- Page 1 DSC-N114_Network_Video_Recorder Quick Start Guide 8200-1116-05...
- Page 2 Regulatory information FCC information This equipment has been tested and found to comply with the limits for a digital device, pursuant compliance: to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
-
Page 3: Trademarks And Registered Trademarks
Trademarks and Registered Trademarks • Windows and Windows mark are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. • HDMI, HDMI mark and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. •... -
Page 4: Table Of Contents
TABLE OF CONTENTS NVR Pre-Installation ............................4 NVR Installation .............................. 4 Hard Disk Installation ............................. 4 Front Panel ............................... 6 Rear Panel ................................ 7 HDD Storage Calculation Chart ........................9 Accessing by Web Browser ..........................10 Logging In ..............................10 Live View .............................. -
Page 5: Nvr Pre-Installation
NVR Pre-Installation The NVR is highly advanced surveillance equipment that should be installed with care. Please take into consideration the following precautionary steps before installation of the NVR. 1. Keep all liquids away from the NVR. 2. Install the NVR in a well-ventilated and dust-free area. 3. - Page 6 3. Connect the power cable to the HDD. 4. Place the HDD on the bottom of the device and then fasten the screws on the bottom to fix the HDD. 5. Re-install the cover of the NVR and fasten screws.
-
Page 7: Front Panel
Front Panel Name Description Power Power indicator turns yellow when system is running. Status indicator blinks red when data is being read from or written Status Status to HDD. Indicator Tx/Rx indictor blinks yellow when network connection is Tx/Rx functioning properly. Universal Serial Bus (USB) ports for additional devices such as USB Interface USB mouse and USB Hard Disk Drive (HDD). -
Page 8: Rear Panel
Rear Panel The rear panel vaires according to different models. DSC-N114-8/ DSC-N114-16 DSC-N114-8/ DSC-N114-16 Item Description Power Supply DC 12V power supply. Audio In RCA connector for audio input. HDMI Interface HDMI video output connector. LAN Network Interface 1 10 /100 /1000 Mbps self-adaptive Ethernet interface Audio Out RCA connector for audio output. - Page 9 Item Description Power Switch Switch for turning on/off the device. Network Interfaces with Network interfaces for the cameras and to provide power over Ethernet. PoE function...
-
Page 10: Hdd Storage Calculation Chart
HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K 256K 112M 320K 140M 384K 168M 448K... -
Page 11: Accessing By Web Browser
Accessing by Web Browser Logging In You can get access to the device via web browser. Open web browser, input the IP address of the device and then press Enter. The login interface appears. Input the user name and password, and click the Login button. ... -
Page 12: Recording
The live view interface may differ according to different models. Interface Introduction Name Description Displays the list of channels and the playing and recording status of each Channel List channel. Live View Window Displays the image of channel, and multi-window division is supported. Play Control Bar Play control operations are supported. - Page 13 3. Check the checkbox of Enable Schedule to enable recording schedule. 4. Choose the day in a week to configure scheduled recording. 5. Click Edit to edit record schedule. Configure All Day or Customize Record: If you want to configure the all-day recording, please check the All Day checkbox. ...
-
Page 14: Playback
Playback The playback interface may differ according to different models. Interface Introduction Name Description Channel List Displays the list of channels and the playing status of each channel. Playback Window Displays the image of channel. Play Control Bar Play control operations are supported. Time Line Displays the time bar and the records marked with different colors. -
Page 15: Log Query
6. You can drag the progress bar with the mouse to locate the exact playback point. You can also input the time in the textbox and click button to locate the playback point. The color of the video on the progress bar stands for the different video types. Log query You can view and export the log files at any time, including operation, alarm, exception and information of device. -
Page 16: Menu Operation
Menu Operation Menu Structure Menu Playback Maintenance Shutdown Export Manual Record Camera Configuration Normal Record General Schedule Camera General System Info Logout Event Alarm Advanced Parameters Network Shutdown Information Advanced Image Alarm Reboot Import/Export Holiday RS-232 Upgrade Motion Live View Default Privacy Net Detect... -
Page 17: Adding Ip Cameras
Select the Shutdown button. Click the Yes button. Adding IP Cameras You should add and configure the online IP cameras to enable the live view and recording function. Steps: 1. Right-click the mouse when you in the live view mode to show the right-click menu. 2. -
Page 18: Recording
Icon Explanation Icon Explanation Edit basic parameters of the camera Add the detected IP camera. The camera is disconnected; you can The camera is connected. click the icon to get the exception information of camera. Delete the IP camera Advanced settings of the camera. To add other IP cameras: Click the Custom Adding button to pop up the Add IP Camera (Custom) interface. -
Page 19: All-Day Recording
window when you click on it. Click the icon to enable the record All-day Recording Steps: 1. On the live view window, right lick the window and move the cursor to the Start Recording option, and select Continuous Record or Motion Detection Record on your demand. 2. - Page 20 Under multi-screen live view, record files of the selected channel will be played back. Pressing numerical buttons will switch playback to related channels during playback process. 2. Playback management. The toolbar in the bottom part of Playback interface can be used to control playing process. Just check the channel or channels if you want to switch playback to another channel or execute simultaneous playback of multiple channels.
- Page 21 3. Check backup result. Choose the recording file in Export interface and click button to check it.
