  • Page 1 User Manual Version 1.2 January 2013 Point-of-Sale Hardware System...
  • Page 2 Copyright 2013 All Rights Reserved Manual Version 1.2 Part Number: 3LMPP3450412 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS To disconnect the machine from the electrical Power Supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. Read these instructions carefully.

  • Page 4: Legislation And Weee Symbol

    CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. Battery Caution Risk of explosion if battery is replaced by an incorrectly type. Dispose of used battery according to the local disposal instructions.
  • Page 5 should be taken to the waste collection centers for activation of the treatment, collection, recycling and disposal procedure. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

  • Page 6: Revision History

    Revision History Revision Date Description V1.0 October, 2009  Release V1.1 May, 2011  C46 MB added  C56 MB added  C36 MB and C46 MB removed V1.2 January,2013  VFD installation changed  2 installation changed...
  • Page 7 This page is intentionally left blank...

  • Page 8: Table Of Contents

    Table of Contents 1 Package Checklist.........1 1-1 Standard items ..............1 1-2 Optional items ..............2 2 System View ...........3 2-1 Front View ................3 2-2 Side View & Bottom View ..........4 2-3 I/O View................5 3 System Assembly & Disassembly....6 3-1 Replace the HDD ...............

  • Page 9: Package Checklist

    Package Checklist Standard items a. System b. Power adapter c. Power cord d. RJ45 to DB9 cable (x2) e. Driver CD...

  • Page 10: Optional Items

    Optional items a. MSR b. 2-in-1 MSR + iButton c. 2-in-1 MSR + Fingerprint d. 2 display module e. VFD module...

  • Page 11: System View

    System View Front View Description Touch screen MSR/2-in-1 MSR (optional) HDD door Stand Ventilation Power button...

  • Page 12: Side View & Bottom View

    Side View & Bottom View Description Hinge cover System box (motherboard inside)

  • Page 13: I/O View

    I/O View Description Cash drawer port USB (x4) LAN (10/100/1000) COM1, 2, 3, 4 (from left to right) 2nd VGA DC In 19V Power button Parallel port...

  • Page 14: System Assembly & Disassembly

    System Assembly & Disassembly Replace the HDD 1. Remove the screw (x1) to remove the HDD cover. 2. Remove the screw (x1) that secures the HDD to the metal bracket. 3. Disconnect the HDD Cable and take out the HDD.

  • Page 15: Replace The Motherboard

    Replace the Motherboard 1. Turn off the power. 2. Remove the screws (x4) to open the system box. 3. Disconnect all the cables (x5) from the motherboard as the arrows show in the picture. 4. Remove the screws (x5) fixing the motherboard on the motherboard tray 5.

  • Page 16: Stand Disassembly

    Stand Disassembly To remove the stand, you need to disconnect the LCD cable firstly. LCD Module 1. Follow the steps 1 and 2 in Chapter to open the system box to access the motherboard. 2. Find the LCD cable and disconnect it from the motherboard. LCD Module Stand 3.

  • Page 17: Peripheral Installation

    Peripheral Installation MSR installation 1. Remove screws (x2) to open the MSR dummy cover. 2. Fasten the grounding cable (x1) and connect the MSR cable (x1). 3. Insert the MSR module in place. 4. Fasten the screws (x2) on the back to secure the MSR module.

  • Page 18: 2-In-1 Msr + Ibutton Installation

    2-in-1 MSR + iButton Installation 1. Remove screws (x2) to open the MSR dummy cover. 2. Connect the 2-in-1 MSR + iButton cable to the connector on system side. 3. Insert 2-in-1 MSR + iButton module in place and fasten the screws (x2) on the back to secure the module.

  • Page 19: 2-In-1 Msr + Fingerprint Installation

    2-in-1 MSR + Fingerprint Installation 1. Remove screws (x2) to open the MSR dummy cover. 2. Fasten the grounding cable (x1) and connect the 2-in-1 MSR + Fingerprint cable to the connector on system side. 3. Insert 2-in-1 MSR + Fingerprint module in place and fasten the screws (x2) on the back to secure the module.

  • Page 20: Cash Drawer Installation

    Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer. Register Location: 48Ch Attribute: Read / Write Size: 8bit...
  • Page 21 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 22: Vfd Installation

    VFD Installation 1. The package includes a metal plate for assemble the VFD module. Please insert the VFD to the metal plate and fasten screws (x4) on the bottom. 2. Follow steps 1~3 in Chapter 3-1 to take out the HDD. 3.
  • Page 23 4. Install the HDD to the position. 5. Connect the other end of the VFD cable to the USB port on the system.

  • Page 24: Nd Display Installation

    Display Installation 1. The package includes a metal plate for assemble the 2 display module. Please insert the 2 display to the metal plate and fasten screws (x4) on the bottom. 2. Follow steps 1~3 in Chapter 3-1 to take out the HDD. 3.
  • Page 25 8.4’ 2 display 15.1’ 2 display 4. Install the HDD to the position. 5. Connect the other end of the 2 display cable to the VGA port on the system.

  • Page 26: Specification

    Specification POS 345 Model Name Motherboard CPU Support Intel Cedarview D2550 dual-core 1.86GHz, L2 1M Chipset CPU integrated graphic + NM10 System Memory 1 x DDR3 SO-DIMM up to 4GB, 1066MHz Graphic Memory Intel GMA 3650 (Gfx frequency up to 640MHz), DX9...
  • Page 27 POS 345 Model Name MSR (USB) + iButton (USB) 2-in-1 MSR MSR (USB) + Fingerprint (USB) Customer Display 2 x 20 VFD customer display (COM) Second Display 8.4" /15.1" LCD display Environment EMC & Safety FCC/CE Class A, LVD Operating Temperature...

  • Page 28: Jumper Settings

    Jumper Setting C56 Motherboard Layout...

  • Page 29: Connectors & Functions

    Connectors & Functions Connector Function LVDS Inverter Connector System FAN Connector LVDS Connector Power LED Connector SATA LED Connector Speaker & MIC Connector SATA Power Connector COM5(Touch) Connector CN10 Printer Port Connector CN11/12 USB Port(Internal) CN13 LAN LED Connector CN14 PS2 Keyboard Connector CN15 Card Reader Connector(COM6)

  • Page 30: Jumper Settings

    Jumper Setting Cash Drawer Power Setting Function (1-2) (3-4) ▲+19V +12V Inverter Selection Function (1-2) (3-4) (5-6) ▲LED CCFL COM2 Power Setting Function (1-2) (3-4) ▲ No Power COM2 +5V COM2 +12V ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 31 COM 3 & COM4 Power Setting Function (1-2) (3-4) (5-6) (7-8) ▲COM3 +5V COM3 +12V COM4+ 5V ▲COM4 +12V COM2/COM3/COM4 Power Setting COM2, COM3 and COM4 can be set to provide power to your serial device. The voltage can be set to +5V or 12V by setting jumper JP5 and JP6 on the motherboard.
  • Page 32 LCD ID Setting Panel LVDS Output Resolution Number Bits Channel (1-2) (3-4) (5-6) (7-8) (9-10) Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 600 Single Panel LVDS 1024 x 768 Single...
  • Page 33 2nd VGA Power Setting 1. Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility. 2. Select the Advanced tab. 3. Select VGA/COM Power and LCD Brightness Configuration Ports and press <Enter>...

  • Page 34: Appendix

    Appendix Drivers Installation: The shipping package includes a Driver CD. You can find every individual driver and utility that enables you to install the drivers in the Driver CD. Please insert the Driver CD into the drive and double click on the “index.htm” to pick up the models.
