ADEMD4B Series Net DVR

User Manual

Model: ADEMD4B000TV
ADEMD4B000TVS
V.1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADEMD4B000TV and is the answer not in the manual?

Questions and answers

Related Manuals for Tyco ADEMD4B000TV

Summary of Contents for Tyco ADEMD4B000TV

  • Page 1: User Manual

    ADEMD4B Series Net DVR User Manual Model: ADEMD4B000TV ADEMD4B000TVS V.1.0...
  • Page 2 Digital Video Recorder User Manual Index Chapter1 Product Introduction..................7 Summary ........................7 Features .........................7 Chapter2 Installation ....................10 Check DVR and It’s Accessories ................10 HDD Installation ......................10 DVR Rear Panel......................12 External Alarm In/Out Connection ................13 Chapter3 Operational Instructions................14 DVR Front Panel......................14 Remote Controller.......................16 OSD Menu Description....................18 3.3.1...
  • Page 3 Digital Video Recorder User Manual 5.7.2 Select tampering area..................48 5.7.3 Alarm handling ....................48 5.7.4 Temple Alarm schedule................49 Video Loss Alarm......................50 Motion Detection Alarm .....................52 5.10 Live View Setup ......................55 5.11 Recording Setup ......................56 5.12 Alarm I/O Setup ......................60 5.13 Network Setup.........................63 5.13.1 Network Basic Settings................64 5.13.2...
  • Page 4 Digital Video Recorder User Manual Safety Precaution Caution: To reduce the risk of electric shock, do not remove cover, unless you are ready to install hard disks, please refer to the section "Hard Disk Installation". Only qualified service technician can perform the service. Important Safeguards: 1.
  • Page 5 Digital Video Recorder User Manual damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 13. Moving - Disconnect the power before moving the unit. The unit should be moved with care.
  • Page 6 Digital Video Recorder User Manual Cleaning You can clean the unit with a moist fluff-free cloth or leather cloth. Warning This device is intended for use in public areas only. Surreptitious recording of oral communications may be prohibited by law. Unpacking Check the package for visible damage.
  • Page 7 Digital Video Recorder User Manual Product Introduction Chapter1 Product Introduction 1.1 Summary ADEMD series network digital video recorders utilize the latest IT technologies, e.g. H.264 video compression, large capacity HDD recording, TCP/IP etc. With embedded MCU and DSP chip, it delivers digital video recording with extremely reliability in an economical package.
  • Page 8 Digital Video Recorder User Manual Local processing Record Supports multiple record modes, including real time, manual record, motion detection, alarm inputs, Motion & Alarm in, motion or alarm in Supports 1 SATA HDD, up to 2TB/HDD. Supports FAT32 file system Supports HDD S.M.A.R.T technology Supports cycle or none cycle record Supports backup the recorded files and clips...
  • Page 9 Digital Video Recorder User Manual Network Supports TCP/IP Supports PPPoE for broad band dialup Supports DHCP Supports remote parameters setup via client software Support real-time preview via TCP, UDP, RTP, broadcast Alarm information can be sent to remote host Network control PTZ Network record the real time stream Network download and playback of recorded files in DVR Supports firmware remote upgrade...
  • Page 10 Digital Video Recorder User Manual Installation Chapter2 Installation 2.1 Check DVR and It’s Accessories Upon receiving the device, check that all the items are included in your product package. There is a list in the package. If any of the items is missing, please contact your dealer immediately.
  • Page 11 Digital Video Recorder User Manual choose "Hard disk" to format the hard disks, Check if all installed disks are detected by the DVR, and if the capacity is OK. Choose "Format" and select "All" to format all hard disks. When all disks are formatted, a confirmation message will be shown on the screen.
  • Page 12 ② Video out Audio in ⑧ ③ VGA interface ⑨ Audio out ④ Alarm out UTP interface ⑩ ⑤ RS485 T+ T- R+ R- ⑪ Alarm in Power switch ⑫ DC12V power supply ⑥ ADEMD4B000TV does not have a VGA interface.
