parts & aCCessories
eVos microscopes with olympus optics
item
PlaIn StaGE: no objectives included
PlaIn StaGE: 4xPh, 10xPh, 20xPh
PlaIn StaGE: 4x, 10xPh, 20xPh, 40xPh
MEChanICal StaGE: no objectives included
MEChanICal StaGE: 4xPh, 10xPh, 20xPh
MEChanICal StaGE: 4x, 10xPh, 20xPh, 40xPh aME-3206
NOTE: EVOS microscopes with Olympus Optics are configured for
use specifically with the Olympus objectives listed below. Use with
any other objective besides those Olympus objectives listed below
will void AMG's warranty support for your EVOS microscope. with
Olympus Optics.
objectives, olympus
item amG part no.
4x Phase Objective aMEP-4602
10x Phase Objective aMEP-4603
aMEP-4604
20x Phase Objective
40x Phase Objective aMEP-4605
eVos microscopes with standard optics
item
MEChanICal StaGE: 4x, 10xPh, 20xPh
MEChanICal StaGE: 4x, 10xPh, 20xPh, 40xPh aME-i2112
PlaIn StaGE: 4x, 10xPh, 20xPh
PlaIn StaGE: 4x, 10xPh, 20xPh, 40xPh
NOTE: Objectives are not interchangeable between EVOS systems
with differing optics packages.
objectives, standard
item
4x Objective
10xPh Objective
20xPh Objective
40xPh Objective
amgmicro.com
part number
aME-3201
aME-3202
aME-3203
aME-3204
aME-3205
olympus part no.
1-U2C522P
1-U2C144P
1-U2C146P
1-U2C149P
part number
aME-i2111
aME-i2101
aME-i2102
part number
aMPI-OP004
aMPI-OP010PC
aMPI-OP020PC
aMPI-OP040PC
15
Vessel Holders
item
Vessel Holder for Slides;
holds two 12mm x 75mm standard
microscope slides, chamber slides, etc.
Vessel Holder for Petri Dishes;
holds four 35mm dishes
Vessel Holder for Petri Dishes;
holds two 60mm dishes
Vessel Holder for Petri Dish;
holds one 100mm dish
Vessel Holder for T-flasks;
holds two 25cm flasks,
2
rectangular or triangular
Vessel Holder for Nunc T-75 Flask;
holds one 75cm flask
2
Vessel Holder for Hemacytometer;
holds one 76mm x 33mm standard
hemacytometer
Vessel Holder for BD/Greiner T-75 flask;
holds one 75cm flask
2
Vessel holder for all vessel types; plain
stage functionality
Vessel Holder for BD/Greiner T-25 flask;
holds one 25cm flask
2
accessories
item
Power Adapter
Dust Cover
Circular Metal Stage Plate (Plain Stage)
USB2 Cable
Anti-Vibration Platform
filter slider assemblies
item
Filter Slider Assembly – Green
Filter Slider Assembly – Pinhole
Filter Slider Assembly - Diffuser
part number
aMEP-Vh001
aMEP-Vh002
aMEP-Vh003
aMEP-Vh004
aMEP-Vh005
aMEP-Vh006
aMEP-Vh007
aMEP-Vh008
aMEP-Vh009
aMEP-Vh010
part number
ZP-EC-00436
ZP-PKG-0403
aMPI-MSP1
ZP-EC-00365
aMEP-VIP1
part number
aMEP-CFG
aMEP-aS15
aMEP-DFS1
eVos™ User Guide
