Summary of Contents for Ariston micro SYSTEM 10 RFFI
- Page 1 Users Manual...
- Page 2 Dear Customer, The guarantee on this appliance is valid for 12 months from the first Thank you for choosing an ARISTON boiler. day of installation. We guarantee that your boiler is a reliable and technically sound product. Repairs to the electric, hydraulic or...
-
Page 3: Table Of Contents
TABLE OF CONTENTS page 4 ENERAL NFORMATION Technical Information page 5 Control Panel page 6 page 7 PERATING NSTRUCTIONS page 12 SEFUL NFORMATION AND ROUBLESHOOTING page 15 AINTENANCE page 15 HANGE OF page 15 LOCK MPORTANT Please read this manual carefully. For additional information, please consult the “Installation and Servicing Instructions.”... -
Page 4: General
1. G Do not allow children or inexperienced ENERAL NFORMATION persons to use the appliance without supervision. MTS (GB) Limited support the If you smell gas in the room, do not turn on initiative. Your installer will give you, and light switches, use the telephone or any other show you how to use, a logbook which will object which might cause sparks. -
Page 5: Technical Information
ECHNICAL NFORMATION 10 kW 15 kW 21 kW 28 kW GENERAL DATA Heating input max-min 11.6 15.4 22.7-10.0 29.8-12.0 Heating output max-min 10.5 27.8-10.5 14.1 21.0-8.7 Efficiency at Maximum Thermal Capacity 81.3 82.4 83.7 84.2 (see Installation Instructions) CENTRAL HEATING Operating Temperature max-min °C 82-42... -
Page 6: Control Panel
ONTROL ANEL 10 RFFI / 15 RFFI 21 RFFI /28 RFFI FR011A... -
Page 7: Operating Instructions
2. OPERATING INSTRUCTIONS EGEND - On/Off button AUTION - On/Off L.E.D. green (frost nstallation, start-up, adjustments and protection active) maintenance must be performed by a - Central Heating button competent person only, in accordance - Cental Heating active with the current Gas Safety (Installation & Use) Regulations and the instructions L.E.D. - Page 8 - The outer panels of the units case must ELPFUL UGGESTIONS only be cleaned with a damp cloth. Do not use abrasive cleaners. The control To get the most out of your boiler, we have panel can be wiped with either a damp provided you with some useful advice on or dry cloth.
-
Page 9: Ignition Procedure
and maintenance costs. Ignition procedure - If the boiler should be out of use for a prolonged period, it is recommended Push the button “A” the green L.E.D. “B” that the electrical power supply be will illuminate indicating that the boiler is disconnected and that the external gas supplied with electricity. - Page 10 The centralised electronic control unit will Adjusting the heating ignite the burner, without any manual intervention but in response to the request It is possible to set the temperature of the for heating. If, after approximately 10 heating system by adjusting the knob “G” seconds, the burner has not ignited, the between 1 and 5 until the stop on the boiler safety devices will shut off the gas...
- Page 11 External (room) thermostat Turning off central heating control To turn off the central heating, push the “C” button and the green L.E.D. ”D” will go off. If an external (room) thermostat is installed, The boiler will remain electrically supplied it is recommended that the temperature of and frost protection will be active for the heating system be set (by means of the temperatures below 6°C.
-
Page 12: Useful Information And Troubleshooting
Turning off the boiler 3. USEFUL INFORMATION AND TROUBLESHOOTING To turn the boiler off, push the button “A” the respective green L.E.D. “B” will go off. Boiler shutdown situations Close the gas cock located under the boiler and turn the electricity supply switch The boiler is equipped with safety devices (located outside the boiler) to the OFF that intervene in certain situations and shut... - Page 13 Should the boiler fail to ignite a second to allow the exchanger to cool down, then time, check that the external gas cock is press and release the reset button “E”. open. If the problem persists, contact an If this situation occurs frequently, contact an Authorised Service Centre.
-
Page 14: Frost Protection
the correct level the boiler will ignite discharge state of exhaust fumes has returned to normal, the boiler automatically automatically. If there are frequent drops in turns back on. pressure within the system, have a plumber Important! check the heating system for possible water If this situation occurs frequently, contact an leaks. -
Page 15: Maintenance
- the system pressure is sufficient; the other, one of our Authorised Service - the boiler is powered electrically; Centres should be contacted. - gas is being distributed. 6. TIME CLOCK 4. MAINTENANCE A time clock for central heating is available Schedule an annual maintenance check-up as an accessory kit and can be mounted for the boiler with a competent person. - Page 16 Manufacturer: Merloni TermoSanitari SpA - Italy Commercial subsidiary: MTS (GB) LIMITED MTS Building Hughenden Avenue High Wycombe Bucks HP13 5FT Telephone: (01494) 755600 Fax: (01494) 459775 Internet: http://www.mtsgb.ltd.uk E-mail: info@mtsgb.ltd.uk Technical Service Hot Line: (01494) 539579...
