Page 1: Instruction Manual
2 x 7" TFT LCD MONITOR TLM-702HD Instruction Manual Rev 150310 www.datavideo-tek.com... -
Page 2: Table Of Contents
Table of Contents Warnings and Precautions ......................3 Warranty ............................. 4 Standard Warranty ........................4 Two Year Warranty ......................... 4 Disposal ............................. 4 Packing List ..........................4 Introduction ..........................5 Features ............................. 5 Supported Formats ........................5 Connections & Control ....................... 6 Front Panel .......................... -
Page 3: Warnings And Precautions
Warnings and Precautions 1. Read all of these warnings and save them for later reference. 2. Follow all warnings and instructions marked on this unit. 3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. -
Page 4: Warranty
For more detailed information about the recycling of this product, please contact your local Datavideo office. Packing List Q’ty Items Description TLM-702HD AC Power Cord 1.5 ψHex Wrench 2.5 ψHex Wrench Switching Adaptor DC 12V/30W User’s Manual... -
Page 5: Introduction
Introduction The Datavideo TLM-702HD is a 19” rack mountable dual 7” TFT Monitor. The all metal construction makes the TLM-702HD robust and durable, and the 12V DC power requirements make it easy to power in the field. The high resolution TFT screens have a wide viewing angle and feature NTSC / PAL auto detection. -
Page 6: Connections & Control
Connections & Control Front Panel Power Switch Switches the power On / Off. Stereo Headphone Mini Jack socket The level is adjusted by headphone volume control. Listen to embedded audio from HDMI or SDI sources. Headphone Volume Control Allows you to adjust the headphone volume. Source Button Select Input source between SDI, YPbPr, CVBS, and HDMI. -
Page 7: Rear Panel
Rear Panel HD/SD - SDI input BNC connector for SDI Input. YUV input BNC connectors for analogue (Component) video inputs. Composite Video input BNC connector for analogue (Composite) video inputs. HDMI in interface HDMI digital signal input connecter. Supports HDMI 1.1 Tally In Send in red and yellow colour tally signal to tally LED. -
Page 8: Menu Options
Menu Options 1. Picture - Press the button once to display the Picture setting menu. MENU - Press the button to highlight the Brightness setting. ENTER - Press the button to highlight the setting that needs to be adjusted. DOWN - Press button to select the Brightness setting. -
Page 9: Advance
- Press the button to display the OSD Blending setting position. ENTER - Press the button to select the OSD blending value (from 0~7). DOWN NB: OSD Blending value 0 = Min transparency 7 = Max transparency - Press the button to save the OSD blending value. -
Page 10: Calibrating Datavideo Monitors
Calibrating Datavideo Monitors Perhaps the most important way to make sure that your video really looks as good as it can on other monitors is to monitor the video during production with a properly calibrated monitor. For guidance on how to calibrate a Datavideo Monitor using SMPTE colour bars please visit our website http://www.datavideo.info/en/faq.php Specifications... -
Page 11: Service & Support
Service & Support It is our goal to make your products ownership a satisfying experience. Our supporting staff is available to assist you in setting up and operating your system. Please refer to our web site www.datavideo-tek.com for answers to common questions, support requests or contact your local office below.
