Interlink electronics VersaPoint User Manual

Rechargeable wireless desktop suite
Hide thumbs Also See for VersaPoint:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Troubleshooting Manual
Users Manual
VersaPoint Rechargeable Wireless Desktop Suite

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VersaPoint and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Interlink electronics VersaPoint

Summary of Contents for Interlink electronics VersaPoint

  • Page 1 Users Manual VersaPoint Rechargeable Wireless Desktop Suite...
  • Page 2 Canada technical specifications were met. Declaration of conformity Hereby, Interlink Electronics, Inc. declares that this VersaPoint Wireless Desktop Suite is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/ EC. All trademarks and registered trademarks mentioned in this document are the property of their respective owners.

  • Page 3: System Requirements

    System Requirements Hardware: Desktop or notebook system with 1 available USB 1.1 or 2.0 port Operating System: Windows 2000, XP or Vista Package Contents • 2.4GHz rechargeable keyboard • 2 x AAA rechargeable Ni-MH batteries (for the keyboard) • 2.4GHz rechargeable mouse •...

  • Page 4: Installing The Mouse

    Make sure the positive (+) and negative (-) ends of the batteries match the polarity markings inside the battery compartment. • Snap the battery cover back into position. Installing the Mouse Page 2...

  • Page 5: Charging The Batteries

    • Remove the battery cover located at the bottom of the mouse. • Insert the two supplied AA rechargeable Ni-MH batteries (included in the package) to the battery slots. Make sure the positive (+) and negative (-) ends of the batteries match the polarity markings inside the battery compartment.
  • Page 6 • Connect the charging cable (included in the box) to the USB RF receiver’s charging port and the mouse. (Repeat this step later for the keyboard.) • Plug the receiver’s USB connector to your computer’s available USB port. • The initial charging process may take up to 8 hours. Subsequent recharge may require less time depending on the level of residual power in the batteries.
  • Page 7 Make sure the computer’s power management is set to disable hibernation mode while the products are being charged. (Go to Control Panel, Power Options, select “Hibernate” from the tabs and uncheck the box marked “Enable Hibernation.) Connecting the Keyboard & Mouse to the Computer •...
  • Page 8 function correctly, i.e. no cursor movements or sluggish cursor movements, there may be other wireless devices in the vicinity operating in the same radio frequency channel. The keyboard and mouse can be easily reset to another channel. • To connect the mouse to your system, press the connect button located at the bottom of the RF receiver (1) while it’s connected to the computer’s USB port, and press the connect button located at the bottom of the mouse (2).

  • Page 9: Operating Instructions

    Operating Instructions Using the Keyboard • This keyboard features the standard 104-key QWERTY configuration plus 15 convenient one-touch hot keys and a volume control wheel. Page 7...
  • Page 10 Page 8...
  • Page 11 Using the Mouse • This mouse features 5 pre-programmed buttons (including the scroll wheel as the 3rd button.) Page 9...
  • Page 12 Using the RF Receiver • This USB RF receiver features 3 LED indicators for your convenience. Operating Tips & Trouble Shooting • Make sure the mouse is turned on by checking the on/off switch located at the bottom of the mouse before using it. •...
  • Page 13 will not be in use for awhile. If you will not use the keyboard and mouse for a long period of time remove the batteries from the respective battery compartments. • When the keyboard and/or mouse behave erratically it may be an indication that the battery power is low. Follow the instructions in Charging the Batteries section to recharge the batteries if necessary.

  • Page 14: Warranty

    Keyboard and Mouse to the Computer section to reconnect the devices. Warranty INTERLINK warrants to the original end-user purchaser of the Product (“you”) that the Product, excluding batteries, will be free from defects in materials or workmanship under normal use and service for one-year from date of purchase.

  • Page 15: Product Support

    Product Support For technical support please contact Interlink Electronics at http://www.interlinkelectronics.com/support Page 13...
  • Page 16 Thank you for purchasing the Interlink VersaPoint Wireless Desktop Suite. We know you had other choices and we appreciate that you chose Interlink Electronics for your product needs. So that we may better serve you in the future, please register online at www.interlinkelec.com/register.
