ASSEMBLY AND INSTALLATION INSTRUCTIONS
IMPORTANT: Read entire instruction sheet be-
fore assembling or installing mantel kit.
These mantels are only approved for use with
any FMI PRODUCTS, LLC 26'' electric and com-
pact gas fireplace systems. Do not use mantel
with any other product.
This mantel kit contains the following:
•
Mantel pieces - unassembled and numbered as follows:
#1 Base
#2 Right Side Assembly
#3 Left Side Assembly
#4 Header
#5 Top
#6 Heat Reflector Strip
•
Hardware Package
20 - 1 1/4" Wood Screws
* Extra hardware may be included
Tools required:
•
Power Screwdriver with #2 Phillips Bit
W26GO Mantel and Base
114325-01
For more information, visit www.fmiproducts.com
If any wood pieces are missing or damaged, contact the dealer
where you purchased this mantel for replacement. If hardware
is missing or damaged, contact FMI PRODUCTS, LLC at
1-866-328-4537 for referral information. You can also visit
FMI PRODUCTS, LLC's web site at www.fmiproducts.com.
Note: Gather all mantel pieces together before assembling
mantel.
WARNING: Only use 1¼" screws to assemble
mantel. Damage to mantel will result if other
screws are used for this purpose.