  • Page 13 Digital Video Recorder User Manual 2.4 External Alarm In/Out Connection Alarm inputs Alarm input port (dry contact): G (GND): Connect the GND of sensor. 1~4: Alarm input, support normally open/normally close. Alarm output: 1G: 1 relay output. Alarm output connection Connect with DC device Connect with AC device...
  • Page 14 Digital Video Recorder User Manual Operational Instructions Chapter3 Operational Instructions 3.1 DVR Front Panel Index Type Name Description IR Sensor IR receiver for remote controller. State Power Green = DVR is working; Lamps Red = DVR is powered off; STATUS Green = Numeric keys is enabled;...
  • Page 15 Digital Video Recorder User Manual In preview mode, display or hide the channel status bar. SHIFT Switch between numeric keys and function keys Control Direction Composed of 【 】,【 】,【 】 and 【 】. Keys Keys 1. Menu mode, use【 】/【 】 select,【 】/【 】 to edit;...
  • Page 16 Digital Video Recorder User Manual 3.2 Remote Controller Index Name Description POWER Turn On/Off device Enable/Disable remote controller Select video channel, entry Numeric Keys password EDIT Same as [EDIT] key on front panel Switching character input method Same as [REC] key on front panel Same as [PLAY] key on front PLAY panel...
  • Page 17 Digital Video Recorder User Manual Same as [ESC] key of front panel Reserved Reserved for future function Reserved for future function IRIS, FOCUS ZOOM for lens Lens control control Reserved for future function Loading the batteries into the remote controller Remove the battery cover.
  • Page 18 Digital Video Recorder User Manual 3.3 OSD Menu Description 3.3.1 Main Menu Items Menu Name Function Menu Name Function Language Device ID Enable/Disable password Camera name and position Screen saver Color Output video format OSD Display mode, position Display Camera Brightness and OSD format setup Menu transparency...
  • Page 19 Digital Video Recorder User Manual 3.3.2 Menu Operation How to enter into menu mode Press [MENU] key to enter into DVR main menu Press [PLAY] key to enter into playback menu Press [REC] key to enter into manual record menu Press [PTZ] key to enter into PTZ control mode Notes: You may be required to input user name and password.
  • Page 20 Digital Video Recorder User Manual Each menu contains different kinds of items: Check Box: Provide 2 options, “ ” means enabled and “×” means disabled. You can use [ENTER] or [EDIT] key to check/uncheck the box. List Box: Provide more than 2 options. However, only one of them can be selected.
  • Page 21 Digital Video Recorder User Manual 3.4 Character Input In the menu interface, if you enter into edit status, for example, in the “camera name” edit box at the bottom of screen, the input status is appeared: Here you can press numeric keys to input digital number. Press [A] key to change input methods.
  • Page 22 Digital Video Recorder User Manual Basic Operation Guide Chapter4 Basic Operation Guide 4.1 Power on Note: make sure the user must have the rights to particular operation, otherwise a warning screen will shown as below. If [POWER] lamp is off, please do as following: Step1: Connect AC cable correctly;...
  • Page 23 Digital Video Recorder User Manual Press [EDIT] key to manually switch to the next camera. You can set the preview mode in the menu. Press [Enter] key to pause/start sequence display. Press [->]/[<-] key to switch multi-screen mode.
  • Page 24 Digital Video Recorder User Manual 4.3 Login Note: The default administrator named is “admin”, and password is“12345”. You may change the administrator password after initial login. The administrator can create 15 users and its privileges. Login dialog is shown as below: Use [ ] / [ ] keys to select one user, press [ ] key to enter into “Password”...
  • Page 25 Digital Video Recorder User Manual Select channel In PTZ control mode, you can press channel buttons or numeric keys to select channel. When a dome camera is selected, you may use the multi-function keys to control PTZ. PTZ control key assignment Direction control: [↑], [↓], [←], [→] ZOOM: [ZOOM+], [ZOOM-] (on remote controller)
  • Page 26 Digital Video Recorder User Manual 4.5 Manual Record Manual record In either preview of menu mode, press [REC] key to enter the Manual Record screen as shown in below. Description Channel: List the available channels on the DVR. Status: There are four available statuses. =idle;...
  • Page 27 Digital Video Recorder User Manual 4.6 Playback Playback interface In either preview of menu mode, press [PLAY] key to enter the “Playback” interface as shown in below. Description Chan: Use [↑] or [↓] key to select the channel you want to playback. Rec Type: Use [↑] or [↓] to select recorded file type.
