Summary of Contents for Cord ezi-dab
- Page 1 manual...
-
Page 2: Introduction
Introduction Thank you for purchasing a CORD Ezi Dab, DAB+ & FM Radio Module. The Ezi Dab is just one product in our range embracing our philosophy of ‘extraordinary audio visual gear.’ This product has been designed and engineered to give you many years of enjoy- ment. -
Page 3: Table Of Contents
Contents • Introduction • Important Safety Messages • What’s in the box • Set Up and Controls • Connections • Remote Control Operation • Initial Startup • Modes of Operation • Listening in DAB+ Mode • Listening in FM Radio Mode •... -
Page 4: Important Safety Messages
Important Safety Messages Before you power on your new CORD product, to ensure safe and efficient operation, please take the time to read the following: • Keep these instructions in a safe place for future reference. • Pay attention to all warnings as these are important to ensure your safety and the optimum operation of this product. -
Page 5: What's In The Box
What’s in the box • One CORD Ezi-dab Radio Adaptor Module • One remote control • One owners manual • One 3.5mm stereo mini jack to stereo RCA audio cable • One 3.5mm fly lead single wire antenna • One 3.5mm to 75 Ohm coaxial antenna adaptor •... -
Page 6: Set Up And Controls
Set Up and Controls 1. LCD Display Window 4. 3.5mm Antenna Input Socket 2. IR Remote Control Sensor 5. 5V DC Power Input Socket 3. 3.5mm Stereo Line Output Socket 6. Power Switch Connections • Connect the 3.5mm stereo mini jack to stereo RCA cable in to the line output sock- et (3), and connect the RCA to your Auxillary (or equivilent) input of your amplifier or home stereo system. -
Page 7: Remote Control Operation
Remote Control Operation Turns the Ezi DAB on or into standby mode • Power Audio mute on and audio mute off • Mute Changes the mode from DAB+ to FM or from FM to DAB+ • Mode Scans for new DAB+ or FM stations, depending on selected mode •... -
Page 8: Initial Startup
Initial Startup connections have been made (refer to page 5) and power to the unit is 1. Once switched on, the LCD display will show the following: Next the DAB+ services will be scanned for automatically, as follows: Once the scan has completed, the first station (alphabetically) will be selected and playback will begin. -
Page 9: Listening In Dab+ Mode
Listening to DAB+ Mode Press the ‘Mode’ button on the remote control to select ‘DAB’ mode. If there are no stations available the Ezi Dab will automatically begin a scan for digital radio stations available in your area. Once the scan has completed, and if stations have been found, the first station listed (alphabetically) will be displayed and begin playing. -
Page 10: Listening In Fm Radio Mode
Listening to FM Radio Mode Press the ‘Mode’ button on the remote control to select FM Radio mode. The following screen will be displayed: Tuning Methods: • Scan - This will scan the FM band for available stations. Press ‘Scan’ on the remote control. The unit will scan up the FM band until it finds the next available station. -
Page 11: Playback Information Display
Playback Information Display Your Ezi Dab has the capability to display various pieces of information, specific to the broadcast you are listening to. This Information service is broadcast dependant, so all information may not be available at all times, depending on what you are lis- tening to. -
Page 12: Alarm Functions
Alarm Functions Your Ezi Dab has 2 separate alarm functions. These alarms can be set at specific times, and alarm alerts can be in the form of DAB+ radio playback / FM radio play- back or 2 different types of buzzer (Series of high pitched beeps or low pitched beeps). -
Page 13: Sleep Function
Sleep Function Your Ezi Dab has a sleep function, which when activated will automatically shut down your unit (into standby mode) after your chosen period of time. Here’s how to use it: Press the ‘Sleep’ button on your remote control. The following screen will be displayed: You can select the desired period of the sleep function by repeatedly pressing the ‘Sleep’... - Page 14 Menu Functions Contd 3. Set 12/24 Hour: This option will change the format of your clock to either 12 hour or 24 hour format. 4. Set Date Format: Changes the date display format between DD-MM-YYYY / MM-DD-YYYY. Backlight: Your Ezi DAB has 3 backlight settings: Timeout: This option is used to set the period of time that you wish your display’s backlight to remain lit when your Ezi Dab is in both ON and STANDBY modes.
-
Page 15: Specifications
Menu Functions Contd DRC: DRC Stands for Dynamic Range Control. The DRC feature is only available when in DAB mode. By adjusting the compression of the broadcast DAB signal, DRC can make quieter sounds easier to hear when your radio is used in a noisy environment. Your Ezi DAB has 3 DRC settings DRC High: Maximum compression. -
Page 16: Troubleshooting
Troubleshooting If you experience any difficulties with the operation of your CORD Ezi Dab, please check the table below before contacting an authorised CORD sercive centre: Problem Possible Cause Remedy No Power • AC Power Cord is out • Connect the AC cord •... -
Page 17: Warranty
Scope Of Warranty CORD warrants to the original retail purchaser that we will repair or replace, at our option, any CORD product which is found to be defective in material and/or work- manship for 12 months from the date of purchase. During the warranty period, an... -
Page 18: What Is Not Covered
We reserve the right to make changes or improvements in design or manufacture without any obligation to change or improve previously manufactured product. CORD shall not be responsible for incidental and or consequential damages or loss. What Is Not Covered The cost of delivery and insurance in transit to the service centre. - Page 19 PROUDLY DISTRIBUTED IN AUSTRALIA AND NEW ZEALAND BY: VOLITION AUSTRALIA PTY LTD 20 Corporate Boulevard, Bayswater VIC 3153 Australia PHONE: 03 9729 9300 / SERVICE: 03 9729 7300 / FAX: 03 9729 7900 Email: service@volition.com.au Ezi Dab July 2013...
