Code Soft TCP-9015 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Version 1.1 June 2011
Point-of-Sale
Hardware System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCP-9015 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Code Soft TCP-9015

Summary of Contents for Code Soft TCP-9015

  • Page 1 User Manual Version 1.1 June 2011 Point-of-Sale Hardware System...
  • Page 2 Copyright 2011 All Rights Reserved Manual Version 1.1 Part Number: 3LMPP3350311 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS To disconnect the machine from the electrical Power Supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. Read these instructions carefully.

  • Page 4: Legislation And Weee Symbol

    CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. Battery Caution Risk of explosion if battery is replaced by an incorrectly type. Dispose of used battery according to the local disposal instructions.
  • Page 5 The crossed dustbin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life. Instead, the device should be taken to the waste collection centers for activation of the treatment, collection, recycling and disposal procedure.

  • Page 6: Revision History

    Revision History Changes to the original user manual are listed below: Revision Date Description V1.0 Sep, 2009  Release V1.1 June, 2011  C46 MB added...

  • Page 7: Table Of Contents

    Table Contents 1 Item Checklist..........1 Standard Items ..............1 Optional Items ..............2 2 System View...........3 Front View ................3 Rear View................4 Bottom View ................. 5 I/O View................6 3 Peripheral Installation........7 MSR & Fingerprint..............7 VFD ..................8 Second Display ..............
  • Page 8 6 Jumper Settings .......... 23 C36A Motherboard ............. 23 C46 Motherboard ............... 28 Appendix............37...

  • Page 9: Item Checklist

    Item Checklist Take the system unit out of the carton. Remove the unit from the carton by holding it by the foam inserts. The following contents should be found in the carton: Standard Items a. System b. Power adapter (65W) c.

  • Page 10: Optional Items

    Optional Items a. MSR module b. Fingerprint c. VFD module d. Second display e. Wall mount kit f. Wireless LAN card g. pSSD card module...

  • Page 11: System View

    System View Front View Number Description Touch Screen MSR Module (Option) Power Button Hard Disk Drive Cover...

  • Page 12: Rear View

    Rear View Number Description VFD cover (for VFD & Second display installation) Stand/Wall mount kit installing place Stand Cable management outlet...

  • Page 13: Bottom View

    Bottom View Number Description Stand Pad Easy-Service Retaining Bracket for Power Adapter...

  • Page 14: I/O View

    I/O View Number Description E-SATA connector Power Jack for HDD Cash Drawer USB x 4 COM1~4 (from left to right) Power Jack for System Power Button Note: The maximum current that can be drawn from each COM port is 500 mA.

  • Page 15: Peripheral Installation

    Peripheral Installation The peripheral and modules units provided are tested and can be supplied at your request. MSR & Fingerprint Components of MSR Kit: Screws Grounding Slide the MSR into the right position of the System. Fasten the screws (x2) and grounding cable (x1). * The fingerprint scanner can be installed in the same way.

  • Page 16: Vfd

    Components of VFD Kit: Plastic bracket Metal Bracket Screws Remove the screws (x2) and slide the VFD Cover outward. Positioning the VFD metal bracket onto the rear side of the VFD module and fasten the screws (x2). Positioning the plastic bracket onto the metal bracket as the direction and steps of arrows show.
  • Page 17 Fasten the screw (x1) to fix the plastic bracket to the metal bracket and VFD module. Slide the MSR module with bracket into the VFD socket. Fix the MSR module by fasten the screws (x2) as circles show. Connect the VFD cable to the VFD Module. Connect to the COM4 port of the System.

  • Page 18: Second Display

    Second Display To install the Second Display, please open the VFD cover first (Chapter 3-2-1). Components of Second Display Kit with power adapter: Plastic Bracket Metal Bracket Screw Power Adapter Screws Second Display Fix the parts of Second Display modules as steps ...
  • Page 19 Fasten the screw (x1) to fix the platic bracket and Second Display module with metal bracket. Slide the Second Display Module into the slot. Fasten the scrws (x2) to fix the Second Display moudle with the System. Connect the VGA cable to the Second Display Module and the System. Finish.

  • Page 20: Cash Drawer

    Cash Drawer You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer. Register Location: 48Ch Attribute: Read / Write Size: 8bit...
  • Page 21 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 22: Wall Mount Kit

    Wall Mount Kit Before installing the Wall Mount Kit, please remove the stand first if needed. (See Chapter 4-3 for removing the stand) (Parts of Wall Mount Kit) (Place to install) a. Wall Plate b. Monitor plate Components of VESA-standard wall mount kit includes follows. a.

  • Page 23: System Assembly & Disassembly

    System Assembly & Disassembly Replace the HDD Unfasten the screw (x1). Slide out the HDD Cover. Unfasten the screws (x4) Separate the HDD from the metal bracket.

  • Page 24: Replace The Power Adapter

    Replace the Power Adapter Release the thumb screw to seperate the retaining metal bracket from the stand and take out the power adapter. Remove the System Stand Release the screws (x2) that fasten the stand and the system. Release the screws (x4) that fasten the plastic VESA mounting plate and the LCD rear cover.

  • Page 25: Remove The Lcd Rear Cover & The System Box

    Remove the LCD Rear Cover & the System Box Remove the system stand (Chapter 4-3). Unfasten the screws (x7) to separate the LCD Rear Cover. After remove the LCD Rear Cover, you will see the “system box” inside. Inside of the system box is the motherboard place. Unfasten the scrws (x4) at both sides of the system box to uncover the Motherboard.

