Mobility
Works.......
®
Brumby
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Brumby and is the answer not in the manual?

Questions and answers

Related Manuals for Mobility Works Brumby

Summary of Contents for Mobility Works Brumby

  • Page 1 Mobility Works……. ® Brumby OWNER’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. PREFACE …………………………………………………………………………………………… 2 2. SAFETY NOTICE …………………………………………………………………………………… 4 2.1 Before Driving 2.2 Whilst Driving 2.3 Labelling 2.4 Electromagnetic Interference 3. PARTS INTRODUCTION ………………………………………………………………………… 10 4. OPERATION ……………………………………………………………………………………… 4.1 Control Panel 4.2 How to Operate Your Scooter 5.

  • Page 3: Preface

    As designs change some illustrations and pictures in the manual may not correspond to the vehicle that you purchased. We reserve the right to make design modifications. The Brumby medium scooter designed and manufactured to provide a solution for some mobility requirements, they are easy to manoeuvre and are suitable for indoor and some outdoor applications.

  • Page 4: Safety Notice

    2. SAFETY NOTICE 2.1 BEFORE DRIVING The user needs to be familiar with the use and operation of this vehicle before driving. Therefore, please follow the recommendations in this safety notice.  The same traffic rules apply to the user of this vehicle as apply to pedestrians. ...
  • Page 5 canals which not guarded by any fence or hedge. Keep away from places where you might get the wheels stuck.  Do not drive at night or when it is raining, snowing, misty, or windy.  Do not drive your vehicle in an “S” pattern or make erratic turnings. ...

  • Page 6: Labelling

    WARNING：  Do not set in freewheel mode when driving on a gradient.  Always re-engage the freewheel device into drive mode before use. Failure to do so may result in injury.  The Maximum User Weight Limit is 115kg. Overloading past the weight limit may lead to damage of your scooter or cause it to malfunction and will endanger your safety.
  • Page 7 2.4.1 ELECTROMAGNETIC INTERFERENCE (EMI) FROM RADIO WAVE SOURCES Powered scooters may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and mobile phones. The interference (from radio wave sources) can cause the powered scooter to release its brakes, move by itself, or move in unintended directions.

  • Page 8: Important Information

    the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the control system of the scooter while using these devices. This can affect powered scooter movement and braking. Therefore, the warnings listed below are recommended to prevent possible interference with the control system of the powered scooter.

  • Page 9: Parts Introduction

    3. PARTS INTRODUCTION Parts Description : 1. Rearview mirror 8. Front basket 2. Control panel 9. Tiller adjustment knob 3. Freewheel lever 10. Seat post 4. Anti-tip wheel 11. Charger socket 5. Seat 12. Circuit breaker 6. Arm rest 13. Anti-tip wheel 7.

  • Page 10: Operation

    4.OPERATION 4.1 CONTROL PANEL Two control panels available:touch control panel and press-button panel, see pictures below. 1. Rearview mirror 5. Push 9. Wigwag Paddle 2. Speed control 6. Hazard warning switch 10.Headlight 3. Key Ignition 11. LED indicator 7. Horn Button 4.
  • Page 11 Pull the left-hand side of the wigwag paddle forward with your left hand and the scooter will move backward, emitting an audible reversing alarm. To brake, release the wigwag paddle which will return to neutral and activate the electromagnetic brake automatically.
  • Page 12  Lift up the lever to adjust seat back angle 90degree 100degree Lever Lever Adjusting seat back angle Attention： Return the seat to the forward position before driving.   Adjusting the Seat Height 1. Remove the seat from your scooter 2.
  • Page 13 Suggestion： 1. You should recharge the batteries after each time the vehicle is used to ensure maximum range. The batteries should be charged up at least once a week even if the scooter is not used. 2. After charging or replacing a new battery, drive the vehicle for 2-3 minutes to make sure the battery capacity is sufficient.
  • Page 14 Warning： Never operate the freewheel lever while seated on the scooter or on an incline.  Tiller Adjustment The tiller can be adjusted in to many different positions to suit each driver. The tiller can be adjusted by following the steps below： Step 1: Loosen the knob (as being performed in the photo by the lower hand) so the tiller can move.
  • Page 15 2. Do not turn the power switch to OFF whilst driving as this will lead to an emergency stop and possible risk of accident and injury. 3. Do not set to the highest speeds whilst driving indoors. 4. Do not adjust the speed dial whilst driving, a sudden change in speed may cause danger to you and others, and may cause damage to your scooter.

