  • Page 1 THIS APPLIANCE TO RAIN OR MOISTURE. NOTE: This equipment has been tested and found to comply with the limits for a GS-16CH264 class digital device, pursuant to part 15 of the FCC Rules. These limits are designed This symbol is intended to...
  • Page 2: Table Of Contents

    Table of Contents CHAPTER 1 MAIN MENU SETUP To enter the main menu and set up DVR, log-in account and user password are required. The default password of the administrator is “123456”. Please check the “Account Setup” for CHAPTER 1 MAIN MENU SETUP ____________________________________4 related setup of other log-in users.
  • Page 3: Record Setup

    Table 1-0.2 The operation of remote control under the setting menu 1-1.1 Quality & Frame Rate Setup Item Description Switch to different options under one item Switch to different items MENU Save setup and back to LIVE mode Back to Upper level of menu without saving ENTER Enter the menu, or display virtual keyboard PS.
  • Page 4: 1-2.1 Motion Setup

    1-2.1 MOTION SETUP Item Description Mask Mouse Selection Switch between “select” and “deselect” for cursor-dragging function All Area Detection Select entire screen as detection area. Mask All Area Deselect entire detection area. Continue Continue setup Exit & Save Save setup and leave Exit &...
  • Page 5: Schedule Setup

    1-3.2 Holiday Setup 1-3 SCHEDULE SETUP Since holidays are different by different country and region, you can setup the holiday of your location accordingly. Except from starting recording manually, you can also setup the recording time by weeks and schedule including normal, motion detect, and recording type. 1-4 CAMERA SETUP Item Description...
  • Page 6: Account Setup

    1-5 ACCOUNT SETUP 1-5.2 User Picture Setup The Account Setup menu is used to provide role-based permission independently setting for each user (maximum of 4 users) to access DVR over network. The default admin account and Users can upload a selected picture from a remote computer password is “admin”...
  • Page 7: 1-6.1 Networking Setup

    1-6.1 NETWORKING SETUP 1-6.1.3 ADSL There are three ways to connect to the network as followed. Select ADSL for network connection, the following information is required. 1-6.1.1 DHCP When DHCP is selected, IP address will be assigned by DHCP server automatically. Item Description User Name...
  • Page 8: 1-6.2 Http Setup

    1-6.3 DDNS Setup Item Description Enable Enable advance setting User Name Enter ISP username Item Description Password Enter ISP password Enable DDNS Enable/disable DDNS function. Enter the registered DDNS Server: IP Address Enter the ISP provides a fixed IP address。 DDNS Server ez-dns*...
  • Page 9: 1-6.4 Mail Setup

    1-6.4 Mail Setup 1-7 PTZ & RS485 SETUP When an event occurs (VLOSS, MOTION), an email will be sent to the receiver’s account The DVR allows users to control PTZ functions of your camera. To enable PTZ function, the 485 automatically.
  • Page 10: System Setup

    1-8 SYSTEM SETUP Item Description Auto-Seq Interval Set up duration time in seconds for the interval between channels under Auto-Seq mode. Show OSD Turn On / Off OSD display Show DVR Status Turn On / Off DVR illustration and record status display Show Date/Time Turn On / Off date and time display Show Channel Name...
  • Page 11: 1-8.2.1 Change Date & Time

    1-8.2.1 CHANGE DATE & TIME 1-8.2.3 INTERNET TIME SETUP Setup date and time of DVR manually according to user’s local time. Synchronize your DVR time with internet time server. Item Description 1-8.2.2 TIME ZONE AND DAYLIGHT SAVING TIME SETUP Set up time zone and activate Daylight Saving Time function according to user’s DVR location. Check to enable DVR automatic synchronization function.
  • Page 12: 1-8.4 Spot Setup

    1-9 UTILITY SETUP Item Description Key Tone Enable/Disable Audible button presses for remote and panel Item Description Enable/Disable buzzer operation when the alarm is triggered for Buzzer Select to enter hard disk initialization menu. Please stop HDD Initialization sensor, motion and vloss (Video Loss). recording before entering this menu.
  • Page 13: Diagnostic

    1-10 DIAGNOSTIC CHAPTER 2 BACKUP & SEARCH 2-1 BACKUP SETUP User can backup any segment of recorded data in a specified time frame. To do so, either a CD R/W or storage device, like USB, must be connected to the DVR. The format of backup file is IRF file that can be played by both “Ifileplay”...
  • Page 14 iFileplay Instructions Step 4:Ifileplay software will play the irf file automatically. Step 1: install 「iFileplay」 software to your PC. You can get 「 iFileplay」 file from the CD with DVR Contents PS: When you using USB to backup file, iFileplay.exe will copy to USB with the backup file automatically.
  • Page 15: Search Setup

    2-2 SEARCH SETUP Item Description Criteria Setup conditions of event search Page Switch between pages of events Date/Time Date/time when event occurred. Event type, defined as following MOTION Motion Detected Video Loss Video Loss Remote Login user log-in over the network Remote Logout user log-out over the network Event Type...
  • Page 16: 2-2.2 Time Search

    CHAPTER 3 Remote Software Installation and Setup 2-2.2 TIME SEARCH 3-1 Remote Software Installation and instruction TIME SEARCH can search for the specific time of recording data to playback. Press “Enter” or Remote software:「DVR Remote Desktop」can allow you to remotely access and control the left click on the desired date to playback.
  • Page 17: How To Do Remote Monitoring Through Ie

    3-2 How to do remote monitoring through IE Step Four: Run or Save our remote software. Step One:Enter the IP address of DVR in IE browser. The address appeared in this image is only for demonstration. Actual address is depending on the setup of on-site DVR. Step Two: Windows as below will show up.
  • Page 18: How To Do Remote Monitoring Through Jpeg Viewer(Only Monitor Function)

    Step Four: DVR images appear. Step Three: Click on “Jpeg Viewer” Step Four: DVR images appear. 3-3 How to do remote monitoring through JPEG VIEWER(Only Monitor Fun ction) Step One:Enter the IP address of DVR in IE browser. The address appeared in this image is only for demonstration.
  • Page 19 3-4 Remote Software Operation Open the file “DVRemoteDesktop.exe”; enter the information of DVR “IP address”, “Port” “Username” and “Password” and click “OK”. You should be able to login DVR successfully and start to use the software. The default username and password is 「admin/ 123456」 “DVRemoteDesktop.exe”...
