Schiit RAGNAROK SCH-09 Owner's Manual

Universal managed amplifier
Hide thumbs Also See for RAGNAROK SCH-09:

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
ITEM
RAGNAROK
FOR
DESCRIPTION
UNIVERSAL MANAGED AMPLIFIER
SCH-09
MODEL NO
IN NORSE MYTHOLOGY, RAGNAROK IS THE END OF THE WORLD.
NOW, DON'T GET TECHNICAL WITH US ABOUT WHO SURVIVES.
OR ABOUT HOW IT'S THE TWILIGHT OF THE GODS.
OR IT NOT REALLY BEING THE END OF THE WORLD.
JUST GO WITH IT.
WE'RE DUMB AMERICANS WHO READ TOO MANY COMIC BOOKS.
NOTES
A
REVISION
RANDOM NUMBER
100000000
AUDIO EQUIPMENT

Advertisement

loading
Need help?

Need help?

Do you have a question about the RAGNAROK SCH-09 and is the answer not in the manual?

Questions and answers

Related Manuals for Schiit RAGNAROK SCH-09

Summary of Contents for Schiit RAGNAROK SCH-09

  • Page 1 OWNER’S MANUAL ITEM RAGNAROK DESCRIPTION UNIVERSAL MANAGED AMPLIFIER SCH-09 100000000 MODEL NO REVISION RANDOM NUMBER IN NORSE MYTHOLOGY, RAGNAROK IS THE END OF THE WORLD. NOW, DON’T GET TECHNICAL WITH US ABOUT WHO SURVIVES. OR ABOUT HOW IT’S THE TWILIGHT OF THE GODS. OR IT NOT REALLY BEING THE END OF THE WORLD.

  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS ITEM The following is required by the roughly 9,542 government agencies and regulations we have to comply with. If you have some common sense, they should seem pretty straightforward. In any case, read these instructions before proceeding farther, follow all instructions, and heed all warnings.

  • Page 3: What's In The Box

    WELCOME IMPORTANT Ragnarok is the ultimate amplifier—for Schiit, anyway. As a managed amplifier, Ragnarok may operate differently than you expect. Keep these things in mind when using Ragnarok: No, we’re not suddenly going to be putting out an even 1. On turn-on, input select, and gain select, Ragnarok does a system more super-duper amp, not after two years of R&D to...
  • Page 4 RAGNAROK CONNECTIONS ITEM SPEAKER OUTPUT SCH-09K 0A19C2832 UNIVERSAL MANAGED AMPLIFIER 115VAC 450W BALANCED OUTPUT SE OUTPUT INPUT 1 INPUT 2 INPUT 3 INPUT 4 INPUT 5 1 Balanced Input. 2 Another Balanced 3 Single-Ended Input. 4 Another Single- 6 Balanced Preamp 7 Single-Ended This is one of two Input.
  • Page 5 IN CASE YOU MISSED IT The speaker outputs on Ragnarok 8 Speaker Outputs. 9 Power Switch. Up 10 Fuse Tray. 11 Power Cord. Plug Connect these to your for on, down for off. Replace only with a the end of the supplied are all active.
  • Page 6 RAGNAROK CONTROLS ITEM 1 Input. Press this 2 Input Indicators. 3 Gain. Press this the best and gives 5 Volume. Turn it up to switched attenuator. button to cycle These indicate which button to cycle you the best range of increase volume, turn When you’re switching through the inputs.
  • Page 7 USING ONLY IN CASE YOU MISSED HEADPHONES OR IT, THE SEQUEL SPEAKERS 5 Gain Indicators. 7 Single-Ended SCENE 1 From left to right, 1, Headphone Output. Hold down the input Be very careful when using balanced 5, and 20. Or, smallest Ragnarok also has switch for 2 seconds.

  • Page 8: Clearing Faults

    CLEARING FAULTS ITEM Ragnarok has extensive fault checking built in, for maximum safety. 5. Connect your preamp outputs. Even the preamp outputs are It continuously monitors for DC offset, overcurrent, and bias. When monitored for faults. Turn up the volume. If the LEDs flash and the Ragnarok encounters a fault, it will mute the output, put the amp into amp cuts out again, you have a shorted preamp cable, or there is low-gain mode, bring the volume to zero, and flash the LEDs on the...
  • Page 9 ITEM Can I run both headphones and speakers at the same time? I hear hum from my headphones or speakers, what can I do? Yes, you can, and you can cycle between outputting to both headphones Loud hum is likely caused by a ground loop, which can be mitigated with and speakers, speakers only, and headphones only by holding down the a GFCI or ground loop isolator.
  • Page 10 SPECS ITEM Gain: 20 (26dB), 5 (14dB), 1 (0db) via front panel switch Frequency Response: 20Hz-20Khz, -0.1db, 2Hz-180KHz, -3dB Topology: Fully discrete Crossfet™ circlotron-style output stage with Maximum Power, 4 ohms: 100W RMS direct-coupled solid state gain stage, no DC servo. Maximum Power, 8 ohms: 60W RMS Protection: microprocessor monitoring of fault conditions including Maximum Power, 32 ohms: 15W RMS...

  • Page 11: Warranty

    OBTAINING WARRANTY SERVICE If you believe you need warranty service, contact us first. There may be a simple solution to your problem. Schiit Audio products sent back to us without a Return Authorization (RA) will be returned to the sender without repair. To contact us and obtain an RA, email support@schiit.com. We will respond quickly to email inquiries.
  • Page 12 YES, PRIMARILY OF US-SOURCED COMPONENTS. YES, IT’S PRONOUNCED EXACTLY LIKE YOU THINK. NO, WE ARE NOT ON FACEBOOK. NO, WE’RE NOT ON TWITTER. AND NO, WE’RE NOT ON YOUTUBE. SCHIIT AUDIO 24900 ANZA DRIVE, SUITE A VALENCIA, CA 91355 USA INFO@SCHIIT.COM SCHIIT.COM NOTES EVERYTHING ELSE AIN’T...
