Night Storm
nIGht StORM USeR'S GUIDe (Rev. 3, JULY 2010)
u s e r ` s
g u i d e
Important Export Restrictions! Commodities, products,
technologies and services contained in this manual are
subject to one or more of the export control laws and
regulations of the U.S. Government and they fall under the
control jurisdiction of either the US Department of State
or the US BIS-Department of Commerce. It is unlawful
and strictly prohibited to export, or attempt to export or
otherwise transfer or sell any hardware or technical data
AmERIcAN
or furnish any service to any foreign person, whether
abroad or in the United States, for which a license or written
TEchNologIES
approval of the U.S. Government is required, without
NETwoRk
first obtaining the required license or written approval
coRp.
from the Department of the U.S. Government having
jurisdiction. Diversion contrary to U.S. law is prohibited.
Advertisement
Table of Contents
Related Manuals for American Technologies Network Night Storm
Summary of Contents for American Technologies Network Night Storm
- Page 1 Night Storm nIGht StORM USeR’S GUIDe (Rev. 3, JULY 2010) u s e r ` s g u i d e Important Export Restrictions! Commodities, products, technologies and services contained in this manual are subject to one or more of the export control laws and regulations of the U.S.
-
Page 2: Optional Accessories
Register your product warranty online at www.atncorp.com /warranty Operating button 50mm F1:1.2 lens for maximum clarity Focus adjustment One 3 volt battery Built-in infra-red illuminator Diopter adjustment Objective lens protective cover LeD indicator Wrist strap opTIoNAl AccESSoRIES CAMeRA ADApteR CA4 InFRA-ReD ILLUMInAtOR IR450-B5 Item #AcmucA04 Item #AcmuIRb5... -
Page 3: Specifications
SpEcIfIcATIoNS Magnification ........ 3.5x Intensifier tube ......1+, 2+, CGt, hpt, Wpt, 3, 3A, 3p and G4. Lens system ........50mm, F1:1.2 FOv..........18° Diopter adjustment ....... ±5 Resolution........varies according to tube & Generation power supply ........ One 3 volt Lithium Range of focus ...... -
Page 4: Operation
ApplIcATIoN the night Storm night vision monocular is a complex opticoeiectronic system for individual use. the device consists of the objective lens assembly, eyepiece and the body. the body contains an image intensifier tube assembly with an integrated high voltage power source and the three volt battery housing. -
Page 5: Infra-Red Illuminator
Storm in order to get the sharpest possible image. • We suggest that you find an open space to work in. Focus the Night Storm so that the scene is at its sharpest. For best results you should disable the auto focus (if any) on either the 35mm camera or the video camera and manually focus the 35mm camera or the video camera. -
Page 6: Cleaning The Eyepiece
ANd cAuTIoNS • Always remember to turn the Night Storm off when it is not in use. If you do not plan on using your device for a period of more than 10 days, you should remove the batteries. -
Page 7: Year Product Warranty
2 yEAR pRoducT wARRANTy this product is guaranteed to be free from manufacturing defects in material and workmanship under normal use for a period of 2 (two) years from the date of purchase. In the event a defect that is covered by the foregoing warranty occurs during the applicable period stated above, Atn, at its option, will ei- ther repair or replace the product, and such action on the part of Atn shall be the full extent of Atn’s li- ability, and the Customer’s sole and exclusive remedy. - Page 8 For customer service and technical support, please contact American Technologies Network corp. North American Office 1341 San Mateo Avenue, South San Francisco, CA 94080 phone: 800-910-2862, 650-989-5100; fax: 650-875-0129 European Office the following countries can use our toll free number:...