  • Page 28 Digital Video Recorder User Manual Backup Devices: You can select USB flash, USB HDD, USB CD/DVD or SATA CD/DVD writer to backup the files or clips. Copy: Start to backup. Backup Today: Backup all recorded files of today. Two playback modes 1.
  • Page 29 Digital Video Recorder User Manual Operation on playback Below images shown the playback: One Channel Playback At the bottom of image, there is an information bar indicates Speaker Volume, play progress in %, play speed, run rime and total rime of the file. You may do the following operation during the playback: Display/Hide information bar: [MENU] Open/Close sound: [PLAY]...
  • Page 30 Digital Video Recorder User Manual 4.7 Backup Recorded Files Backup intraday recorded files In the playback interface, move “Active Frame” to “Backup Today” button, press [ENTER] key, all intraday recorded files of all channels will be backup to the save device. A pop-up dialog will display the backup status.
  • Page 31 Digital Video Recorder User Manual Backup video clips You also can backup the video clips when the file is being playback. The steps are: Step 1: Enter into the playback interface, and play the video by files or by time; Step 2: Press [EDIT] key to start selecting the current position, and press [EDIT] again to stop selecting.
  • Page 32 Digital Video Recorder User Manual Enter into “Utilities” menu, move “Active Frame” to “Power Off” button and enter into power off dialog, press “Yes" to shut down the DVR. Use [POWER] key Press [POWER] key on IR for 3seconds. DVR will be shut off. Note: Do not switch off the power switch at real panel directly or disconnect the power cable during DVR recording, it may damage the HDD and the DVR permanently.
  • Page 33 Digital Video Recorder User Manual Advanced Operation Guide Chapter5 Advanced Operation Guide Note: Only the users with “Parameters Setup” right have the access to the advanced operation. When the following parameters are modified and saved, you must reboot the DVR to make the new parameters effective. Modifications on other parameters do not require reboot.
  • Page 34 Digital Video Recorder User Manual 5.1 User Management There is one default administrator from the manufacturer. The default usename is “admin” and password is “12345”. The administrator’s name can not be changed, you may change the password after initial login. Move “Active Frame”...
  • Page 35 Digital Video Recorder User Manual 5.1.1 Add User Step 1: Enter into “User Management” menu: Step 2: Add new user name: Move to “Add” button and press [ENTER], in the pop-up menu, input the new user name, press [ENTER] and return to “User Management” menu. Max. 15 users can be added.
  • Page 36 Digital Video Recorder User Manual Step 3: Setup the password for new user: After you add one new user, the password is null. You can use [ ] [ ] keys to move the “Active Frame” to “Password”, press [Edit] to go into the edit mode, enter your password twice and press [Done] to confirm.
  • Page 37 Digital Video Recorder User Manual 5.1.3 Password Modification Move “Active Frame” to “User” icon, press [ENTER] key to enter into “User Management” menu. Use [ ][ ] keys to select one user, and use [→] key to move “Active Frame” to password edit box, and press [EDIT] key to enter into edit mode.
  • Page 38 Digital Video Recorder User Manual If the two entries do not match, an error message will shown as above, please press [ENTER] to return password edit box, and enter the new password again. 5.1.4 User Rights The new user does not have any operation rights. You must setup rights for it. On the “User Management”...
  • Page 39 Digital Video Recorder User Manual User rights description “Local Rights”: Local rights represent the operation on the DVR. E.g. Operate via front panel, remote controller and RS-485 keyboard. PTZ control: Locally control PTZ; Record: Manual start/stop recording; Playback: Local playback and backup the recorded files; Parameters Setup: Locally setup the DVR parameters;...
  • Page 40 Digital Video Recorder User Manual 5.2 Device ID The default device ID of DVR is “88”. If there are more than one DVR in one place, please make sure to set different device ID for each DVR. In “Display” menu, move “Active Frame” to the device ID edit box, in the edit mode, you can use numeric keys to input new device ID.
