User Manual
Version 1.3 December 2012
Point-of-Sale
Hardware System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POS335 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seypos POS335

Summary of Contents for Seypos POS335

  • Page 1 User Manual Version 1.3 December 2012 Point-of-Sale Hardware System...
  • Page 2 Copyright 2012 All Rights Reserved Manual Version 1.3 Part Number: The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS To disconnect the machine from the electrical Power Supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. Read these instructions carefully.

  • Page 4: Legislation And Weee Symbol

    CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. Battery Caution Risk of explosion if battery is replaced by an incorrectly type. Dispose of used battery according to the local disposal instructions.
  • Page 5 The crossed dustbin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life. Instead, the device should be taken to the waste collection centers for activation of the treatment, collection, recycling and disposal procedure.

  • Page 6: Revision History

    Revision History Revision Date Description V1.0 Sep, 2009 Release  V1.1 June, 2011 C46 MB added  V1.2 July,2012 C56 MB added   I/O port changed V1.3 December, 2012 Rear cover changed  MSR module changed ...

  • Page 7: Table Of Contents

    Table Contents 1 Item Checklist..........1 Standard Items................1 Optional Items ................2 2 System View...........3 Front View ..................3 Rear View ..................4 Bottom View..................5 I/O View................... 6 3 Peripherals Installation.........7 MSR Installation................7 VFD Installation ................8 Second Display Installation ............10 Cash Drawer Installation..............12 Wall Mount Kit ................14 4 System Assembly &...

  • Page 8: Item Checklist

    1 Item Checklist Standard Items a. System b. Power adapter (65W) c. Power cable d. COM-RJ45 cable (x2) e. Driver CD...

  • Page 9: Optional Items

    Optional Items a. MSR module b. Finger print c. VFD module d. Second display e. Wall mount kit f. Wireless LAN card g. SSD card module...

  • Page 10: System View

    System View Front View Number Description Touch screen MSR module (Option) Power button...

  • Page 11: Rear View

    Rear View Number Description VFD cover (for VFD & Second display installation) Stand/Wall mount kit installing place Stand Cable management outlet...

  • Page 12: Bottom View

    Bottom View Number Description Stand pad...

  • Page 13: I/O View

    I/O View Standard Optional Number Description Cash drawer USB x 4 COM1~4 (from right to left) Power jack for system Power button Parallel (standard) / USB x 2 (optional) HDD clip Note: The maximum current that can be drawn from each COM port is 500 mA.

  • Page 14: Peripherals Installation

    3 Peripherals Installation MSR Installation Open the dummy cover of the MSR. Connect the MSR cable to the connector on the system. Insert the MSR module in place and fasten the screw (x2) on the back to secure the module.

  • Page 15: Vfd Installation

    VFD Installation Accessories: Plastic bracket Metal bracket Screws Remove the screws (x2) and slide the VFD cover outward. Positioning the VFD metal bracket onto the rear side of the VFD module and fasten the screws (x2). Positioning the plastic bracket onto the metal bracket as shown in the picture.
  • Page 16 Fasten the screw (x1) to fix the plastic bracket to the metal bracket and VFD module. Slide the VFD module with bracket into the VFD socket. Fasten the screws (x2) to fix the VFD module. Connect the VFD cable to the VFD module. Connect the VFD cable to the COM4 port on the System.

  • Page 17: Second Display Installation

    Second Display Installation To install the 8.4” second display, please open the VFD cover first (See chapter 3-2 step1). Accessories: Plastic bracket Metal bracket Screw Power adapter Screws Second display Place the system face down, make sure not to scratch the screen. Place the metal bracket onto the rear side of the second display and fasten the screws (x4) to fix metal bracket with the system.
  • Page 18 Fasten the screw (x1) to fix the platic bracket and second display module with metal bracket. Slide the second display module into the slot. Fasten the scrws (x2) to fix the second display moudle with the system. Connect the VGA cable to the second display module and the COM port on the system.

  • Page 19: Cash Drawer Installation

    Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer. Register Location: 48Ch Attribute: Read / Write Size: 8bit...
  • Page 20 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 21: Wall Mount Kit

    Wall Mount Kit Before installing the Wall Mount Kit, please remove the stand first if needed. (See Chapter 4-3) Accrssories Place to install a. Wall Plate b. Monitor plate Screw metal bracket The wall mount Kit installing place is at the rear side of the system. Place “b”...

  • Page 22: System Assembly & Disassembly

    4 System Assembly & Disassembly Replace the HDD Place the system face down. Make sure not to scratch the screen. The HDD is secured by a clip, please push the clip aside as the picture shows. Pull the plastic tab (see picture) to remove the hard drive.

  • Page 23: Replace The Power Adapter

    Replace the Power Adapter Unfasten the thumb screw (x1) to seperate the retaining metal bracket from the stand and take out the power adapter. Remove the System Stand Remove the screws (x2) that secure the stand and the system. Remove the screws (x4) that fasten the plastic VESA mounting plate and the LCD rear cover.

  • Page 24: Specification

    5 Specification Model Name POS335 Motherboard Intel Atom N270 Intel PineTrial D525 Intel Cedarview D2550 dual-core CPU support processors 1.6G, L2 512K dual-core 1.8G, L2 1M, 1.86GHz, L2 1M FSB 533MHz FSB667/ 800MHz Intel 945GSE Express CPU integrated graphic +...
  • Page 25 Model Name POS335 Motherboard DC jack E-SATA interface DC-OUT, E-SATA 2nd VGA 1 (DB-15 Female, power by BIOS configuration) Cash drawer 1 (19V) 1 (12V/24V cash drawer power by BIOS configuration) Audio Speaker 2 x 2W speakers (Option) Power Power adapter 65W, 19V/3.42A...