  • Page 26: Replace The Motherboard

    Replace the Motherboard To open the LCD rear cover & system box first as steps in Chapter 4-4. Unfasten the screws (x5) on the Motherboard. Unfasten the hex screws (x2) to release the I/O metal panel from the Motherboard. Replace the Inverter Board To open the LCD rear cover first (see Chapter 4-4).

  • Page 27: Replace The Elo Touch Control Board

    Replace the ELO Touch Control Board Open the LCD rear cover first (see Chapter 4-4). Unfasten the screws (x2). Release the connectors (x2).

  • Page 28: Replace The Lcd Panel

    Replace the LCD Panel Touch LCD Bezel Remove the LCD rear Cover (Chapter 4-4) Remove the system box and release all the connectors on the Motherboard (Chapter 4-4) Release inverter cables & touch cables (Chapter 4-6 and 4-7) Remove the screws (x9) to separate the Touch LCD bezel from the LCD Panel Module.

  • Page 29: Specification

    Specification Model Name POS335 Motherboard Intel Atom N270 processors 1.6G, L2 Intel PineTrial D525 Duo Core 1.8G, CPU Support 512K FSB 533MHz L2 1M, FSB667 / 800MHz Chipset Intel 945GSE Express chipset + ICH7M CPU integrated graphic + ICH8M System Memory 1 x DDR2 SO-DIMM socket up to 2GB 1 x DDR3 SO-DIMM socket up to 2GB Intel GMA 950 share system memory...
  • Page 30 Power Power Adapter 65W, 19V/3.4A Control / Indicator Power Button Indicator LED Peripheral MSR module MSR (USB) Fingerprint Fingerprint (USB) Customer display 2 x 20 VFD customer display (COM) Second display 8.4” 2nd display without touch Communication Wireless LAN 802.11 b/g/n wireless LAN card & antenna (Option) Environment EMC &...

  • Page 31: Jumper Settings

    Jumper Settings C36A Motherboard 6-1-1 Motherboard Layout...
  • Page 32 6-1-2 Connectors & Functions Connector Purpose BAT3 CMOS Battery Base ( Use CR2023) Speaker & MIC Connector Power Connector For HDD USB5 USB7 Card Reader Connector CN12 IrDA Connector CN13 Inverter Connector CN15 Power LED CN16 LCD Interface Connector CN21 Internal Power On Switch Connector CN22 5 Wire Touch...
  • Page 33 6-1-3 Jumper Settings Cash Drawer Power Settings Function (1-2) (3-4) +12V ▲+19V Power Mode Settings Function (1-2) ▲ATX Power AT Power CMOS Operation Mode Function (1-2) ▲CMOS Normal CMOS Reset System Reset Settings: Function (1-2) ▲Normal Reset ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 34 COM3 & COM4 Power Settings Function (1-2) (3-4) (5-6) (7-8) (9-10) (11-12) COM3 Pin10 ▲+5V +12V COM4 Pin10 ▲+12V VGA Power Settings Function (1-2) ▲No Power +12V ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 35 LCD ID Settings Panel LVDS Resolution Number Bits Channel (1-2) (3-4) (5-6) (7-8) 1024 Single 1280 1024 Dual Single 1024 Single ▲ = Manufacturer Default Setting OPEN SHORT...

  • Page 36: C46 Motherboard

    C46 Motherboard 6-2-1 Motherboard Layout...
  • Page 37 6-2-2 Connectors & Functions Connector Function Speaker & MIC CONN SATA Power For external Touch Card reader CN12 PS2 Keyboard CN13 HDD LED CONN CN16 Inverter CN17 TUOCH CN18 Power LED CONN CN19 LVDS (24bit) CN20 SYSTEM FAN CN21 DC-JACK CN22 POWER BOTTOM CONN CN25...
  • Page 38 6-2-3 Jumper Settings Cash Drawer Power Setting Function (1-2) (3-4) ▲19V Power Mode Setting Function (1-2) ▲ATX Power AT Power ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 39 CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’. (refer to the jumper shown below) 3. Connect the power cable to the system, and power on the system: in ATX mode: press the power button and it will fail power on in AT mode: turn on system power 4.
  • Page 40 System Reset Function (1-2) ▲System Normal System Reset CRT Power Ctrl Function (1-2) ▲HW BIOS ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 41 Inverter Selection Function JP10 (1-2) (3-4) (5-6) ▲CCFL COM3 & COM4 Power Setting COM3 and COM4 can be set to provide power to your serial device. The voltage can be set to +5V or 12V by setting jumper JP9 on the motherboard. When enabled, the power is available on pin 10 of the RJ45 serial connector.
  • Page 42 COM Power Setting Function (1-2) (3-4) (5-6) (7-8) ▲COM3 5V COM3 12V COM4 5V ▲COM4 12V ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 43 LCD ID Setting LVDS/TTL Resolution Output Interface Bits Channel (1-2) (3-4) (5-6) (7-8) Single 1024 Single 1366 Single : LCD Panel : VGA Port Single *800 Single 1024 Single CRT only (Pineview CRT only) *Note: specialized for Sharp 12.1” LQ121S1LG41/LQ121S1LG42 panel.
  • Page 44 2nd VGA Power Setting VGA port power must be on through BIOS/Utility for default is “No Power“ Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility. Select the Advanced tab Select "Power Configuration COM/VGA Ports"...

  • Page 45: Appendix

    Appendix Drivers Installation: The shipping package includes a Driver CD. You can find every individual driver and utility that enables you to install the drivers in the Driver CD. Please insert the Driver CD into the drive and double click on the “index.htm” to pick up the models.