  • Page 41 Digital Video Recorder User Manual Press [Done] button to save, or press [Cancel] to abort. 5.4 Date and Time Setup 5.4.1 Date and Time Setting In “Display” menu, you can setup DVR system date and time. Date/Time setting window is shown in below:...
  • Page 42 Digital Video Recorder User Manual 5.4.2 Date and Time Display Mode You can setup display properties for each camera, including display format, position and format. And you can copy the properties of one camera to the others. In “Image Setup” menu as following, select one camera: Display mode: There are several display modes: Opaque&Steady, Transparent&...
  • Page 43 Digital Video Recorder User Manual 5.4.3 Daylight Saving Time Setup DST means Daylight Saving Time, select the check box to enable the function, and you can set DST start time and end time in your region. 5.5 Camera Setting 5.5.1 Camera Title In “Camera Setting”...
  • Page 44 Digital Video Recorder User Manual The steps to setup camera title are listed below: Step 1: Select one camera. Step 2: Move “Active Frame” to “camera Title” edit box, press [Enter] key to enter into edit window, move to Title, you can input numbers, uppercase and lowercase characters (refer to Chapter 3.4).
  • Page 45 Digital Video Recorder User Manual 5.5.2 Video Parameters Setup To get the best video quality, you may need to adjust video parameters for each individual camera. Video parameter can be setup individually, or you can copy the setting from one to the others.
  • Page 46 Digital Video Recorder User Manual Step4: Enable “Privacy Mask” option, click [Area] button to enter into mask setup window. Step 5: Setup mask area: Setup the masks as prompted on screen. Step 6: Save mask area: Repeat step2~4 to setup mask area for other cameras. In “Advanced Setting”...
  • Page 47 Digital Video Recorder User Manual 5.7 View Tampering Alarm 5.7.1 Enable Tamper Alarm Step 1: Enter into “Camera” menu. Step 2: Select camera: use [ ] [ ] keys to select one camera. Step 3: Enter into “Advanced settings” setup menu. Step 4: Select sensitivity.
  • Page 48 Digital Video Recorder User Manual the Tamper alarm is enabled. 5.7.2 Select tampering area Step 1: Enter the “Area” setting window. Step 2: Select tamper area as prompt on screen. Only one tamper area can be setup. 5.7.3 Alarm handling Step 1: Press [Action] to save the setting Step 2: Enter “Alarm Handling”.
  • Page 49 Digital Video Recorder User Manual Step 4: Set Temple Alarm handling. Step 5: Press [Done] to save configuration or press [Cancel] 5.7.4 Temple Alarm schedule Step 1: Enter “Event Schedule”. Step 2: Set schedule as desired. Max. 4 time periods allowed for one day. Schedule can be copied from one day to the others.
  • Page 50 Digital Video Recorder User Manual 5.8 Video Loss Alarm DVR will generate alarm in case of video loss, if this feature is enabled. Please follow the steps in below to setup the video loss alarm: Step 1: Follow the Step1~3 as described in chapter 5.7.1. Step 2: enable check box next to ”Video Loss”...
  • Page 51 Digital Video Recorder User Manual Step 5: Set the alarm handling. Step 6: Save alarm setup: Press [Done] to return to “Advanced Setting” menu or press [Cancel] to abort. DO REMEMBER to press [Done] again to save your setting.
  • Page 52 Digital Video Recorder User Manual 5.9 Motion Detection Alarm If you enable this function, when there is a motion detected, DVR will make alarm. Step 1: Enter “Camera” menu: Step 2: Select camera: Use [ ] [ ] key to select one camera. Step 3: Enter “Motion Detection”.
  • Page 53 Digital Video Recorder User Manual Step 6: Motion alarm handling: Enter the “Motion Alarm Handle” menu: Step 7: Motion alarm record channel setting: In case of motion alarm occurs, DVR can trigger related camera to start recording. In “Motion Alarm Handle” menu, you can select one or more record channels.
  • Page 54 Digital Video Recorder User Manual Step 9: Motion alarm handling: Set the alarm handling as needed. Description: If “On Screen Warning” is enabled, in case of motion alarm occurs and DVR is in preview mode, it will pop-up the live image of related camera. If more than one camera are assigned, DVR will pop-up the live image in sequence with a interval of 10 seconds.
  • Page 55 Digital Video Recorder User Manual 5.10 Live View Setup In “Display” menu, you can setup live preview properties. Enter the “Preview” setting window, you can setup preview mode, display interval for sequence, enable/disable audio preview and preview layout etc.. Preview mode: For preview mode item, you can use [↑] [↓] key to select one mode. Display interval: Set the interval for sequence display.
