- Page 1 amgmicro.com QUICK START GUIDE Digital Inverted Microscope Fluorescence Transmitted Light Applications ZP-PKGA-0494 REV A...
- Page 2 Overview The EVOS fl microscope has two types of controls: mechanical and software. Mechanical controls include the stage X–Y axis knobs, Channel Bar focusing knobs, objective selection wheel, and the light cube selection lever. Software controls are located in the Control Bar at the bottom of the display screen.
- Page 3 Click the Overlay Tab to show all channels in color overlay mode. Save Button Adjust Brightness and Contrast for each channel to bring them into desired balance. Click the Save Button to save the color image (refer to EVOS fl User Guide).
- Page 4 Note: The EVOS fl User Guide is on the USB flash drive in the accessories box. You can also download it from the EVOS fl product page at www.amgmicro.com.
- Page 5 Light cube selection lever (left side of base) Phase annuli selector Condenser slider slot Stage Y-axis knobs Coarse stage positioning knobs USB and DVI ports Stage X-axis knob Objective selection wheel Focusing knob Power switch Power input jack...
- Page 6 Copyright © 2010 Advanced Microscopy Group. All rights reserved. ZP-PKGA-0494 REV A...
