General information

plain staGe
meCHaniCal staGe
amgmicro.com
lCD Display
Power On Indicator
lCD Settings Button
lCD Control
lED lamp house
lCD Positioning Knob
Condenser assembly
Phase annuli Select Wheel
Image Capture Button
Plain Stage
Focus Control
Objective Select Wheel
lCD Display
Power On Indicator
lCD Settings Button
lCD Control
lED lamp house
lCD Positioning Knob
Condenser assembly
Phase annuli Select Wheel
Image Capture Button
Coarse Positioning
Y-axis Fine Positioning
X-axis Fine Positioning
Focus Control
Objective Select Wheel
3
Dimmer
adjustable Rubber Feet (4)
Dimmer
adjustable Rubber Feet (4)
Secure Digital (SD™) Card Slot
lCD tilt Knob
USB Connect Port
Note: Install software
before connecting USB.
Power Cord
Power Switch
Secure Digital (SD™) Card Slot
lCD tilt Knob
USB Connect Port
Note: Install software
before connecting USB.
Power Cord
Power Switch