  • Page 56 Digital Video Recorder User Manual select the channel to be displayed on the auxiliary(spot) monitor. Audio preview: Play the audio with live image. Alarm display time: Time to display the alarm live video. Preview layout setup: To set the video layout. First select the preview mode, then move the “Active Frame”...
  • Page 57 Digital Video Recorder User Manual Resolution: Recording resolution. You may choose from QCIF, CIF. Bit Rate: Set the maximum bit rate of video stream. The bit rate value has following options (bps): 32K, 48K, 64K, 80K, 96K, 128K, 160K, 192K, 224K, 256K, 320K, 384K, 448K, 512K, 640K, 768K, 896K, 1M, 1.25M, 1.5M, 1.75M, 2M and “User define”.
  • Page 58 Digital Video Recorder User Manual Step 2: Select one day and enable all day recording option Move the “Active Frame” to “Day”, select a day and check the “All Day” box. Step 3: Record type Select “Rec Type” from: All Time, Motion Detect, Alarm, Motion|Alarm, or Motion&Alarm. For all day record mode, only one record type can be selected.
  • Page 59 Digital Video Recorder User Manual Step 2: Select one day and disable all day recording option Move the “Active Frame” to “Day”, select a day and uncheck the “All Day” box. Step 3: Setup time period and record type There are 4 time periods for one day, enter the start time and stop time for each time period, and select record type.
  • Page 60 Digital Video Recorder User Manual 5.12 Alarm I/O Setup From the main menu, move “Active Frame” to “Alarms” and press [ENTER] key to enter into alarms setting page: External alarm input setup: Step 1: Select alarm input: Use [↑] [↓] keys to select one alarm input. Step 2: Select input type: Select from N.O.
  • Page 61 Digital Video Recorder User Manual Step 4: Alarm trigger record channel setup You can select channels to record for each alarm input. In the sub menu, you can use [ENTER] or [EDIT] key to enable record channel. Note: In order to trigger the channel recording, in “Recording” menu, you must enable recording and select record type as “Alarm”...
  • Page 62 Digital Video Recorder User Manual First select one camera, and then select one of following PTZ linkage: Preset: Check the “Enable Preset” box to enable recall preset, and enter the preset # in the following box. In case of alarm input activated, DVR will trigger SpeedDome to an assigned preset.
  • Page 63 Digital Video Recorder User Manual Step 2: Select delay time: Set the output delay time from: 5 Seconds, 10 Seconds, 30 Seconds, 1 Minute, 2 Minutes, 5 Minutes, 10 Minutes and Manual Stop. If you select “Manual’, the alarm output will not be deactivated until you press “Clear Alarm”...
  • Page 64 Digital Video Recorder User Manual 5.13.1 Network Basic Settings IP address: This IP address must not be conflict with other IP. If there is DHCP server in network, you can set the IP as “0.0.0.0”, save and reboot DVR. In reboot process, DVR will search the DHCP server and get one dynamic IP address.
  • Page 65 Digital Video Recorder User Manual 5.13.2 Network Advanced Settings NIC type: Default is “10M/100M Auto”, the other options are: 10M Half-Dup, 10M Full-Dup, 100M Half-Dup and 100M Full-Dup. : If DVR uses PPPoE function, and get one dynamic IP address. If you set IP IP Server server with one fixed Internet IP, DVR will send some information such as DVR name, DVR serial number, DVR current IP to that fixed IP address.
  • Page 66 Digital Video Recorder User Manual display the dynamic IP address obtained from DHCP server. 5.13.4 PPPoE Function Enter into DVR “Network” menu, press “PPPoE” setup menu: Step 1: Enable “PPPoE” option Step 2: Input PPPoE username provided by ISP Step 3: Input PPPoE password provided by ISP Step 4: Input PPPoE password again Step 5: Save parameters.
  • Page 67 Digital Video Recorder User Manual can receive DVR information and used to resolve DVR dynamic IP. IP server is one software run on the computer; The following figure illustrate the typical window of the IP server software. You may develop your own IP server SW to fit your particular project needs based on the DVR SDK.
  • Page 68 Digital Video Recorder User Manual Connect DVR RS-485 port Pin “T+” with PTZ Pin “A”. Connect DVR RS-485 port Pin “T-“with PTZ Pin “B”. 5.14.2 PTZ Settings Please make sure RS-485 parameters setting is match to the PTZ protocol . In main menu, move “Active Frame”...
