Summary of Contents for Data Video TLM-702HD
-
Page 2: Table Of Contents
Table of Contents Warnings and Precautions............................3 Packing List................................4 Introduction ................................5 Features ..................................5 Supported Formats ..............................5 Front Panel ................................6 Rear Panel ................................. 7 Menu Options................................8 1. Picture ................................8 2. Audio .................................. 8 3. Function................................8 4. -
Page 3: Warnings And Precautions
Warnings and Precautions 1. Read all of these warnings and save them for later reference. 2. Follow all warnings and instructions marked on this unit. 3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. -
Page 4: Packing List
For more detailed information about the recycling of this product, please contact your local Datavideo office. Packing List TLM-702HD 1.5 ψ Hex Wrench 2.5 ψ Hex Wrench Switching Adaptor DC 12V/1.5A... -
Page 5: Introduction
Introduction The Datavideo TLM-702HD is a 19” rack mountable dual 7” TFT Monitor. The all metal construction makes the TLM-702HD robust and durable, and the 12V DC power requirements make it easy to power in the field. The high resolution TFT screens have a wide viewing angle and feature NTSC / PAL auto detection. -
Page 6: Front Panel
Front Panel Power Switch Switches the power On / Off. Stereo Headphone Mini Jack socket The level is adjusted by headphone volume control. Listen to embedded audio from HDMI or SDI sources. Headphone Volume Control Allows you to adjust the headphone volume. Source Button Select Input source between SDI, YPbPr, CVBS, and HDMI. -
Page 7: Rear Panel
Rear Panel HD/SD - SDI input BNC connector for SDI Input. YUV input BNC connectors for analogue (Component) video inputs. Composite Video input BNC connector for analogue (Composite) video inputs. HDMI in interface HDMI digital signal input connecter. Supports HDMI 1.1 Tally In Send in red and yellow colour tally signal to tally LED. -
Page 8: Menu Options
Menu Options 1. Picture - Press the button once to display the Picture setting menu. MENU - Press the button to highlight the Brightness setting. ENTER - Press the button to highlight the setting that needs to be adjusted. DOWN - Press button to select the Brightness setting. -
Page 9: Advance
NB: OSD Blending value 0 = Min transparency 7 = Max transparency - Press the button to save the OSD blending value. ENTER - Press the button to highlight the Time Code setting. DOWN - Press the button to toggle the on screen Time Code display ON/OFF. ENTER - Press the button to highlight the TC Position setting. -
Page 10: Calibrating Datavideo Monitors
Tally light indication The TLM-702HD has a tally input connector on the rear of each panel. The Datavideo range of digital video switchers can provide tally light signals to this connector. The Datavideo range of intercom systems can also be used to pass on these tally signals. -
Page 11: Specifications
Specifications 2x HD/SD-SDI input (SMPTE 272M-C 1.5Gbps, 270Mbps with Embedded Audio) 2x Component Y.U.V Sony Betacam Specification Interface 2x CV input 2x HDMI input 2x D-Sub 15 Pin Plug (Tally Light Signal) SDI/HD-SDI Specifications Standard SMPTE 259M-C (270Mbps - 525/625 Component Video) and SMPTE 292M (1.485/1.001 Gbps) Connector BNC (IEC 169-8)
