Replacing Slip-On Back Upholstery - Probasics EC03 Owner's Manual

REPLACING SLIP-ON BACK UPHOLSTERY

Standard High Strength Lightweight manual wheelchairs)
1. Remove the twp (2) mounting screws
and washers that secure the existing
back upholstery to the back canes.
2. Remove the mounting screw and locking
knob that secure one (1) back cane to
the wheel chair frame.
NOTE: It is necessary to remove only
one (1) back cane to replace the back
upholstery.
3. Pull the loose back cane out of the existing back upholstery.
4. Pull the existing back upholstery up and over the mounted back cane.
5. Install the NEW back upholstery over the mounted back cane.
6. Slide the loose back cane to the wheelchair frame with the mounting screw and
locking knob.
7. Secure the back cane to the wheelchair frame with the mounting screw and locking
knob.
8. Secure the NEW back upholstery to the back canes with the existing mounting
screws and washers.
21
(Deluxe and