  • Page 69 Digital Video Recorder User Manual parameters must be the same as those of PTZ protocol. PTZ address: Set PTZ camera address. Protocol: DVR had the following PTZ protocol: TYCO_AD422, Pelco-p, Pelco-D, Samsung, Panasonic, infinova, YouLi, LinLin-1016, LinLin-820, DM DynaColor, HD600, JC-4116, Pelco-d WX, VCOM VC-2000, NetStreamer, SAE/YAAN, Kalatel-312, CELOTEX, TLPelco-p, TLHHX-2000, BBV, RM110, KC3360S, ACES, ALSON, INV3609HD, Howell, Tc Pelco P, Tc Pelco D, AUTO-M, AUTO-H, ANTEN, CHANGLIN, DeltaDome, XYM-12,...
  • Page 70 Digital Video Recorder User Manual 5.14.3 PTZ Control In “Preview” mode, press [PTZ] button on IR, you can enter into PTZ control mode. Use jog shutter or [ ]/[ ] [->]/[<-], DVR will check PTZ protocol and send corresponding PTZ control commands through RS-485 port. 5.14.4 Preset Setup Preset is using one number to represent the camera’s position, zoom, focus and iris.
  • Page 71 You can save to 16 sequences. Feature may vary on different PTZ cameras, refer to manufacturer’s instruction for details. Tyco will only provide technical support for Tyco SpeedDome Ultra & Optima series.
  • Page 72 “Sequence” setup menu: In “Sequence” setup menu, you can input the sequence number. If you use Tyco SpeedDome, you should go to SpeedDome menu to set the Sequence, and only SpeedDome Ultra 7 and later version supports recall on Sequence.
  • Page 73 Press [Return] button back to “PTZ” menu. In “PTZ” menu, press [Done] button to save all settings. Feature may vary on different PTZ cameras, refer to manufacturer’s instruction for details. Tyco will only provide technical support for Tyco SpeedDome Ultra & Optima series.
  • Page 74 Digital Video Recorder User Manual 5.15 Exceptions Setup The exceptions alarm includes the followings: hard disk full, hard disk error, illegal access, IP address conflict, network failure, and NTSC/PAL differ. Enter into DVR “Alarms” menu, move active frame to “Exceptions” and press [Enter] to enter into exception menu.
  • Page 75 Digital Video Recorder User Manual Utilities Chapter6 Utilities “Utilities” menu provides many useful features of the DVR. The “Utilities” setting window is shown in below: 6.1 Restore Parameters Restore factory default parameters for DVR. Please note the IP address, gateway and port number can not be restored.
  • Page 76 Digital Video Recorder User Manual...
  • Page 77 Digital Video Recorder User Manual 6.2 Hard Disk Management HDD status Display the Hard Disk Capacity, Free space, Idle, status. Format HDD Please make sure you stop all recording before run the format. Reboot the unit after format. 6.3 Clear Alarm Out Reset the alarm output manually.
  • Page 78 Digital Video Recorder User Manual 6.6 View Log To view log file of the DVR. In “Utilities” menu, press “View Log” to enter into “Log” menu: If you want to view the log based on default option, just press [ENTER] key. DVR will list all matched information.
  • Page 79 Digital Video Recorder User Manual Firmware Upgrade Chapter7 Firmware Upgrade 7.1 Upgrade from USB Flash In DVR “Utilities” menu, click firmware “Upgrade” button, in the popup dialog box: You can select either upgrade via FTP mode or USB mode. If you select USB mode, please make sure that firmware file is placed in USB FLASH root directory, and USB FLASH should be FAT32 file system.
  • Page 80 Digital Video Recorder User Manual Step 2: Select “Logging” in the menu，choose Log Options in the sub menu, and make selection as following: Step 3: Select “Users/rights” under “Security” menu item. The following dialog box will be pop-up. Step 4: Create new user: Click “new user’. New user dialog pops up. Input user name “target”.
  • Page 81 Digital Video Recorder User Manual Step 5: In the password dialog, input password “target” in “New Password” and “Verify Password” edit box. Click “OK” to save and exit the dialog box. Step 6: In the “User/Rights Security” Dialog, select “User Name” as “target”. In “Home Directory”...
  • Page 82 Digital Video Recorder User Manual Upgrading will start and prompt to reboot the device once the process is done.
  • Page 83 Digital Video Recorder User Manual 7.3 Use Client Software to Upgrade You can use client software to upgrade, please refer to user manual of client software for how to configure the DVR and some other configurations, then enter the menu “configuration”...

