Summary of Contents for Celluon Picopro
- Page 1 User Manual...
-
Page 3: Table Of Contents
Switching Connection Mode e. Reset Switch 8. Making Adjustments a. Volume Adjustment b. Speaker / Earphone Usage c. Laser Alignment d. APC Setting e. Engine High Temperature Protection Mode 9. Charging the PicoPro 10. Troubleshooting 11. Specifications 12. Warranty... -
Page 4: Safety Precautions
1. Safety Precautions This product is not waterproof – avoid using it near water or wet places. There is a risk of malfunction if product is used in places where sudden or extreme temperature changes occur. Applying excessive force or impact to this product may result in product damage, and will void warranty. Never attempt to disassemble or service this product yourself. -
Page 5: Industry Canada Statement
FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Industry Canada Statement This device complies with Industry Canada license- exempt RSS standard(s). -
Page 6: Certifications
Pulse frequency : 60Hz IEC 60825-1:2007 compliant RoHS IC No : 10211A-PICOPRO IEC-60825-1 : Class 3R Laser IEC-60825-1 : Class 3R Laser 3. Environmentally Friendly Disposal and Recycling To protect the environment, dispose this product separately from household waste once it has reached its end of life, or take it to your local electronic waste disposal center. -
Page 7: Package Contents
5. Product Features PicoPro is a laser-based HD pico projector that always stay focused and easily fits in your pocket. It enables you to share contents from your mobile device onto any surface via HDMI connection or Miracast (Screen Mirroring) capability. -
Page 8: Identifying Parts
6. Identifying Parts Touch-sensitive Volume Down Touch-sensitive Volume Up Reset Button Speaker Backlit Battery Indicator Light FCC ID : TCLPICOPRO CE1177 KC : MSIP-CMM-CLK-PICOPRO IC : 10211A-PICOPRO Model : PicoPro DC : 5V 2A Celluon, Inc. Made in Korea 3.5mm Audio Out... -
Page 9: Connecting Picopro
App Store or Play Store. b. Wired Connection **For proper operation of PicoPro, please do not insert HDMI cable during Miracast connection. Using HDMI Connection : Use plug-n-play connection for any digital/mobile device via HDMI connection. - Page 10 * For Samsung devices, please use supplied Samsung adapter (5pin to 11pin converter) to connect to MHL/HDMI cable. *During the use of PicoPro via supplied MHL cable, connected mobile device may charge from PicoPro's internal battery. It is recommended to supply power via USB port on supplied MHL cable to maintain PicoPro's operating time.
-
Page 11: Wireless Connection
The Miracast capability is called different names on difference devices. ( i.e. Samsung/Sony = Screen Mirroring, HTC = Media Output) Please find this in device settings. 1. Turn on PicoPro by pressing the power button for about 2-3 seconds. 2. Celluon logo will display upon powering on, followed by a “Preparing 3. - Page 12 4. On a desired mobile device, find and select Screen Mirroring / Media Output. 5. Mobile device will search for nearby devices to connect. 6. When device discovers “Celluon PicoPro”, tap 7. Mobile device will say “Connected” to connect. and PicoPro will start mirroring display.
-
Page 13: Using Dlna
* To connect to a device using DLNA capability, you must install a DLNA streaming app on your mobile device. Applicable apps can be downloaded from App Store/ Play Store. 1. Turn on PicoPro by pressing the power button for about 2-3 seconds. - Page 14 4. Lightly press “Mode Switch” button again to change to DLNA mode. 5. DLNA “Ready to Connect” screen will display upon completion of mode switch.
- Page 15 6. On a desired mobile device, go to WiFi setting, and connect to “Celluon PicoPro”. Use password “12345670” to connect. 8. When WiFi is successfully connected, open the installed DLNA streaming application on the mobile device. 9. Select desired content to display.
-
Page 16: Reset Switch
1. From HDMI mode, press and hold "Mode Switch" button for about 2 seconds. 2. Celluon logo will display briefly, and "Please connect using HDMI cable or Press Mode Switch button to change to wireless mode" screen will display. 3. Use HDMI cable to connect device. -
Page 17: Making Adjustments
When the temperature of the engine reaches 140°F, the engine will power off automatically to prevent damages from the heat. For the safety of the product, it is recommended to use PicoPro in the areas with specified operating temperature, and use the product again after cooling. -
Page 18: Charging The Picopro
A low battery warning icon will show on the screen when the battery is low. ■ Use the included power adapter to charge your PicoPro. If the battery is too low, PicoPro will automatically turn off. ■ Please use included power adapter or any adapter supports 5V 2A to charge PicoPro. -
Page 19: Troubleshooting
Please make sure PicoPro is being charged with the dedicated adapter. Other adapters may not meet the optimal power supply required PicoPro turns off while charging for PicoPro. Therefore, using other adapters than the one provided may lead to the PicoPro turning off until sufficient battery power is stored. -
Page 20: Specifications
11. Specifications Item Spec. Remark Display Method Laser Product Lifetime 10,000 hours The perceived brightness of laser projectors with a given ANSI Brightness 32 ANSI Lumens brightness is 50%+ higher than that of the LED based projectors Aspect Ratio 16:9 Throw Ratio Display Performance Sequential Contrast Ratio... -
Page 21: Warranty
Adapter MicroUSB Type 5V / Max 2A 5V 2A to charge PicoPro. ** Using other adapters than the one provided may result in longer charging times. When PicoPro is paired to your mobile device via provided MHL cable, the connected device will charge from PicoPro’s internal battery. - Page 22 12. Warranty Celluon warrants this product to be free from defects in materials and workmanship under normal use for a period of one (1) year from the date of purchase, ■ as evidenced by the receipt of purchase. During the warranty period, Celluon shall repair or replace the product if defective. If replaced, the replacement shall be with a product of equal or greater value.
- Page 24 Version 1.1...
