Summary of Contents for Celluon PicoAir

  • Page 1 User Manual...

  • Page 3: Table Of Contents

    6. Identifying Parts 7. Connecting PicoAir a. Compatible Operating Systems b. How to Connect c. Switching Connection Mode 8. Making Adjustments a. Volume Adjustment b. Speaker / Earphone Usage c. Laser Alignment 9. Charging the PicoAir 10. Troubleshooting 11. Specifications 12. Warranty...

  • Page 4: Safety Precautions

    1. Safety Precautions This product is not waterproof – avoid using it near water or wet places. There is a risk of malfunction if product is used in places where sudden or extreme temperature changes occur. Applying excessive force or impact to this product may result in product damage, and will void warranty. Never attempt to disassemble or service this product yourself.

  • Page 5: Industry Canada Statement

    FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Industry Canada Statement This device complies with Industry Canada license- exempt RSS standard(s).

  • Page 6: Certifications

    Pulse frequency : 60Hz IEC 60825-1:2007 compliant RoHS IC No : 10211A-PICOAIR IEC-60825-1 : Class 3R Laser IEC-60825-1 : Class 3R Laser 3. Environmentally Friendly Disposal and Recycling To protect the environment, dispose this product separately from household waste once it has reached its end of life, or take it to your local electronic waste disposal center.

  • Page 7: Package Contents

    Holding Mount Pouch 5. Product Features PicoAir is a laser-based HD pico projector that always stay focused and easily fits in your pocket. It enables you to share contents from your mobile device onto any surface via Miracast or DLNA connection.

  • Page 8: Identifying Parts

    Touch-sensitive Volume Down Touch-sensitive Volume Up Reset Button Backlit Battery Indicator Light Speaker FCC ID : TCLPICOAIR CE1177 KC : MSIP-CMM-CLK-PICOAIR IC : 10211A-PICOAIR Model : PicoAir DC : 5V 2A Celluon, Inc. Made in Korea 3.5mm Audio Out Power Button...

  • Page 9: Connecting Picoair

    1. Turn on PicoAir by pressing power button for Please find this in device settings. 2-3 seconds. 2. Celluon logo will display upon powering on, followed by a "Preparing 3. After 20~30 seconds, "Ready to Connect" screen will display. Wireless Connection…" screen.
  • Page 10 4. On a desired mobile device, find and select Screen Mirroring / Media Output. 5. Mobile device will search for nearby devices to connect. 6. When device discovers “Celluon PicoAir”, 7. Mobile device will say “Connected” and tap to connect.
  • Page 11 1. Turn on PicoAir by pressing power button and App Store / Play Store. holding for 2-3 seconds. 2. Celluon logo will display upon powering on, followed by a "Preparing 4. DLNA “Ready to Connect” screen will display upon completion of mode wireless connection" screen.

  • Page 12: Switching Connection Mode

    5. On a desired mobile device, go to WiFi setting, and connect to "Celluon PicoAir". Use password "12345670" to connect. 6. When WiFi is successfully connected, open the installed DLNA streaming application on the mobile device. 7. Select desired content to display.

  • Page 13: Making Adjustments

    Please connect a speaker or an earphone to the 3.5mm audio out jack. Laser Alignment When the images seem blurry and/or the colors appear skewed, please visit Celluon website at www.celluon.com for Laser Alignment instructions. Engine Firmware Update Press and hold battery status indicator for about 3 seconds.

  • Page 14: Charging The Picoair

    A low battery warning icon will show on the screen when the battery is low. ■ Use the included power adapter to charge your PicoAir. If the battery is too low, PicoAir will automatically turn off. ■ Please use included power adapter or any adapter supports 5V 2A to charge PicoAir.

  • Page 15: Troubleshooting

    10. Troubleshooting Mobile device cannot find Celluon PicoAir during Please make sure PicoAir is on Miracast mode. This may also be due to particularly heavy wireless traffic. If this is Miracast connection search the case, please reset the device by pressing the reset button on the back of device.

  • Page 16: Specifications

    11. Specifications Item Spec. Remark Display Method Laser Product Lifetime 10,000 hours The perceived brightness of laser projectors with a given ANSI Brightness 32 ANSI Lumens brightness is 50%+ higher than that of the LED based projectors Aspect Ratio 16:9 Throw Ratio Display Performance Sequential Contrast Ratio...
  • Page 17 Please use the included power adapter or any adapter supports Power Adapter MicroUSB Type 5V / Max 2A 5V 2A to charge PicoAir. ** Using other adapters than the one provided may result in longer charging times. The MIT License (MIT) Copyright (c) <2015> <Celluon, Inc.>...

  • Page 18: Warranty

    12. Warranty Celluon warrants this product to be free from defects in materials and workmanship under normal use for a period of one (1) year from the date of purchase, ■ as evidenced by the receipt of purchase. During the warranty period, Celluon shall repair or replace the product if defective. If replaced, the replacement shall be with a product of equal or greater value.
  • Page 20 Version 1.0...
