- Page 1 900 Peak Amp Power Station Plus with Inflator Model No.: PKC0S9-01 Owner’s Manual and Warranty Information Read these instructions completely before using this product. Retain this Owner’s Manual for future reference. 1/14 © 2014...
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ........................ 2 Power Station Safety ....................... 2 Battery Jump-Starting Safety ....................2 INTRODUCTION ..........................4 FEATURES ............................4 OPERATION ............................ 5 Display Button ......................... 5 Low Charge Alert (LCA) ......................5 Charging Power Station Battery ....................5 Jump-Starting (Negative Ground Systems Only).............. -
Page 3: First Aid
• Do not smoke or use flammable items (matches, cigarette lighters, etc.) while working on a vehicle’s battery system. • Never jump-start a frozen battery, as it could explode. • Perform all jump-starting procedures in a safe, dry, well-ventilated area. • Do not expose battery to fire or intense heat since it can explode. -
Page 4: Introduction
Please keep this manual on file for future reference. FEATURES • Built-in 900 peak amps battery jump-starter with quick storing cables and clamps • Built-in 100 psi (7 bar) air compressor and quick storing hose to inflate vehicle tires and sport leisure equipment • Built-in 200 watt power (400 peak watts) inverter for powering AC appliances... -
Page 5: Operation
OPERATION Display Button Press the display button once and the screen will indicate the battery charge state as a percentage of the full battery capacity. Pressing the button again will display pounds per square inch (PSI). Pressing the button a third time will turn off the display. -
Page 6: Air Compressor Operation
EXPLOSION HAZARD Jump-start cable clamp connections at the vehicle’s battery terminals must be positive to positive (red clamp to battery “+”) and negative (black clamp) to the grounding point such as the metal frame of the vehicle. A reverse polarity connection (positive to negative) may cause damage to the unit and/or create a sparking/explosion hazard. -
Page 7: Ac Power Inverter Operation
AC Power Inverter Operation Understanding AC Appliances AC appliances are rated by how much electrical power (in watts) they consume. The Power Station can power most appliances within its continuous power rating of 200 watts. Some appliances may be difficult or impossible to operate from this Power Station. -
Page 8: Usb Power Outlet Operation
USB Power Outlet Operation FIRE HAZARD When the jump-starter/USB ON/OFF switch is turned on, the jump-start cables are active. Make sure the jump-starter cables and clamps are properly stored in the designated storage area on the back of the Jump-Starter and are not touching any metal objects when using the USB port. The USB power outlet does not support data communication. -
Page 9: Care And Maintenance
SPECIFICATIONS Built-in battery 12-volt rechargeable, lead-acid, AGM (Absorbed Glass Mat) battery Compressor 100 psi (7 bar) reading gauge 110/120-volt AC 200 watt (peak: 400 watt/0.3 sec.) outlet 12V power socket 12-volt, 10-amp maximum USB power outlet 5 volts/1000 mA maximum... -
Page 10: Limited Warranty
Manufacturer warrants to the original consumer, or purchaser, that the PEAK® 900 Peak Amp Power Station Plus with Inflator PKC0S9-01 will be free from defects in material and workmanship for one year from the date of sale to the original purchaser. Manufacturer hereby excludes and disclaims any and all other warranties, expressed or implied, beyond those warranties specified above.