  • Page 26: Jumper Settings

    6 Jumper Settings C36A Motherboard 6-1-1 Motherboard Layout...
  • Page 27 6-1-2 Connectors & Functions Connector Function BAT3 CMOS Battery Base ( Use CR2023) Speaker & MIC Connector Power Connector For HDD USB5 USB7 Card Reader Connector CN12 IrDA Connector CN13 Inverter Connector CN15 Power LED CN16 LCD Interface Connector CN21 Internal Power On Switch Connector CN22 5 Wire Touch...
  • Page 28 6-1-3 Jumper Settings Cash Drawer Power Setting Function (1-2) (3-4) +12V ▲+19V Power Mode Setting Function (1-2) ▲ATX Power AT Power CMOS Operation Mode Function (1-2) ▲CMOS Normal CMOS Reset System Reset Setting Function (1-2) ▲Normal Reset ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 29 COM3 & COM4 Power Setting Function (1-2) (3-4) (5-6) (7-8) (9-10) (11-12) COM3 Pin10 ▲+5V +12V COM4 Pin10 ▲+12V VGA Power Setting Function (1-2) ▲No Power +12V ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 30 LCD ID Setting Panel LVDS Resolution Number Bits Channel (1-2) (3-4) (5-6) (7-8) 1024 Single 1280 1024 Dual Single 1024 Single ▲ = Manufacturer Default Setting OPEN SHORT...

  • Page 31: C46 Motherboard

    C46 Motherboard 6-2-1 Motherboard Layout...
  • Page 32 6-2-2 Connectors & Functions Connector Function Speaker & MIC CONN SATA Power For external Touch Card reader CN12 PS2 Keyboard CN13 HDD LED CONN CN16 Inverter CN17 TUOCH CN18 Power LED CONN CN19 LVDS (24bit) CN20 SYSTEM FAN CN21 DC-JACK CN22 POWER BOTTOM CONN CN25...
  • Page 33 6-2-3 Jumper Settings Cash Drawer Power Setting Function (1-2) (3-4) ▲+19V +12V Power Mode Setting Function (1-2) ▲ATX Power AT Power System Reset Function (1-2) ▲System Normal System Reset CRT Power Ctrl Function (1-2) ▲HW BIOS ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 34 CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’. (refer to the jumper shown below) 3. Connect the power cable to the system, and power on the system: in ATX mode: press the power button and it will fail power on in AT mode: turn on system power 4.
  • Page 35 1. Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility. 2. Select the Advanced tab 3. Select Power Configuration COM/VGA Ports and press <Enter> to go to display the available options.
  • Page 36 LCD ID Setting LVDS/TTL Resolution Output Interface Bits Channel (1-2) (3-4) (5-6) (7-8) Single 1024 Single 1366 Single : LCD Panel : VGA Port Single *800 Single 1024 Single CRT only (Pineview CRT only) *Note: specialized for Sharp 12.1” LQ121S1LG41/LQ121S1LG42 panel. 2nd VGA Power Setting VGA port power must be enabled through BIOS/Utility.
  • Page 37 To switch on the power, select "+12V" press <Enter>. Please Save the change by pressing F10.

  • Page 38: C56 Motherboard

    C56 Motherboard 6-3-1 Motherboard Layout...
  • Page 39 6-3-2 Connectors & Functions Connectors Functions LVDS Inverter Connector System FAN Connector LVDS Connector Power LED Connector SATA LED Connector Speaker & MIC Connector SATA Power Connector COM5(Touch) Connector CN10 Printer Port Connector CN11/12 USB Port(Internal) CN13 LAN LED Connector CN14 PS2 Keyboard Connector CN15...
  • Page 40 6-3-3 Jumper Settings Cash Drawer Power Setting Function (1-2) (3-4) ▲+19V +12V Inverter Selection Function (1-2) (3-4) (5-6) ▲LED CCFL COM2 Power Setting Function (1-2) (3-4) ▲ No Power COM2 +5V COM2 +12V ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 41 COM 3 & COM4 Power Setting Function (1-2) (3-4) (5-6) (7-8) ▲COM3 +5V COM3 +12V COM4+ 5V ▲COM4 +12V COM2/COM3/COM4 Power Setting COM2, COM3 and COM4 can be set to provide power to your serial device. The voltage can be set to +5V or 12V by setting jumper JP5 and JP6 on the motherboard.
  • Page 42 LCD ID Setting Panel LVDS Output Resolution Number Bits Channel (1-2) (3-4) (5-6) (7-8) (9-10) Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 600 Single Panel LVDS 1024 x 768 Single...
  • Page 43 2nd VGA Power Setting 1. Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility. 2. Select the Advanced tab. 3. Select VGA/COM Power and LCD Brightness Configuration Ports and press <Enter>...

  • Page 44: Appendix: Driver Installation

    7 Appendix: Driver Installation The shipping package includes a Driver CD. You can find every individual driver and utility that enables you to install the drivers in the Driver CD. Please insert the Driver CD into the drive and double click on the “index.htm” to pick the models.