  • Page 84: Appendix A Hdd Capacity Calculation

    Digital Video Recorder User Manual Appendix A HDD Capacity Calculation Please use the below formula to calculate total HDD capacity needed for the DVR according to video recording requirement (Recording resolution and Time period). Step 1: Use the Formula (1) to calculate storage capacity that is the capacity for one camera/hour, in unit Mbyte.

  • Page 85: Appendix B Dvr Connector Definition

    Digital Video Recorder User Manual Appendix B DVR Connector Definition RS485 Connection RJ45 introduction Pin definition To make the connect cable according the follows. T+, T- = TXD+, TXD- R+, R- = RXD+, RXD- UTP Network Connection Pin definition To make the network cable according to the actual situation, there are two options: (1) Connect via a hub/switcch Standard Ethernet Patch Cable (2) Connect directly to PC...
  • Page 86 Digital Video Recorder User Manual Ethernet Crossover Cable...

  • Page 87: Appendix C Specifications

    Digital Video Recorder User Manual Appendix C Specifications ADEMD4B000TV ADEMD4B000TVS Model Name Video H.264 compression Preview PAL: 352*288 (CIF), NTSC: 352*240 (CIF) resolution Playback PAL: 352*288 (CIF), NTSC: 352*240 (CIF) resolution Video input 4-ch BNC (Electrical Level: 1.0Vp-p, resistance: 75Ω) Composite video 1-ch, BNC (Electrical Level: 1.0Vp-p, resistance: 75Ω)
  • Page 88 Digital Video Recorder User Manual Size 315mm x 230mm x 45mm...

  • Page 89: Appendix D Quick Reference

    Digital Video Recorder User Manual Appendix D Quick Reference Type Name Description Index Create and delete users. System has one User default administrator. The administrator can management Safety create 15 users and define their rights. Password Modify password. Management Format HDD, HDD information. management Manual record, All time record, Motion Recording...
  • Page 90 Digital Video Recorder User Manual Remote Remote playback the recorded files in DVR playback Download Download recorded files in DVR. Remote Remote upgrade firmware. upgrade Using IE to access DVR OSD setup 5.4, 5.5 LOGO Logo setup 5.4, 5.5 Utilities View log View log Two way voice talk or one way voice...

  • Page 91: Appendix E Troubleshooting

    Digital Video Recorder User Manual Appendix E Troubleshooting Failure Possible reasons “POWER” light in front Panel does not turn on, and fan Power cable is broken. does not work. Power supply is broken. DVR continuously reboots after start up every 10 Upgraded wrong seconds.

This manual is also suitable for:
