LG Electronics U.S.A., Inc.
DLP Projection TV
OWNER'S MANUAL
MODELS: RU-44SZ63D
RU-52SZ53D
Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote this
information to your dealer when you require service.
Advertisement
Table of Contents
Troubleshooting
Related Manuals for LG RU-52SZ53D
Summary of Contents for LG RU-52SZ53D
- Page 1 LG Electronics U.S.A., Inc. DLP Projection TV OWNER’S MANUAL MODELS: RU-44SZ63D RU-52SZ53D Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this...
-
Page 2: Note To Cable/Tv Installer
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics Corporation. Unauthorized modification could void the user’s authority to operate this product. COMPLIANCE: The responsible party for this product’s compliance is:... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Important safeguards for you and your new product Your product has been manufactured and tested with your safety in mind. However, improper use can result in electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new product, please read and observe the following safety points when installing and using your new product, and save them for future reference. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS (Continued from previous page) 14. Outdoor Antenna Grounding If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded to provide protection against voltage surges and built-up static charges. -
Page 5: Table Of Contents
Table of Contents Safety Warnings ......2 Important Safety Instructions ....3-4 Function Status Indicators . -
Page 6: Function Status Indicators
Function Status Indicators Lamp indicator, operation indicator, and temperature indicator located below the front panel controls, reveal the operating status of the DLP projection TV. Operation Indicator Lamp Indicator Temperature Indicator P A G E 6 Operation Indicator Temperature Indicator Lamp Indicator Power cord is not connected. -
Page 7: Rear Connections Panel
Rear Connections Panel Connecting cables and external equipment to your TV. This manual explains the features available on the RU-44SZ63D TVs. PC and HD-STB Input Used to connect from a PC source or HD-STB Satellite system. PC/DTV (XGA /480p /720p /1080i) DVI INPUT Y, Pb, Pr... -
Page 8: Front Connections Panel
Front Connection Panel There are four jacks on the left side on your projection TV that make connecting Audio/Video devices like video games and cam- corders very simple. The jacks are like those found on the back jack connection panel. This means that most equipment that connects to those types of jacks on the rear jackpack, may be connected to the front con- nection panel. -
Page 9: Ant/Cable Service Hookup
ANT / Cable Service Hookup Connect an antenna or cable service to your TV as shown. Turn to page 22 to do a channel search with EZ Scan for Ant/Cable connection(s). If you receive your RF signal through an antenna that is several years old and connects with two small prongs, you will need to pur- chase a 300 to 75 ohm adapter. -
Page 10: Cable Box Connections
Cable Box Connections Locate the output jack on the back of your cable box. Connect this to the Antenna jack on the back of your TV. Or find the composite video and audio jacks on the back of your cable box, and connect them following the instructions provided with your equipment. -
Page 11: Vcr Connections
VCR Connections Locate the Antenna jack on the back of your TV. Connect this to RF out jack on the back of your VCR. Or, find the composite video and audio jacks on the back of your VCR, and connect them following the instructions provided with your equipment. -
Page 12: Dvd Player
DVD Player Find the audio and component or S-Video jacks on the back of your DVD Player and connect them fol- lowing the instructions provided with your equipment. You may connect either the com- posite video or the S-Video cables to your TV. -
Page 13: Rgb-Dtv/Dvi-Dtv Input
RGB-DTV/DVI-DTV Input Find the audio and Y, P /RGB/DVI jacks on the back of your DBS receiver and con- nect them following the instructions provid- ed with your equipment. Connect these cables to your TV as shown. The DTV shows the sharpest picture in 720p mode. This TV supports HDCP (High-bandwidth Digital Content Protection) protocol for DVI-DTV (480p, 720p, 1080i) mode. -
Page 14: Rgb-Pc/Dvi-Pc Input
RGB-PC/DVI-PC Input Find the audio and RGB or DVI jacks on the back of your PC and then connect them fol- lowing the instructions provided with your equipment. Connect these cables to your TV as shown. Computer Select RGB-PC Source and press ENTER. Use UP/DOWN arrows to select the desired options (H-Position/V-Position/H-Size/V- Size/Phase) and then use LEFT/RIGHT arrow to make appropriate adjustments. -
Page 15: External Stereo Connections
External Stereo Connections Connect Left/Right Variable Audio Output to an external Audio Amplifier System. Locate both Variable Audio Out jacks on the back of your TV and the Left/Right audio input jacks on the back of your stereo's amplifier. Connect these jacks, making sure that they are connected correctly. -
Page 16: Home Theater: Speaker Layout
Home Theater: Speaker Layout This is a typical speaker layout. Any number of other speaker setups are possible, and some changes may be needed to maximize your sound. However, a Dolby Digital Receiver is required to hear 5.1 channel audio. Left and right speakers on each side of the TV enhance separation. -
