Installation and Operating handbook
DLA200 Dual Line Amplifier Unit
th
Handbook Issue 1.00, 20
October 2009
1997
EN 55022 CLASS B
EN 50082-1
EN 60950
PEAK COMMUNICATIONS Ltd.
Kirklees House, 22 West Park Street
Brighouse, West Yorkshire
HD6 1DU, England
Phone 01484 714200
Fax 01484 723666
IMPORTANT NOTE: THE INFORMATION AND SPECIFICATIONS
CONTAINED IN THIS DOCUMENT SUPERCEDE ALL PREVIOUSLY
PUBLISHED INFORMATION CONCERNING THIS PRODUCT
PEAK COMMUNICATIONS Ltd maintains a continuing programme of product
improvement and therefore reserves the right to change specifications without notice
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Peak DLA200
Summary of Contents for Peak DLA200
- Page 1 Fax 01484 723666 IMPORTANT NOTE: THE INFORMATION AND SPECIFICATIONS CONTAINED IN THIS DOCUMENT SUPERCEDE ALL PREVIOUSLY PUBLISHED INFORMATION CONCERNING THIS PRODUCT PEAK COMMUNICATIONS Ltd maintains a continuing programme of product improvement and therefore reserves the right to change specifications without notice...
-
Page 2: Emc And Safety
The DLA200 units are able to power 2 MLA Amplifier units. The DLA200 units are housed in 19 inch 1'U' high chassis, suitable for rack mounting. They are 400 mm deep and may be fitted with rack slides if required. -
Page 3: Specification
22dB typical Active Directivity 20dB minimum -10dBm max. (no load, no damage) RF Input power +25dBm typical TOIP +13dBm typical 1dB Output GCP 7 to 9dB typ. (frequency dependent) Noise Figure Issue 1.00 DLA200 Dual Line Amplifier Units Page 3... -
Page 4: Unit Description
UNIT DESCRIPTION Front panel and Rear panel The DLA200 unit front panels have 5 indicator lights Front panel indicators SUMMARY ALARM GREEN both units no fault. Ext reference locked block 1 and 2 RED unit failure BLOCK 1 GREEN Line amplifier OK and ONLINE AMBER Line amplifier OK and OFFLINE RED Line amplifier failure see rear panel interface connector for condition. -
Page 5: Power Connections
GROUND Not used Not used When the DLA200 has the Ethernet option (option 9), the 15 way D type connector is replaced by a RJ45 ethernet connector. POWER CONNECTIONS The unit contains 2 redundant switch mode power supplies. The voltage input can be in the range of 100-240VAC. - Page 6 When the Ethernet option is fitted to the unit the user cannot change between RS232 or RS485, however the baudrate and address can still be changed. If the baudrate is changed the internal settings for the Moxa Ethernet board needs changing accordingly to match. Issue 1.00 DLA200 Dual Line Amplifier Units Page 6...
-
Page 7: Status Request
Remote control interfacing The DLA200 dual block control system unit may be monitored and controlled remotely either via a RS232 or a RS485 multidrop bus. The connection is made via the 15 way D type on the rear of the unit and configured as described earlier. -
Page 8: Status Reply
Example of an RCU100 message body which is Auto, Local, switch to BDC1, summary alarm OK, UNIT A online, UNIT A unit alarm OK, UNIT B offline, UNIT B unit alarm OK is ALA11101 Issue 1.00 DLA200 Dual Line Amplifier Units Page 8... - Page 9 CONFIGURE Instruction Message body: (all bytes/chars) Description Values position of the UNIT SELECT switch “O" or "A" or "B" Issue 1.00 DLA200 Dual Line Amplifier Units Page 9...
- Page 10 In order to use the Ethernet, the microprocessor in the Peak unit talks to the NE-4001T via its serial port, this means a baud rate must be set up for talking between the NE-4001T and microprocessor. This baud rate can be set to any desirable setting, as long as the NE-4001T board is setup similarly.
- Page 11 UdpNoPorts tcpRtoMin snmpOutPkts UdpInErrors tcpRtoMax snmpInBadVersions UdpOutDatagrams tcpMaxConn snmpInBadCommunityNames UdpLocalAddress tcpActiveOpens snmpInASNParseErrs UdpLocalPort tcpPassiveOpens snmpInTooBigs tcpAttempFails snmpInNoSuchNames tcpEstabResets snmpInBadValues Address Translation MIB AtIfIndex tcpCurrEstab snmpInReadOnlys AtPhysAddress tcpInSegs snmpInGenErrs AtNetAddress tcpOutSegs snmpInTotalReqVars Issue 1.00 DLA200 Dual Line Amplifier Units Page 11...
