- Page 1 ORIGINAL INSTRUCTIONS CAUTION – READ THESE INSTRUCTIONS BEFORE USING THE MACHINE User instructions HM10, HM10HD, HM20HD Carpet Soil Extraction Machines 03-8229-0000 Iss.2 04/10...
-
Page 2: Table Of Contents
Contents Product Information ....................... 3 1.1 Important Safety Advice....................3 1.2 Guidelines for the operator....................4 1.3 Transporting the machine ....................4 1.4 Electrical connection ......................4 1.5 Symbols & Markings ......................4 Controls..........................5 Preparing for use ........................5 Operation .......................... -
Page 3: Product Information
• Do not pick up oil or other flammable material. Truvox International for advice. • Do not use to pick up moisture or any liquids. • Do not leave the machine connected to the... -
Page 4: Guidelines For The Operator
1.2 Guidelines for the operator plug are not trailing. Detach hose and wand from machine where applicable. WARNING Operators must be fully trained in the use Do not lift or transport the machine whilst of the machine in accordance with these containing liquid as this will add considerably to instructions, able... -
Page 5: Controls
• Important - Take care to only use appropriate low-foam carpet cleaning chemicals with the Controls machine. Incorrect chemicals could cause damage to the carpets being cleaned or cause the machine to malfunction. Hose release Operation catch Vacuum hose 4.1 Starting the machine inlet •... -
Page 6: Cleaning Stairs
4.4 Cleaning Stairs 5.3 Maintenance CAUTION - When cleaning on stairs WARNING Before undertaking maintenance operations exercise adjustments switch off machine and great care to ensure that machine is unplug from the electricity supply. stable and cannot overbalance, possibly causing injury to The machine requires minimum maintenance either operator or third party. -
Page 7: Guarantee
61 x 37.5 x 43 Cable length 14.4 16.4 Weight empty 15.8 Warranty 1 year Truvox International is a BSI Registered Company and our policy is one of continuous development. We reserve the right to change specifications without prior notification. -
Page 8: Accessories And Cleaning Chemicals
10 Accessories and Cleaning Chemicals Accessory Part no. Usage 3 metre hose assembly (vac hose, 93-0125-0000 As supplied with HM10, HM10HD solution hose and all connectors) and HM20HD Standard floor tool 93-0140-0000 As supplied with Hydromist 10 3 part stainless tubes, polyethylene... -
Page 9: Parts Lists & Diagrams
Hydromist 10 Parts List 12 Parts List & Diagrams Model Ref.: HM10 Series B Service Parts List Issue 2 23rd March 2010 Part No. Description 93-0001-0000 Label (Vacuum) 93-0002-0000 Label (Spray) 93-0014-0000 Vacuum motor 93-0021-0000 Water feed hose coupling flat washer... - Page 16 ...
- Page 17 Hydromist 10HD Parts List Model Ref.: HM10HD Series B Service Parts List Issue 2 23rd March 2010 Part No. Description 93-0001-0000 Label (Vacuum) 93-0002-0000 Label (Spray) 93-0007-0000 Suppressor wiring 93-0008-0000 Diaphragm Pump 230v 40W 93-0009-0000 Brown wire connection 93-0014-0000 Vacuum motor 93-0021-0000 Water feed hose coupling flat washer 93-0025-0000 Bumper strip 93-0028-0000 Switch (Pump / Vacuum)
- Page 24 ...
- Page 25 Hydromist 20HD Parts List Model Ref.: HM20HD Series B Service Parts List Issue 2 23rd March 2010 Part No. Description 93-0001-0000 Label (Vacuum) 93-0002-0000 Label (Spray) 93-0007-0000 Suppressor wiring 93-0008-0000 Diaphragm Pump 230v 40W 93-0009-0000 Brown wire connection 93-0014-0000 Vacuum motor 93-0021-0000 Water feed hose coupling flat washer 93-0025-0000 Bumper strip 93-0028-0000 Switch (Pump / Vacuum)
- Page 32 ...
-
Page 33: Declaration Of Conformity
13 Declaration of Conformity Declaration of Conformity We, Truvox International Ltd. Third Avenue, Millbrook, Southampton, Hampshire England SO15 0LE declare that the machinery Make : Carpet Soil Extraction Machines Type : Hydromist Model : HM10..., HM10HD…,HM20HD… Serial Number : from 01000... - Page 36 Authorised dealer: Truvox International Limited Third Avenue, Millbrook, Southampton, Hampshire SO15 0LE, England Tel: +44 (0) 23 8070 2200 Fax: +44 (0) 23 8070 5001 e-mail: truvox@truvox.com Web: www.truvox.com...