Page 17: Monitor Out Setup
Monitor Out Setup Your TV has a special signal output capa- bility which allows you to hook up a sec- ond TV or monitor. Just connect the second TV or monitor to the MONITOR OUT Audio/Video jacks locat- ed on the back of your TV. See the Operating Manual of the second TV or monitor for further details regarding that device’s input settings. -
Page 18: Remote Control Functions In Tv Mode
Remote Control Functions in TV Mode MODE Selects the remote operating mode: TV, VCR, Cable, DVD and Satellite. Select other operating modes, for the remote to control external devices. TV/VIDEO Selects: Analog, Video1, Video2, Front video, Component1-2, RGB, and DVI input sources. FRONT Selects the front video signal if a device, such as a camcorder or... -
Page 19: Volume Up/Down
Remote Control Functions in TV Mode COMPONENT 1, 2 Selects component signal sources, such as DVD or HD receiver. NUMBER KEYPAD For direct channel selection and programming functions. ENTER When in the menu system and other on-screen displays, selects highlighted options. VOLUME UP/DOWN Increases/decreases the sound level. -
Page 20: On-Screen Displays
On-Screen Displays This page describes your on-screen display and information banner options. Mute Appears when sound is muted. P A G E 2 0 Main Channel Display Displays current channel number. Volume Volume level is displayed while adjusting the sound. Channel Label If a channel label has been set, then it will appear here. -
Page 21: Front Panel Controls
Front Panel Controls POWER MENU ENTER POWER MENU ENTER (Same as ENTER button on your remote control) VOLUME UP / DOWN CHANNEL UP / DOWN Operation indicator. (See page 6). Lamp indicator. (See page 6). Temperature indicator. (See page 6). - This manual explains the features available on the RU-44SZ63D TVs. -
Page 22: Ez Scan (Channel Search)
EZ Scan (Channel Search) Automatically finds analog channels available through ANT IN input, and stores all active over-the-air and cable channels in memory on the channel list. Refer to pages 7-17 to connect external equipment to your TV. If you have done so, plug in your TV to a standard (non- switched) 120V 60Hz power outlet. -
Page 23: Channel Add/Delete/Surf Setup
Channel Add / Delete / Surf Setup EZ Scan SETUP SETUP Ch. Edit VIDEO VIDEO Ch. Label Main Input AUDIO AUDIO Sub Input Booster TIME TIME SPECIAL SPECIAL LOCK LOCK MENU Prev. Create two different types of channel lists in memory: “Custom list” and “Surf list”. -
Page 24: Channel Labels Setup
Channel Labels Setup EZ Scan SETUP SETUP Ch. Edit VIDEO VIDEO Ch. Label Main Input AUDIO AUDIO Sub Input Booster TIME TIME SPECIAL SPECIAL LOCK LOCK Prev. MENU Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Setup menu. -
Page 25: Main Picture Source Selection
Main Picture Source Selection Changes the picture source for the main screen so you can watch your TV, cable TV, VCR, DVD, or any other devices that are connected to your TV. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Setup menu. -
Page 26: Pip (Picture-In-Picture) / Twin Picture Operation
PIP (Picture-in-Picture) / Twin Picture Operation PIP lets you view 2 different inputs (sources) on your monitor screen at the same time. One source will be large, and the other source (PIP) will show a smaller inset image. Twin Picture splits the screen into 2, allowing 2 pictures to be shown on the TV screen at the same time. Each source is given half the screen. -
Page 27: Pop (Picture-Outside-Picture)
PIP (Picture-in-Picture) / Twin Picture Operation Selecting PIP / Twin Picture Channels Press the PIP button on the remote control to select PIP or Twin picture mode. Select the Ant/Cable source with the PIP INPUT button. Use the PIPCH-/PIPCH+ button to select a channel for the sub picture. Swapping Pictures Press the SWAP button. -
Page 28: Booster
Booster If TV signal reception is poor because you are in a fringe area, set Booster to On. If the picture condition is good, set Booster to Off. Adjustments for one channel don’t affect the adjustment for other channels. Set booster to on or off for each channel separately. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Setup menu. -
Page 29: Video Menu Options
Video Menu Options Adjust the picture appearance to suit your preference and viewing situations. Press the MENU button on the remote con- trol, then use the UP/DOWN arrow button to select the Video menu. Press ENTER or the RIGHT arrow button to access the Video menu. -
Page 30: Video Menu Options
• Color Temperature Adjusts levels of all colors in the TV picture: Warm, Medium, or Cool. • LG electronic’s unique picture improving technology to display a real HD source through an advanced digital signal processing algorithm. P A G E 3 0... -
Page 31: Audio Menu Options
Audio Menu Options Adjust the sound to suit your taste and room situations. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Audio menu. Press ENTER or the RIGHT arrow button to access the Audio menu. Use the UP/DOWN arrows to select one of the following options: EZ SoundRite, EZ Sound, Balance, Treble, Bass, Front... - Page 32 Audio Menu Options SETUP SETUP VIDEO VIDEO AUDIO AUDIO Bass TIME TIME SPECIAL SPECIAL LOCK LOCK • EZ SoundRite Scans for changes in the sound level during commercials, then adjusts the sound to match the current audio level of the TV program you are watching. •...
-
Page 33: Auto Clock Setup
Auto Clock Setup Sets the time automatically from the PBS broadcast sig- nal. The PBS channel signal includes information for the cor- rect time. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. Press ENTER or the RIGHT arrow button to activate the Time menu. -
Page 34: Manual Clock Setup
Manual Clock Setup Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. Press ENTER or the RIGHT arrow button to activate the Time menu. Use the UP/DOWN arrow button to choose Manual Clock, then press the RIGHT arrow to activate the Manual Clock menu. -
Page 35: Tv Turn Off Timer Setup
TV Turn Off Timer Setup Lets you set an automatic daily turn off time for your TV. Off Timer function overrides On Timer function if they are both set to the same time. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. -
Page 36: Tv Turn On Timer Setup
TV Turn On Time Setup Time function operates only if current time is set. Unless a button is pressed within two hours after the TV is turned on by the On timer function, the TV will auto- matically turn itself off. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. -
Page 37: Sleep Timer Setup
Sleep Timer Setup Select a preset time to turn your TV off automatically. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. Press ENTER or the RIGHT arrow button to activate the Time menu. Use the UP/DOWN arrow to choose Sleep Timer then press the RIGHT arrow to access the Sleep Timer menu. -
Page 38: Auto Off
Auto Off If there is no input signal, the TV can be set up to switch to standby mode automatically after 10 minutes. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. Press the RIGHT arrow button to activate the Time menu. -
Page 39: Aspect Ratio
Aspect Ratio Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Special menu. Or press RATIO button to instantly access the Aspect Ratio . Press ENTER or the RIGHT arrow button to acti- vate the Special menu. -
Page 40: On-Screen Menu Languages
On-Screen Menu Languages Select your preferred language for the menus: English, Spanish, or French. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Special menu. Press ENTER or the RIGHT arrow button to activate the Special menu. -
Page 41: Captions Setup
Captions Setup Using the menu Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Special menu. Press ENTER or the RIGHT arrow button to activate the Special menu. Use the UP/DOWN arrow to choose Captions, then press ENTER or the Right arrow button. -
Page 42: Caption/Text Mode Selection
Caption/Text Mode Selection Select a closed caption mode for displaying captioning information when provided on the program. Captions displays information at any position on the screen usually the program's dialog. Text displays information, usually at the bottom position and is used for a data service, generally not program related. -
Page 43: Key Lock
Key Lock The TV can be set up so that it can only be used with the remote control. The feature can be used to prevent unauthorized viewing by disabling the front panel controls. The TV is programmed to remember which option it was last set to even if you turn the TV off. -
Page 44: Cinema Mode Setup
Cinema Mode Setup Set up the TV for the best picture appearance for viewing movies. When you operate Cinema (3:2 Pull-Down Mode or Cinema Correction Mode), the TV will adjust 24 fps video from movies to 30 fps video for display (This function is only available in Component 480i mode.) Press the MENU button on the remote control, then use the UP/DOWN arrow... -
Page 45: Demo (Menu Review)
Demo (Menu Review) EZ Demo Use to scan the features and menu options available on your TV. XD Demo Use to see the difference between XD Demo On and XD Demo Off. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Special menu. -
Page 46: Parental Lock Setup
Parental Lock Setup Lets you set up blocking schemes to block specific chan- nels, ratings and external sources. A password is required to gain access to this menu if the Lock System is active. Press the MENU button on the remote con- trol, then use the UP/DOWN arrow button to select the Lock Menu. -
Page 47: Parental Lock (Ratings Overview)
Parental Lock (Ratings Overview) Parental Lock Rating Descriptions Lock System SETUP SETUP Set Password VIDEO VIDEO Block Ch. Movie Rating AUDIO AUDIO TV Rating- Children TV Rating-General TIME TIME Aux. Block SPECIAL SPECIAL LOCK LOCK Prev. MENU TV-Y7 (Children 7 Years & Older): Program is designed for children age 7 and above. TV-G (General Audience): Most parents would find this program suitable for all ages. -
Page 48: Programming The Remote
Programming the Remote The remote control for your HD receiver is a multi-brand or universal remote control that can be programmed to operate most remote-control- lable devices of other manufacturers. Note: The remote control may not be able to con- trol all models of other brands. -
Page 49: Programming Codes
Programming Codes: TVs Brand Codes Brand A MARK 112 143 GOLDSTAR ADMIRAL 072 081 161 AKAI 006 146 AMPRO 073 167 AMSTRAD HALL MARK ANAM 043 054 056 HITACHI 080 104 108 112 115 118 121 131 004 006 058 INFINITY BLAUPUNKT INKEL... - Page 50 Programming Codes: VCRs VCRs Brand Codes Brand AIWA AKAI 016 043 046 124 125 146 KENWOOD AMPRO ANAM 031 033 103 AUDIO DYNAMICS 012 023 039 LLOYD BROKSONIC 035 037 129 CANON 028 031 033 CAPEHART MAGIN CRAIG 003 040 135 MAGNAVOX CURTIS MATHES 031 033 041...