  • Page 16: Battery Charging And Care

    breaker has tripped, the button will be protruding by 7mm. To reset the circuit breaker,push the button in and the scooter should function as normal. 6.BATTERY CHARGING AND CARE 6.1 CHARGING THE BATTERY Follow the procedure below step by step: 1.

  • Page 17: Charger

    7. The batteries carry a twelve-month manufacturer's warranty. This warranty only covers issues relating to manufacturing faults, and not faults relating to failure to recharge the batteries as instructed above. Attention: Please follow the rules below to avoid accidents while charging. 1.

  • Page 18: Battery

    6.3 BATTERY Do not expose the battery to temperatures below – 10°C or above 50°C when charging or storing the  vehicle. Being out of the above temperature range can cause the battery either to freeze or over heat. This will damage the batteries and shorten their life.

  • Page 19: Inspection And Maintenance

    7.INSPECTION AND MAINTENANCE 7.1 DAILY CHECKING Check the following items before driving. If you find anything abnormal, contact your dealer for further inspection or advice before using the scooter. Item Inspection Tiller Is there any looseness? Can it turn left and right smoothly ? Speed Control Dial Can it be adjusted freely and does it function well? ...

  • Page 20: Regular Checking Record

    7.2 REGULAR CHECKING RECORD To make sure your scooter is correctly serviced, please regularly check it, if you detect any faulty, please contact your dealer timely. Below check record list (for reference). Suggestion： Even if you do not use the vehicle for a long time it should still be serviced regularly. 7.3 BATTERY, FUSE AND TYRE ...

  • Page 21: Maintenance

     Tyres The condition of the tyres depends on how you drive and use your scooter. Please check the tread depth and air pressure regularly. Replace the tyres when the tread depth is less than 0.5mm. Attention： 1. When tread depth is below 0.5mm it can easily lead to vehicle slippage, making braking distances longer.

  • Page 22: Storage

    7.5 STORAGE Ensure the scooter is stored under the following conditions:  Ensure the seat is set in the ‘forward’ position;  Ensure the scooter is switched off;  Ensure the charger is disconnected when not in use. Suggestion： Please store the scooter in an environment where it is out of direct sunlight or damp. When storing for a long time, charge the battery to full power and then disconnect the battery terminal.

  • Page 23: Specification

    The seat moves whilst in use Seat not locked in position Slowly rotate the seat until it drops in to place and is secure The tiller appears loose Tiller adjustment knob loose Tighten the tiller adjustment knob Involuntary horn sounds There is a fault on the scooter Ensure the wigwag paddle is released and switch the scooter...

  • Page 24: Warranty

    Third year: 35% replacement of parts cost One-Year Limited Warranty: For one year from the date of purchase, Mobility Works will repair or replace, at our option to the original purchaser free of charge any part found upon examination by an authorized representative of Mobility Works to be defective in material and/or workmanship.
  • Page 25 Thomastown VIC 3074 Phone 1300 23 66 24 www.mobilityworks.net.au Scooter Manufactured By Ningbo Jiahe Special Vehicle Co. Ltd. Ningbo, Zhejang China Sold to Name ________________________________________ Address ________________________________________ ________________________________________ ________________________________________ Date ________________________________________ Model Brumby ( JH07-558A-B ) 500WPG70A44AH Serial No ________________________________________...
