 2 (10W, 8 Ohm) YPbPr Input (For YPBPR, AV) USB Input 1920x1080 160W...
