FASTCOM: G232/8-PCI-335 ADAPTER CABLE

We provide access to the eight channels of the FASTCOM: G232/8-PCI-335 through a shielded HDDB78
connector and an adapter cable (supplied with the board). The adapter cable consists of a HDDB78 male plug
fanning out to eight standard DB25 male plugs.
Signals DIN1 (pin 19), DOUT1 (pin 20), DIN2 (pin 58), and DOUT2 (pin 59) are not connected to the cable.

HDDB78 Pin Description

SIGNAL
COLOR
NAME
DCD
RED
CTS
YELLOW
RXD
BLUE
RI
GREEN
DTR
PURPLE
DSR
BLACK
RTS
BROWN
TXD
WHITE
GND
ORANGE
They are available only on the board connector.
DB25 DB78 CHANNEL NUMBER / PIN NUMBER
PIN NO.
#1
8 1
5 2
3 3
22 21
20 22
6 40
4 41
2 60
7 61
#2 #3 #4
4 6 8
5 7 9
23 26 28
24 27 29
25 44 47
42 45 48
43 46 66
62 64 67
63 65 68
#5 #6 #7
10 13 15
11 14 16
12 32 35
30 33 36
31 34 53
49 51 54
50 52 55
69 71 73
70 72 74
®
Fastcom : G232/8-PCI-335
9
#8
17
18
37
38
56
57
75
76
77