- Page 51 Programming Codes: SAT/DVDs Brand Codes Brand ALPHASTAR DSR AMPLICA GENERAL INSTRUMENT 003 004 016 BIRDVIEW 051 126 129 CAPETRONICS HITACHI CHANNEL MASTER 013 014 015 HOUSTON TRACKER 018 036 055 CHAPARRAL 008 009 012 HUGHES HYTEK CITOH JANIEL CURTIS MATHES 050 145 JERROLD DRAKE...
-
Page 52: Programming Codes
Programming Codes: Cable Boxes CATV Brand Codes Brand 003 004 039 042 046 052 ANTRONIK M-NET ARCHER 005 007 014 MACOM MAGNAVOX CABLE STAR CENTURION MEMOREX CENTURY MOVIE TIME CITIZEN COLOUR VOICE 065 090 COMBANO 080 081 COMTRONICS 019 030 DIAMOND PANASONIC EAGLE... -
Page 53: Maintenance
Maintenance Early malfunctions can be prevented. Please read pages 2-3-4 in the front of the manual and follow the recom- mendations provided. Careful and regular cleaning of your new TV can enhance its appearance and your viewing pleasure. Be sure to turn the power off and pull out the plug before you begin any cleaning. SCREEN CLEANING 1. -
Page 54: Troubleshooting
Troubleshooting Some quick and easy tips to fixing problems yourself. SYMPTOMS Snowy picture and unclear sound. Multiple images or ‘ghost shadows.’ Interference: Sharp lines across the screen and unclear sound. Normal picture but no sound. No picture and unclear sound. No picture and no sound. -
Page 55: Troubleshooting
Troubleshooting (Contd.) Remote control doesn’t work. Menu options can’t be changed or selected. No picture or sound when any non-cable source is selected. Weak or no Stereo Sound when using a stereo VCR. The PIP inset is black or lacks contrast. The PIP inset is “snow”... -
Page 56: Glossary
Glossary A list of definitions for some of the words found in this guide as they relate to these TVs. 75 OHM RF CABLE The round cable that comes from an off-air antenna or cable service provider. Each end looks like a hex shaped nut with a wire sticking through the middle, and it screws onto the threaded jack on the back of your TV. -
Page 57: Glossary (Contd.)
Glossary (Contd.) A list of definitions for some of the words found in this guide as they relate to these TVs. HD-STB High-definition set-top box. INPUT Refers to the jack that receives a signal into the TV, VCR or other A/V device. -
Page 58: Product Specifications
Product Specifications Models RU-44SZ63D RU-52SZ53D Power Requirement Television System Television Channels Power Consumption (W) Antenna Audio Output (W) External Input/Output Ports Design and specifications are subject to change without prior notice. P A G E 5 8 Horizontal Size (Inches) 41.7... - Page 59 If a replacement unit is required, under some circumstances you may be asked to provide a reserve deposit to the LG®Brand Service Center against a credit card number as surety for advanced shipment. Your credit card will not be charged if you return the defective unit within 10 working days.
-
Page 60: Warranty
Your LG® brand DLP Rear Projection Television will be repaired or replaced as set forth below, if it proves to be defec- tive in material or workmanship under normal use, during the warranty period ("Warranty Period") listed below, effec- tive from the date ("Date of Purchase") of original consumer purchase of the product. This warranty is good only to the original purchaser of the product and effective only when used in the United States, excluding U.S.
