Getting Started

Connectors
Back panel
- 1 PS/2 mouse port
- 1 PS/2 keyboard port
- 4 USB 2.0 ports
- 1 VGA port
- 1 DVI-D port (optional)
- 1 LAN jack
- 6 flexible audio jacks
- 1 Serial port (COM1)
- 1 IEEE1394 port (optional for V2.X)
On-Board Pinheaders/ Connectors
- 1 Front Panel Audio pinheader
- 1 CD-In pinheader
- 1 SPDIF-Out pinheader
- 2 USB 2.0 pinheaders
- 1 Chassis Intrusion Switch pinheader
- 1 Parallel port supporting SPP/EPP/ECP mode pinheader
- 1 Serial port pinheader (for V2.X)
- 1 IEEE1394 pinheader (optional for V2.X)
Slots
- 1 PCI Express x16 slot
- 1 PCI Express x1 slot (for V1.X)
- 2 PCI slots (for V1.X)
- 3 PCI slots (for V2.X)
- Support 3.3V/ 5V PCI bus Interface
TPM (optional)
- Supports TPM
Form Factor
- M-ATX (23cm X 24.4cm, for V1.X)
- M-ATX (24.4cm X 24.4cm, for V2.X)
M ounting
- 6 mounting holes (for V1.X)
- 8 mounting holes (for V2.X)
1-3
