Summary of Contents for MCLaren Sound Systems MLX-23
- Page 1 3 WAY ELECTRONIC CROSSOVER MLX-23 Owner s Manual Installation Guide...
- Page 2 The quality of installation may affect the performance and reliability of your Mc Laren crossover points for the front /highpass crossover. crossover MLX-23. Please take a few minutes to read the manual carefully. The time you X1 position: 60 to 600Hz X10 position: 600 to 6KHz spend on installation will prove to be worthwhile when it's time to listen to your investment.
- Page 3 Now it's time to do the final connections, the outputs. Be careful you link the outputs, via RCA patch MOUNTING cables, to the proper amplifier(s). Use the diagrams on the following pages to determine the correct Find a sturdy, secure area to mount the MLX 23. Be sure it is accessible, but not out in the open system layout.
- Page 4 SYSTEM VARIATIONS TROUBLE SHOOTING GUIDE 2 CHANNELS 2 WAY SYSTEM FRONT/REAR NON FADE 2CH/4CH Front/HP Rear/Mid HP/BP Front tweeters 1. NOT WORKING Check all fuses. Check all power (positive,remote) wire connections. Rear woofers Front Output Check that ground wire is properly connected. 2.
