ISOFIX Base.
User Guide
ECE R44/04 ISOFIX
Class E
Group 0+
Up to 13kg
Language: English
Important – Keep these instructions
for future reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISOFIX Base and is the answer not in the manual?

Questions and answers

Summary of Contents for doona ISOFIX Base

  • Page 1 ISOFIX Base. User Guide ECE R44/04 ISOFIX Class E Group 0+ Up to 13kg Language: English Important – Keep these instructions for future reference...

  • Page 2: Table Of Contents

    Use in the vehicle ................12 Installing the Doona ISOFIX Base in the vehicle ......15 5.1. Securing the Doona ISOFIX Base in your vehicle ....15 5.2. Removing the Doona ISOFIX Base from your vehicle....18 Installing and removing the Doona Car Seat from the Doona ISOFIX Base ..............20...
  • Page 3 6.1. Securing the Doona Car Seat on the Doona ISOFIX Base ..................20 6.2 Removing the Doona Car Seat from the Doona ISOFIX Base ..................23 Car fitting List ..................25 Care instructions ................26 8.1. Cleaning ..................26 Two-year warranty ................27 Warranty Card ..................29...
  • Page 4 In order to protect your baby, and allow easy use of the Doona inside and outside of the car, the Doona ISOFIX Base must always be used and installed as described in these instructions. Important – Keep these instructions for future reference. Read these instructions carefully, your child’s safety may be affected if you do not...

  • Page 5: Vital Information / Warnings

    WARNING! Use original accessories and manufacturer approved parts only. Do not make any alterations or additions to the Doona ISOFIX Base. WARNING! Always check car fitting list before installation. WARNING! In a case of a car accident violent stresses occur.
  • Page 6 WARNING! Any luggage or other objects liable to cause injuries in the event of a collision shall be properly secured. The Doona ISOFIX Base must always be secured with the support leg, even when not in use. WARNING!
  • Page 7 WARNING! Do not use the Doona ISOFIX Base in seating positions where there is an airbag installed. WARNING! It is recommended to cover up the Doona ISOFIX Base when the car is parked in the sun, as plastic and metal parts may become extremely hot.

  • Page 8: Suitability

    0 2 / Suitability. The Doona ISOFIX Base is compatible with the Doona Car Seat, and is intended for Rear-Facing use only. Group: 0+ Weight: Up to 13 kg Safety Information: WARNING! Do not use the Doona ISOFIX Base in seating positions where there is an airbag installed.

  • Page 9: Product Overview

    0 3/ Product overview. P R O D U CT O V E RV IE W...

  • Page 10: Use In The Vehicle

    For seats with side airbags, please observe the instructions in your vehicle owner’s manual. The Doona ISOFIX Base may be used only on a forward facing seat equipped with ISOFIX anchor points. Either on the passenger seat or on the back seat, but it should always face backwards.
  • Page 11 User Guide. The Doona ISOFIX Base is approved for use with the Doona Car Seat. The Doona ISOFIX Base is compatible for use in cars with approved ISOFIX anchor points (See chapter 7 for Car fitting list).
  • Page 12 3-point belt without a base, refer to the user guide provided with the Doona Car Seat. Fastening the Doona Car Seat to the vehicle using the Doona ISOFIX Base is based on semi-universal approval. The seat may only be used with a base in the vehicles detailed in the list of approved vehicle types enclosed with the base.

  • Page 13: Installing The Doona Isofix Base In The Vehicle

    (subject to the existence of ISOFIX anchors in the front seat). Should you decide to install your Doona ISOFIX Base in the front, make sure to disable the Airbag system. IMPORTANT! Secure any fold down seats.
  • Page 14 (#5) facing the back of the vehicle›s seat. Align the ISOFIX Connectors (#5) with the vehicle ISOFIX low anchors (#11). Push the Doona ISOFIX Base from the top of the support leg until the base clicks and locks with both connectors.
  • Page 15 I N S T A L L I NG T HE D O O N A IS O F I X B AS E IN T HE V E H ICLE...

  • Page 16: Removing The Doona Isofix Base From Your Vehicle

    Base from your vehicle Step 1: Make sure the Doona Infant Car Seat is not connected to the ISOFIX Base. In case it is connected, please remove it first. Detailed description for removing the Doona Infant Car Seat from the ISOFIX Base can be found in chapter 6.2.
  • Page 17 I N S T A L L I NG T HE D O O N A IS O F I X B AS E IN T HE V E H ICLE...

  • Page 18: Securing The Doona Car Seat On The Doona Isofix Base

    After securing the Doona ISOFIX Base in your vehicle (See chapter 5 for instructions), you may now easily connect and remove the Doona Car Seat from your vehicle. To do so, follow the steps below: IMPOTRANT! Before installing the Doona car seat on the Doona ISOFIX Base, make sure that the Doona release button (#3) is pressed in, and the Doona color indicator (#4) is red.
  • Page 19 Seat and adjusting the handle, please refer to the Doona Car Seat User Guide. Step 2: Position the Doona Car Seat and align its 2 metal bars (See image below) above the Doona anchor points (#1) in the Doona ISOFIX Base. Slide the Doona Car Seat into the Doona anchor points (#1) until you hear a ‘click’...
  • Page 20 THE N EX T G EN ER AT I O N C A R SEA T / IS O FI X B A S E...

  • Page 21: Removing The Doona Car Seat From The Doona Isofix Base

    Doona toward your body until it is released from the Doona anchor points (#1).Once the Doona Car Seat is disconnected from the base, lift the Doona and place it outside of the car. Step 3: Unfold the Doona Car Seat wheels, rotate and extend the handle to ‘stroller mode’...
  • Page 22 THE N EX T G EN ER AT I O N C A R SEA T / IS O FI X B A S E...

  • Page 23: Car Fitting List

    0 7/ Car fitting list. To obtain further information on fitting the Doona ISOFIX Base in specific cars, please contact us at: info@simpleparenting.co or visit our website: www.simpleparenting.co CA R F IT T IN G LIS T...

  • Page 24: Care Instructions

    Base. It is also recommended to remove the Doona ISOFIX Base from the car in order to clean it properly. To clean the ISOFIX Base, sponge clean or rinse using warm water, soap and a rag. DO NOT use any solvents or lubrication. Using anything other than soapy water can cause the moving parts to malfunction.

  • Page 25: Two-Year Warranty

    European safety standards and regulations, and it meets the highest standards of quality. For the Doona ISOFIX Base we provide a 2-year warranty against manufacturing or material defects. The warranty period is effective from the day of purchase. As proof of purchase we ask that you fill out the Warranty Card and retain it for the whole term of the warranty period, together with your sales receipt.
  • Page 26 • When the product has been used for a purpose other than that specified in this user manual. In the event of a warranty claim, please contact us directly at: info@simpleparenting.co THE N EX T G EN ER AT I O N C A R SEA T / IS O FI X B A S E...

  • Page 27: Warranty Card

    Warranty card: Name: Address: Post code: City/Town: State: Country: Telephone no. (including area code): E-mail address: Doona ISOFIX Base serial no. : Store where product was purchased: Date of purchase: W A R R AN T Y C A RD...
  • Page 28 simpleparenting.co info@simpleparenting.co...
