Copland CTA506 User Manual

Table of Contents

Need help?

Do you have a question about the CTA506 and is the answer not in the manual?

Page 2 We would like to take this opportunity to thank you for selecting the CTA506 amplifier. We at Copland wish you many enjoyable hours in the company of fine music. Please read this owner’s manual before operating the equipment. Various regulation agencies require us to bring the following information to your attention.
Page 3 Use shielded cables to connect the signal source to the amplifier input. To minimise the possibility to hum the shielded cables should run parallel to each other or loosely twisted together. Locate the cables away from speaker leads and AC power cords. Selection of the proper gauge wire to connect the loudspeakers reserves the quality of sound reproduction for which the loudspeakers has been designed.
Page 4 AC. POWER OUTPUTS LEFT CHANNEL LIGHT 8 ohm 4 ohm 4 ohm FUSE. T.4 A POWER AMPLIFIER CTA506 INPUTS RIGHT INPUTS LEFT DESIGN BY COPLAND MADE IN DENMARK The AC Power Cord is plugged here. ! " % The amplifier AC power cord is plugged into a 110/120/220/240 volt 50/60 Hz wall outlet. The right voltage is indicated on the back panel just beside the series number.
Page 5 " 2 " Copland provides a warranty to the first purchaser for a period of one year. Copland usually commissions the Copland agency in the country in which the amplifier was purchased to carry out any warranty work. Following consent from Copland in a particular case, the warranty service may also be claimed at an agency in another country.
