  • Page 1 User Manual Revision v1.1 Aug. 2010 Point-Of-Sale Monitor...
  • Page 2 Copyright 2010 August All Rights Reserved Manual Version 1.1 Part Number: 3LMPP1300111 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 3 Safety IMPORTANT SAFETY INSTRUCTIONS To disconnect the machine from the electrical Power Supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. Read these instructions carefully.
  • Page 4 CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components.
  • Page 5 Revision History Changes to the original user manual are listed below: Revision Date Description V1.0 Mar. 2010  Release  MB version change V1.1 Aug. 2010 Add Fingerprint Scanner to  optional items...

  • Page 6: Table Of Contents

    Table Contents 1 Package Checklist ........1 Standard Items ..............1 Optional Items ..............2 2 System View..........3 Front View ................3 Rear View................4 Bottom View ................. 5 I/O View................6 3 Peripheral Installation ......7 MSR & Fingerprint Scanner ..........7 VFD ..................

  • Page 7: Package Checklist

    Package Checklist Take the system unit out of the carton. Remove the unit from the carton by holding it by the foam inserts. The following contents should be found in the carton: Standard Items a. Monitor b. Driver CD c. Power Adapter (36W) d.

  • Page 8: Optional Items

    Optional Items a. MSR Module b. VFD Module c. Wall Mount Kit d. Fingerprint (either choose W/MSR module)

  • Page 9: System View

    System View Front View System Overview table -1 Number Component Touch Screen MSR (Optional) OSD Button for OSD menu selection From left to right button: Stand Hole for cable management...

  • Page 10: Rear View

    Rear View System Overview table -2 Number Component VFD Module (Optional) Stand (with cable management and power adapter bracket) Cable Outlet VFD Cover (VFD module installation location) VESA hole for stand and wall-mount kit installation...

  • Page 11: Bottom View

    Bottom View System Overview table -3 Number Component Easy-Service Retaining Bracket for Power Adapter Rubber feet...

  • Page 12: I/O View

    I/O View System Overview table -4 Number Component USB (to Device) USB IN (from PC) VGA IN COM IN COM (can be adjusted with 12V) 12V IN...

  • Page 13: Peripheral Installation

    Peripheral Installation The peripheral and modules units provided are tested and can be supplied at your request. MSR & Fingerprint Scanner Components of MSR Kit: Screws Grounding Slide the MSR into the right position of the System. Fasten the screws (x2) and grounding cable (x1). * The fingerprint scanner can be installed in the same way.

  • Page 14: Vfd

    Components of VFD Kit: Plastic bracket Metal Bracket Screws Unfasten the screws (x2) and slide the VFD Cover outward. ❶ ❷ Position the VFD metal bracket onto the rear side of the VFD module and fasten the screws (x4). Position the plastic bracket on the metal bracket as shown in the images above.
  • Page 15 Fasten the screw (x1) to attach the plastic bracket to the metal bracket and VFD module. Slide the VFD module with bracket into the VFD socket. Attach the VFD module by fastening the screws (x2) as shown. Connect the VFD’s RJ45 to the VFD Module. Connect the other end of the VFD Cable to the Touch Screen Monitor.

  • Page 16: Wall Mount Kit

    Wall Mount Kit Before installing the Wall Mount Kit, please remove the stand first. (See Chapter 4-1) (Parts of Wall Mount Kit) (Location to install) a. Wall Plate b. Monitor plate VESA Wall Mount Kit includes the following: a. Wall-mount plate b.
  • Page 17 Mount part “a” to the wall in your desired location. Align the hooks of the monitor plate with the keyholes of the wall plate and slide the monitor into place. Tighten the thumb screw (x1).

  • Page 18: System Assembly & Disassembly

    System Assembly & Disassembly Remove the System Stand Remove the screws (x2) that secure the stand to the system. Remove the screws (x4) that secure the VESA mount to the monitor. Remove the VESA bracket.

  • Page 19: Remove The Lcd Rear Cover & The Emi Cover

    Remove the LCD Rear Cover & the EMI Cover EMI Cover LCD Rear Cover LCD Chassis Remove the stand (Chapter 4-1). Unfasten the screws (x7) to remove the LCD Rear Cover. Unfasten the scrws (x5) that fixing the EMI cover to the LCD chassis. Disconnect the hex screws (x4) on the I/O panel and remove the EMI Cover.

  • Page 20: Replace The Power Adapter

    Replace the Power Adapter Release the thumb screw to seperate the retaining metal bracket from the stand and take out the power adapter. Replace the AD Board Remove the stand (Chapter 4-1). Remove the LCD rear cover & the EMI cover (Chapter 4-2). Disconnect all the cables connecting to the AD board (including touch, LCD, OSD, inverter cables and etc.

  • Page 21: Replace The Inverter Board

    Replace the Inverter Board Remove the stand (Chapter 4-1). Remove the LCD rear cover (Chapter 4-2). Disconnect the cables (x3) from the inverter board. Unfasten the screw (x2). Replace the LCD Front Bezel Remove the stand (Chapter 4-1). Remove the LCD rear cover & the EMI cover (Chapter 4-2). Disconnect the touch cable (x1).

  • Page 22: Specification

    Specification AD board LCD Panel Panel Size 15" 17" Brightness 250nits 300~380nits Resolution 1024 x 768 1280 x 1024 Touch Resistive Tilt Angle 4° ~ 90° External I/O Ports 1 x USB 2.0 (Type A), 1 x USB 2.0 (Type B to PC) Serial / COM 2 x COM (1 x DB-9/F type to PC, 1 x RJ-45 type to VFD) DC Jack...

  • Page 23: Jumper Settings

    Jumper Settings Connectors and Functions Connector Purpose USB Audio USB Port (Down-Stream) Inverter Connector Keypad Connector LVDS Connector CN10 PS/2 Input Connector CN11 E-Turbo Touch Panel Connector CN14 ELO Touch CN15 OSD On/Off LED CN16 COM Port Connector (Output) PRW1 Power Adapter RJ45-1 COM Port Connector (Output)

  • Page 24: Motherboard Layout

    Motherboard Layout...

  • Page 25: Jumper Setting

    Jumper Setting 1. Touch Interface Setting (1-2,3-4,5-6,7-8) (1-2,3-4,5-6,7-8) Function RS232 ▲USB 2. Touch Setting (1-2,3-4,5-6) Function / Location JP11 ▲EXTERNAL INTERNAL 3. COM Power Setting Function / Location JP10 (1-2,3-4,5-6) ▲COM RI COM+5V COM+12V ▲ = Manufacturer Default setting...
  • Page 26 4. USB Channel Setting PORT2 Function / Location (1-2, 3-4, 5-6, 7-8) USB (CN4) ▲USB to Audio PORT4 Function / Location (1-2, 3-4, 5-6, 7-8) ▲MSR USB (CN2) 5. LCD ID Setting Panel LVDS (1-2,3-4,5-6,7-8) Resolution Size Bits Channel 15” 1024 Single 17”...
